- Page 1 Instructions for use. piper. The comfortable, folding rehab buggy.
- Page 2 Instructions for use may deviate from your product due to differing equipment. We reserve the right to make technical modifications. Important information! Ensure that these Instructions for use remain with the product. Your schuchmann Team...
-
Page 3: Table Of Contents
Contents. 1. Preparation................. 05 1.1 Delivery ..........................05 1.2 Safety measures prior to use ................05 1.3 Safe disposal .......................05 1.3.1 Packaging ......................05 1.3.2 Product ........................05 1.4 Where to store the Instructions for use ............05 2. Product description..............06 2.1 Material information ....................06 2.2 Handling and transport ..................06 2.2.1 Folding the frame ...................06 2.2.2 Unfold frame .................... - Page 4 Contents. 6. Technical data................18 7. Guarantee................... 19 8. Identification................20 8.1 EU Declaration of Conformity ................20 8.2 Serial number / date of manufacture ............21 8.3 Product version ......................22 8.4 Issue of the document ..................22 8.5 Name and address of the manufacturer, importer and supplying specialist dealer .......................
-
Page 5: Preparation
1.4 Where to store the Instructions for use Please store these Instructions for use carefully and ensure that these In- structions for use remain with the product in case of re-use. Should you lose the instructions, you can always download an updated version at www.schuchmann.de . -
Page 6: Product Description
2. Product description. 2.1 Material information The base frame as well as the individual elements are made from pow- der-coated aluminium and are therefore free from corrosion. The covers are made of 100% polyester and are flame resistant (according to DIN EN 1021-1+2). -
Page 7: Unfold Frame
2. Product description. In order to better store the buggy e.g. in the car, the wheels can be removed. In order to better store the rehab buggy e.g. in the car, all wheels can also be removed. To do this, press the pushbuttons (A) on the rear wheels and at the same time pull out the wheels to the side. -
Page 8: Locking The Rear Wheels
2.2.5 Securing the user The piper. rehab buggy is equipped as standard with a 5-point harness that must be used to secure the user. To set the desired length of the... -
Page 9: Application Areas, Use According To The Intended Purpose
• Practice handling piper. on even ground. You must also research the effects of shifts in the centre of gravity on the behaviour of the piper. Try tilting with the tilting aid (see Point 2.2.4) and the shift in the centre of gravity at first without occupants. -
Page 10: Equipment For Basic Model
• When using the rehab buggy, keep any extremities away from moving parts. • When folding the piper. there is the risk of jamming or crushing the extremities. • Read these operating instructions carefully before using the buggy for the first time. -
Page 11: List Of Accessories
2. Product description. 2.6 List of accessories • Headrest • Seat reduction • Seat padding • Foot positioner • Summer foot bag • Winter foot bag • Rain cape 2.7 Product overview The Fig. below is intended to show you the designation of the most important components as well as the terms which you will find in these Instructions for use. -
Page 12: Settings
3.1 Backrest The angle of the piper. backrest can be adjusted in five stages by a total of 45°. To this end, you must pull the release lever (A) on the rear of the backrest. -
Page 13: Foot Support
3. Settings. 3.3 Foot support The height of the foot support can be adjusted in five stages. To this end, pull out the two self-securing locking bolts (A) at the foot support brackets and at the same time bring the foot support into the desired position. -
Page 14: Seat Reduction
4. Accessories. 4.2 Seat reduction The seat reduction (A) consists of a to- tal of 6 elements that can be attached to the sides of the seating surface using hook and loop. Each individual element is equipped with hook and loop. In this way, you can decide yourself how many ele- ments you attach for reach side and thus adjust the desired seat width. -
Page 15: Summer Foot Bag
4. Accessories. 4.5 Summer foot bag The summer foot bag (A) is attached to the canopy (C) using press studs (B). At the food end, the summer foot bag (A) has a zipper (D). 4.6 Winter foot bag The winter foot bag (E) has a zipper(F) on both sides for easy access and exit. -
Page 16: Cleaning And Servicing
The over can be washed at 40° by hand. Please also pay attention to our general cleaning and hygiene advice. This can be found at www.schuchmann.de/mediathek. 5.2 Disinfection Disinfection should only be carried out when needed. For disinfection, please use prepared, liquid disinfecting solution or cloths pre-soaked in disinfecting solution and ensure extensive application. -
Page 17: Duration Of Use And Re-Use
5. Cleaning and maintaining. 5.5 Duration of use and re-use The expected duration of use of our product, dependent on the usage intensity and amount of re-use, totals up to "8" years if the usage takes place in accordance with the information in these Instructions for use. It may be possible to use the product over and above this time period if it is in a safe condition. -
Page 18: Technical Data
6. Technical data. Dimensions - basic model piper. Backrest height 68 cm Seat depth 29 cm Seat height 36 cm Seat width 24 - 35 cm Lower leg length 25 - 37.5 cm Backrest angle 90° - 135° Seat angle 26°... -
Page 19: Guarantee
7. Guarantee. The two-year statutory guarantee period shall apply for all products. This begins with the delivery or handover of the goods. Should the goods supplied by us manifest a verifiable material or manufacturing fault within this time period, kindly contact directly the supplying specialist dealer (see Point 8.5) -
Page 20: Identification
8. Identification. 8.1 EU Declaration of Conformity... -
Page 21: Serial Number / Date Of Manufacture
8.2 Serial number / date of manufacture The serial number, the date of manufacture as well as other details can be found on the type plate (A) by Patron and another sign (B) by Schuchmann. Type plate (A) (Patron): Serial number... -
Page 22: Product Version
8. Identification. 8.3 Product version The piper. rehab buggy is available in one size and can be supplemented through a diverse range of accessories (see Point 4). 8.4 Issue of the document Instructions for use piper. - Change status A; issue 09.2020 8.5 Name and address of the manufacturer, importer and supplying spe-... - Page 23 Notes.
