Forest AV ELECTRIC FORS03-22R Assembly Instructions

H eight Adjustable D esk Fram e
Model: FORS03-22R
FOREST AV
FOREST-AV.com
WARNING: FAILURE TO COMPLY WITH OR OBSERVE ALL
ASSEMB LY, SAFETY AND OPERATION INSTRUCTIONS AND
WARNINGS REGARDING THE USE OF THIS PRODUCT MAY
WARN IN G RESULT IN SERIOUS BODILY INJ URY.

Important information

Read the entire instruction manual before you start
installation and assembly.
This product is not intended for use by young children without supervision.
This product contains small items that could be a choking hazard if swallowed. Keep these items
away fromchildren.
This product is intended for indoor use only. Using this product outdoors could lead to product
failure and personal injury.
This product can be used by children from8 years old (supervised) to Adult. Users with disabilities
or lack of experience and operating knowledge should be supervised and given careful instruction
prior to using this product. The desktop should never be sat on and children should be prohibited
fromhaving unsupervised contact with the product.
Cleaning and user maintenance shall not be made by children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or a
similarly qualified person in order to avoid a hazard.
IMPO RT ANT : Ensure that you have received all parts according to the component checklist prior
to installation. If any parts are missing or faulty, telephone your local distributor for a replacement.
Q UICKTIP: DONO Tover-tighten screw s duringinstallation.
CAUTIO N:
·Please place the product away fromcorrosive gas, water and dusty environment.
·Please do not disassemble all the components, otherwise, it will be seen as the withdrawn of
the warranty service.
Disposal:
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. T o prevent possible harmto the environment or human health
fromuncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse
of material resources. T o return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They can take this product
for environmental safe recycling.
T ools
Needed
ELECTRIC
ASSEMBLY INSTRUCTIONS
Com ponent Checklist
A(x1)
telescopic crossbar
B (x1)
sync rod
C(x1)
shelf
D(x2)
foot
E (x2)
side bracket H(x1)
leg
F (x2)
hook
S- A(x16) S- B (x10)
S- D(x1) S- E (x3)
Allenkey cable clip
1
Assem blingtheFram e
·Loosen the two screws using the Allen key.
·Adjust the frame length to suit the desktop.
·Retighten all screws.
·Attach the telescopic crossbar to the legs as shown
using the screws identified in the illustration.
I
G (x1)
control unit
·Tighten all screws with a proper screwdriver.
I (x1)
leg
J (x1)
adapter
S- C(x2)
S- F (x6)
rubber pad
2
·Attach the two side brackets to both ends of the frame
using the four screws and tighten all screws with an Allen key.
A
3
S- A
·With the frame upside down, place the feet on the legs as shown.
·Insert the screws as shown and fixthemunder the desk legs.
H
InstallingtheSideBrackets
S- A
E
InstallingtheFeet
S- A
