Summary of Contents for Pinnacle Smart Thermostat

  • Page 1 Smart Thermostat User Guide Easy Touch. Easy Warm.
  • Page 2 www.underfloorshop.co.uk • 01284 339 669...
  • Page 3: Table Of Contents

    Contents Installation Function & Operation Temporary Override Temperature Wiring Instructions Mode Key-Lock Wifi Connection Menu Clock Thermostat Symbols Event Setting Readout Start Up Wizard Advanced Setting Open Window Detection Troubleshooting Dimensions www.underfloorshop.co.uk • sales@underfloorshop.co.uk...
  • Page 4: Installation

    The Pinnacle Smart Thermostat is an intuitive programmable thermostat which can be used to control either electric or wet underfloor heating systems. It will keep your home at a comfortable temperature whilst minimising energy use. Simply install the app on your smart phone to control your Pinnacle Smart thermostat remotely. Technical Specifications...
  • Page 5: Wiring Instructions

    Wiring Instructions ROOM-OUT SENSOR FLOOR SENSOR FLOOR SENSOR For installations in a bathroom or wet location where the thermostat cannot be installed within the room, please select either floor sensor, remote air sensor or floor sensor and remote air sensor. A remote air sensor (room-out sensor) can be purchased separately.
  • Page 6: Wifi Connection

    WiFi Connection Step 3: Click "Add Device" followed by "Wifi Thermostat" on the bottom of the screen. Step 2: Create and account, then login through the registered phone number or email address. Step 4: Check the thermostat WiFi flag is fast flashing. If not,operate the thermostat according to the APP tips until it flashes quickly.
  • Page 7 Step 6: Click “Done” after the APP has connected successfully to the thermostat. Step 5: Fill in the phone with the WiFi network password, click “confirm”. You can check the real-time temperature, Step 7: adjust or set the temperature, switch on/off or do other operations on the main interface.
  • Page 8: Thermostat Symbols

    Thermostat Symbols Once the thermostat has been installed and connected to the electric supply, simply turn the thermostat on using the Master On/Off switch on the side of the thermostat. Slide the switch down to turn on or up to turn off. •...
  • Page 9: Startup Wizard

    Startup Wizard Initial settings must be set when the unit is activated for the first time, this will ensure correct and efficient use of your underfloor heating system. Clock Sensor Selection There are 5 options: • 00 Floor sensor: run by floor sensor only (default).
  • Page 10: Function & Operation

    Function & Operation Temporary Override Temperature On the actual temperature interface, press the to set temporary override temperature. The temperature is only valid at the current event and it will not be saved. Mode On the main display, Press the to select the mode.
  • Page 11: Menu

    Menu On the main display, press and hold the for 3 seconds to enter menu. Set day and time Sensor Used for heating Selection or cooling Room Set event’s Adaptive Temperature parameters Function Calibration READ Floor Located in Home Read heating Temperature or Office time of a...
  • Page 12: Clock

    Clock The default interface of the menu is CLK. Day and clock is set here. Press the to enter day setting. Press the to set day. Press the to enter hour setting. Press the to set hour. Press the to enter minute setting. Press the to set minute.
  • Page 13: Readout

    Default Parameters (Wake) (Leave) (Back) (Sleep) Mon - Fri 06:00 20.0°C 08:30 15.0°C 17:00 20.0°C 23:00 15.0°C Home Sat / Sun 06:00 20.0°C 08:30 20.0°C 17:00 20.0°C 23:00 15.0°C (Wake) (Leave) Mon - Fri 07:00 20.0°C 18:00 15.0°C Office Sat / Sun 07:00 15.0°C 18:00 15.0°C Readout...
  • Page 14 Number Name Default Setting Options 00: Floor Sensor 01: Room-In Sensor 00: Floor Sensor 02: 01+00 Sensor Selection 03: Room-Out Sensor 04: 03+00 0.0°C -5.0°C — 5.0°C Room Temp Calibration 0.0°C -5.0°C — 5.0°C Floor Temp Calibration 35.0°C 20.0°C — 50.0°C Floor Temp Limit 00: 7 00: 7...
  • Page 15: Open Window Detection

    Sensor selection: There are 5 options: 00 Floor sensor: uses the floor sensor only (default). 01 Room-in sensor: uses the built-in room sensor. 02 Room-in sensor and floor sensor: uses the built-in sensor with floor temperature limit. 03 Room-out sensor: uses a remote air sensor. 04 Room-out sensor and floor sensor: uses a remote air sensor with floor temperature limit.
  • Page 16: Troubleshooting

    Troubleshooting E1: Room-in sensor error. E2: Floor sensor error. E4: Room-out sensor error. Dimensions (mm) www.underfloorshop.co.uk • 01284 339 669...
