  • Page 1 I G NI T E K 2 S E T - U P G U I D E...

  • Page 2: Table Of Contents

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 CONTENTS Chassis Information Quick Start Guide Safety Guide General Maintenance Driving Lines and Terms Tire Pressures Wheels and Tires Front Track Width Front Ride Height Caster/Camber/Toe Rear Track Width Rear Wheel Hubs Rear Axle Rear Ride Height Supplemental Seat Struts...

  • Page 3: Chassis Information

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 CHASSIS INFORMATION Chassis Model: Ignite K2 Serial Number: Chassis Color: Welded by: Assembled by: Spindle heights: Bodywork Style: Evo Stilo Stilo Bodywork Color: Black Blue Yellow Pearl Rear Bumper: Tris None Steering Shaft: 17”...

  • Page 4: Quick Start Guide

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 QUICK START GUIDE Hoosier R80 Hoosier R60B Tire Pressure 14-20 PSI 12 – 14 PSI Wheels TruSpeed 130mm/212mm TruSpeed 130mm/212mm Front Width 25mm inside wheel 20mm inside wheel Front Torsion Bar Front Ride Height neutral neutral...

  • Page 5: Safety Guide

    KART MODIFICATIONS Under no circumstances does Margay Racing authorize or recommend modifications of any type to the chassis or components we manufacture and distribute. This includes alternative methods of component assembly, chassis manufacturing, etc.

  • Page 6: General Maintenance

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 GENERAL MAINTANENCE Below are a list of items to keep your new kart running at maximum efficiency: FILL DRAIN Ensure front and rear sprockets are aligned for a smooth chain. Lube chain before every Change oil after Day 1 break-in (30 min), run with chain lube or a 90w gear oil.
  • Page 7 IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 GENERAL MAINTANENCE (CONT) At the completion of each days racing Remove the float bowl on the carburetor and sessions, be sure to pull the carburetor drain break clean the brass jets that are screwed plug screw to empty the float bowl.

  • Page 8: Driving Lines And Terms

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 DRIVING LINE AND TERMS Oversteer is when the rear of the kart Understeer is when the front slides more slides more than the front, causing the than the rear, causing the kart to ‘push’ driver to counter steer to avoid spinning.

  • Page 9: Tire Pressures

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 TIRE PRESSURES Tire pressure starting points (set before going on track):  Hoosier R55: 10 – 12 PSI  Hoosier R60B: 12 – 14 PSI  Hoosier R80: 14 - 20 PSI Setting tire pressures for a cold tires is done so the tire can reach maximum temperature near the last 25% of the race.

  • Page 10: Wheels And Tires

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 WHEELS AND TIRES The relationship between wheels and tires is an important one, both for handling and overall performance. The recommended wheels for the Ignite K2 are:  #771311 TruSpeed 130mm DSM front wheel / for 4.5 front tires ...

  • Page 11: Front Track Width

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 FRONT TRACK WIDTH Front track width can be adjusted by moving spacers to the inside or outside of the wheel. Adjusting front track width can adjust the front responsiveness on turn-in and also the resulting inside rear tire lift.

  • Page 12: Front Ride Height

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 FRONT RIDE HEIGHT Front ride height can be adjusted for two reasons: to adjust cross weight percentages and to adjust front end responsiveness. A standard Ignite K2 has three adjustment shims on top of the spindle, and three adjustment shims on the bottom of the spindle.

  • Page 13: Caster/Camber/Toe

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 CASTER / CAMBER / TOE Front end geometry is crucial in creating the perfect handling kart. Caster, camber and toe can be adjusted to achieve almost any desired handling characteristic. Standard settings are: ...
  • Page 14 IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 CASTER / CAMBER / TOE (CONT) PROBLEM: The kart is hopping through the center of the corner. SOLUTION: The kart is trying to transfer more weight than the flex in the chassis will allow.
  • Page 15 IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 CASTER / CAMBER / TOE (CONT) PROBLEM: The kart is “darty” and too responsive in the front end. SOLUTION: Decrease the camber (increase the negative camber). This will reduce the contact patch and reduce front end grip levels.

