- Page 1 ASSEMBLY INSTRUCTIONS Comfort Lift Version: May 2021...
- Page 2 Place the upholstered box spring on a dry and protected surface. Unscrew and remove the wooden transport slats. These are only for transporting the box spring. Remove the bolts from the mounting holes (see photo below). Now, take the frame. Leaving the cable ties in place, mount the legs/wheels under the frame.
- Page 3 Put the metal frame in the correct position on the box spring. Pictograms show the head and foot ends on the frame and on the box spring. Remove all red cable ties, including those securing the mains cable and the remote control. Do not cut the 2 white cable ties on the ends of the metal frame as yet.
- Page 4 Next, also screw in all the bolts that were loosened earlier. When all the bolts are in place, tighten them. Mount the hook-on fittings for the headboard and the foot bracket, if using. Make sure that the mains cable is free. Now, turn the box spring over and cut the white cable ties on both ends.
- Page 5 Mounting the optional foot bracket Place the box spring bottom side up on a mattress. Now place the foot bracket and position it nicely in the middle. Fasten the foot bracket with the seven screws supplied. Page 5 of 7...
- Page 6 Remote control Status LED Motor “back” up Motor “back” down Motor “legs” up Motor “legs” down Tilt the bed up Tilt the bed down Bed flat up Bed flat down Memory position 1 Memory position 2 Flashlight If the status LED and the backlight of the remote control are flashing, the remote control has not yet been synched to the motor.
- Page 7 System reset Press and hold the motor's learning button until it adjusts (this happens after about ten seconds). On the remote control, press and hold the first three buttons on the left of the remote simultaneously (1, 3, 5) until the status LED emits a steady light (this takes about five seconds). Now, if you release the buttons, the status LED and the buttons will start flashing again.
