- Page 1 SPIDERMIKE 2 S S S ERMIKE MANUAL VERSION 1.0, MAY 2011 Designed and Manufactured by ITEC Tontechnik und Industrieelektronik GesmbH 8200 Laßnitzthal 300 Austria / Europe...
-
Page 2: Dear Customer
For knowing the entire system, all its possibilities and for executing the necessary confi guration tasks the soft- ware manual is required in addition. Please observe during the installation / operation of the ITEC SpiderMike 2 all listed safety instructions in this manual; furthermore data and examples provided ensuring the optimum usage of the device. -
Page 3: Safety Instructions
When installing the device, the local connecting conditions, the required protective measures and all relevant standards have to be observed. The installation and confi guration of the ITEC SpiderMike 2 must be performed by trained personnel only. For the confi guration the original software ITEC NetDesign has to be used exclu- sively. - Page 4 ITECNET is a decentralized, Ethernet-based audio network for the simultaneous transmission of up to 64 audio channels with the highest audio quality. At the same time, a huge number of system data, measurement data and IOs are controlled and transmitted. ITEC SPIDERMIKE 2 www.itec-audio.com...
- Page 5 OnTime: Total running time of the device Audio Out 1 Speaker 6 External Controls Audio In 1 XLR 4 Logic Outputs Audio In 2 Audio Out 2 RS 232 4 Logic Inputs 24 V DC Audio Out 1 Speaker Bottom view ITEC SPIDERMIKE 2 www.itec-audio.com...
-
Page 6: Block Diagram
+30 dB IN 1 OUT 1 Volume ∞ Delay ÷ +20 dBs +12 V μP Priority μP 0 dB OUT 2 IN 2 +30 dB Sig+ Sig+ ∞ OUTPUT UNIT 2 Sig- Delay Sig- ÷ +20 dBs ITEC SPIDERMIKE 2 www.itec-audio.com... -
Page 7: Power Supply 24 V Dc
The fi rst audio output device drives the built-in speaker with an output of 1 watt. A second, balanced line out- put is designed as plug terminal block in the housing. The maximum output level is +15 dB. Out 1 Out 2 Signal + Signal - ITEC SPIDERMIKE 2 www.itec-audio.com... -
Page 8: Digital Inputs
36 V DC μP Outputs 4 Logic Ouputs Open Collector = 36 V DC = 200 mA per Channel SPIDERMIKE 2 Out1÷Out8) = 500 mA ∑ TOTAL ITEC SPIDERMIKE 2 www.itec-audio.com... -
Page 9: External Control Inputs
If a link to second redundant network is planned, socket B is used. The LEDs on the RJ45 connector show the operating status of the network connection: Green LED on: Connected Green LED fl ashing: Connected and network activity Yellow LED on: valid connection (100Mbps full duplex) ITEC SPIDERMIKE 2 www.itec-audio.com... - Page 10 Each SpiderMike 2 station is equipped with a SD Card slot by default. Micro SD cards with a storage capacity up to 2 GB can be used. On the SD card up to 256 sound fi les can be stored: Possible are alarm texts, safety instructions, signal tones as well as advertising messages or jingles. ITEC SPIDERMIKE 2 www.itec-audio.com...
- Page 11 The station SpiderMike 2 can be supplied with 19“ brackets for rack assembling. A base station with an expansion module respectively with a dummy unit results in a 19” mountable component with 5 rack units in height. ITEC SPIDERMIKE 2 www.itec-audio.com...
- Page 12 Micro SD cards up to 2 GB NETWORK Ethernet 100 Base-TX, IEEE 802.3u No responsibility is taken for the correctness of this information - Specifi cations subject to change ITEC- Tontechnik und Industrieelektronik GesmbH, A-8200 Lassnitzthal 300 Tel.: +43 (0)3133 / 3780-0, offi ce@itec-audio.com, www.itec-audio.com...