  • Page 16: Rear Track Width

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 REAR TRACK WIDTH Rear track width is described as the measurement of the rear width, from the outside edge of the LR wheel to the outside edge of the RR wheel. Adjusting the rear track width helps determine the rear weight transfer of the kart.

  • Page 17: Rear Wheel Hubs

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 REAR WHEEL HUBS Rear hubs come in variable lengths, which can be used to adjust rear end stiffness and rear track width. If rear track width remains the same, and a longer hub is installed, the leverage point on the axle decreases, causing it to become stiffer and thus working the outside rear tire harder.

  • Page 18: Rear Axle

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 REAR AXLE Rear axle stiffness can be adjusted to create more or less flex in the rear end. Ultimately, the rule of thumb is: softer axles create less grip and stiffer axles create more grip.

  • Page 19: Rear Ride Height

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 REAR RIDE HEIGHT Rear ride height can be adjusted to raise or lower the center of gravity toward the rear end of the kart. The Ignite K2 comes with two vertically adjustable axle positions.

  • Page 20: Supplemental Seat Struts

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 SUPPLEMENTAL SEAT STRUTS Adding additional seat struts to a kart can help a driver dictate rigidity towards the rear of the kart. Much like a torsion bar in the front, rear seat struts help direct energy towards the rear of the kart.

  • Page 21: Seat Style And Positioning

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 SEAT STYLE AND POSITIONING DRIVER HEIGHT 4’ – 4’ 8” 9.75” 19.00” 4’ 6” – 4’ 8” 9.50” 19.25” 4’ 9” – 4’ 11” 20.50” 9.25” 5’ 0” – 5’ 2” 9.00”...
  • Page 22 IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 SEAT STYLE AND POSITIONING (CONT) PROBLEM: The kart slides through the corner and oversteers on exit. SOLUTION: Although there are plenty of chassis adjustments to help solve this issue, adjusting the seat can correct the problem as well. Moving the entire seat backwards (or simply tilting the seat backwards) in 0.25”...

  • Page 23: Chassis Scaling

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 CHASSIS SCALING It is important to scale your chassis when you first purchase it, along with a few other scaling sessions throughout the year. Scaling the kart helps you determine if the kart is mathematically balanced in its neutral position.

  • Page 24: Wet Conditions

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 WET CONDITIONS CONDITIONS Track conditions play a major role in how you should set your kart up for rain. It is important to note if the track is merely damp, retaining water, or entirely submerged. Typically, the wetter the track becomes, the further you will deviate from your normal dry set-up.
  • Page 25 IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 WET CONDITIONS (CONT) TIRE PRESSURE Hoosier WET: 12-24 PSI cold. Track conditions and ambient temperature play a big part in determining the correct tire pressures for any given run. As the track gets increasingly wet, you will generally increase tire pressures to ensure the tires get to temperature.

  • Page 26: Adjusting For Understeer

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 ADJUSTING FOR UNDERSTEER Understeer can cause many reciprocating effects on chassis handling. It is important to notice where in the corner the understeer is taking place. Most often, a kart will understeer on entry, the driver will put in more steering input, and once the kart grabs become loose on exit.

  • Page 27: Adjusting For Oversteer

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 ADJUSTING FOR OVERSTEER Oversteering, or the rear end being ‘loose’, is when the rear end of the kart has less grip than the front, causing the kart to slide around or through the corner.

  • Page 28: Adjusting For Hopping

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 ADJUSTING FOR HOPPING A driver may feel the kart hop through the middle of the corner, all the way to the exit. This is usually a result of the chassis binding up through the corner. This happens when the chassis does not flex properly through the center of the kart.

  • Page 29: Adjusting For Flat Tight

    IGNITE K2 SET-UP BASELINE SET-UP INFORMATION FOR THE IGNITE K2 ADJUSTING FOR FLAT TIGHT There are different kinds of tight that a driver will need to communicate. Flat tight is when a driver cannot feel the inside rear tire pick up on the entry to a corner, and as a result, the inside rear drags along the racing surface and causes the kart to lose momentum on exit.
