- Page 1 10.1” SmartTV Ready Overhead In-Vehicle Entertainment System With Built-In DVD Player / HDMI for SmartTV connectivity (Optional) / USB and A/V Inputs OWNER'S MANUAL ®...
-
Page 2: Table Of Contents
TABLE OF CONTENTS FCC Statement ...........................................3 Important Notice ..........................................4 Warnings ..............................................4 Congratulations ..........................................5 Safety Precaution ..........................................5 Features ...............................................5 Controls and indicators diagram(front view) .................................6 Controls and indicators diagram(side view) ................................7 Remote Control Operation ......................................8 Remote Control Functions ......................................9 Turning the unit on or off ......................................13 Source menu ...........................................14 System Menu Setting and Adjustments ................................16... -
Page 3: Fcc Statement
FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 4: Important Notice
Important Notice Installation of overhead products requires careful planning and preparation. Be extremely careful when working on a vehicle with side curtain air bags. Do not route wires near any portion of the side curtain air bag assemblies. This includes any anchor points in A, B, C or D pillars of the vehicle. Routing wires in these areas or running wires by the side curtain air bags can prevent the side curtain air bag from fully deploying which can result in personal injury to vehicle occupants. -
Page 5: Congratulations
Congratulations FEATURES • 10.1” TFT(Thin Film Transistor) Active Matrix LCD (Liquid Crystal Congratulations on your purchase of this In-Vehicle Entertainment System . This system has been designed to give you and your family many Display) Monitor years of video entertainment in the mobile environment. Please read the •... -
Page 6: Controls And Indicators Diagram(Front View)
CONTROLS AND INDICATORS DIAGRAM (FRONT VIEW) 4. HOME/MENU Select Button This button is used to display and select options on the system menu. Press and hold for 3 seconds to access the System Menu. 5. UP/NEXT( ) Button Short press to select the source mode and system menu pages. Long press to select next chapter or track during play the DVD. -
Page 7: Controls And Indicators Diagram(Side View)
CONTROLS AND INDICATORS DIAGRAM (SIDE VIEWS) 1. DVD DISC INSERTION SLOT For loading and removing discs. When a disc is inserted, the unit will automatically turn ON and switch to DVD source. Insert a disc with label side facing up. Note: The disc slot indicator is red when a disc is inserted and green when the disc slot is empty. -
Page 8: Remote Control Operation
REMOTE CONTROL OPERATION Battery Replacement 1. Remove the battery cover. 2. Insert two AAA batteries into the battery holder. Be sure to observe the correct polarity. 3. Reinstall the battery cover back into the Remote Control until it locks in place. -
Page 9: Remote Control Functions
REMOTE CONTROL FUNCTIONS * Function control is available on the unit and the Remote Control. ** Function not available in this model. 1. POWER* Press this button to turn the unit ON and OFF. 2. SOURCE* Press to display the Source OSD for DVD, USB, AV, HDMI 1 and HDMI 2. 3. - Page 10 10. DISPLAY Press once to display current disc information of Title, Chapter & Time. Press again to display Subtitle, Audio & Angle while the disc is playing. DVD TT 0/12 CH 0/25 00:00:00 ..11. PLAY (u)* Press to activate the play mode while a disc is loaded into the disc compartment. 12.
- Page 11 19. SUBTITLE Press to display and select the subtitle language in DVD mode. Each time this button is pressed, the subtitle language changes. Pressing the button will also turn the subtitles off. Note: The type and number of subtitle languages vary from disc to disc. 20.
- Page 12 27. STOP ( n )* Press to stop playback. (Playback will resume from the point it is stopped). Press twice to stop playback fully. (Playback will resume from the beginning of the disc). Note: For MP3 or photo mode, press twice to return to Audio/Photo/Video option menu. 28.
-
Page 13: Turning The Unit On Or Off
TURNING THE UNIT ON OR OFF 1. Push in the Screen Release button to unlock the LCD screen. The screen will drop down slightly. 2. Pivot the screen downward until a comfortable viewing angle is reached. The hinge friction will hold the screen in position while the system is in use. 3. -
Page 14: Source Menu
SOURCE MENU The System is capable of accessing five source inputs. To select or change a source, press the source button on the front panel or the Source button on the remote control. The source OSD will appear on the screen as shown in the figure below. Use the + or - cursor buttons on the front panel or the p or q cursor buttons on the remote control to highlight a source. - Page 15 HDMI 1 & HDMI 2 These Source inputs allow the user to enjoy high-definition digital images, video and high-quality sound by connecting an HDMI Device such as a Blu-ray player, Smartphone or Tablet. You can also use this input to connect a Smart TV Stick such as a ROKU, Amazon Fire TV or Chromecast device.
-
Page 16: System Menu Setting And Adjustments
SYSTEM MENU SETTINGS AND ADJUSTMENTS The Setup Menu contains features and options that let you customize your DVD player. For example, you can set a language for the on-screen display or set up PARENTAL controls to control DVD playback for children. Using the System Menu Press the System Menu button on the remote. - Page 17 PICTURE CONTROL The PICTURE setup functions allows the user to select and set the picture control function. BRIGHTNESS CONTRAST PICTURE BRIGHTNESS, CONTRAST, COLOR adjustments range from 0 to 32. COLOR AUDIO TINT TINT adjustments range from -16 to 16. SYSTEM PLAYER SMART STREAM MOVE...
- Page 18 SYSTEM SYSTEM PLAYER PLAYER SMART STREAM SMART STREAM MOVE ADJUST EXIT MOVE ADJUST EXIT MENU MENU DEFAULT DVD The DEFAULT DVD allows the user to set the system default source to DVD ON or OFF. LANGUAGE TV SYSTEM ENGLISH NTSC DEFAULT DVD SCREEN SAVER PICTURE...
- Page 19 SYSTEM BRIGHTNESS FM MODULATION PLAYER CONTRAST FMM CHANNEL PICTURE PICTURE COLOR SMART STREAM MOVE ADJUST MENU EXIT AUDIO AUDIO TINT RESET SYSTEM SYSTEM The RESET functions allows all settings options to be reset to factory PLAYER PLAYER settings. LANGUAGE ENGLISH SMART STREAM SMART STREAM MOVE...
- Page 20 PICTURE PICTURE ASPECT RATIO 16:9 ASPECT RATIO 16:9 LAST MEMORY LAST MEMORY PLAYER PLAYER AUDIO AUDIO PASSWORD SETUP PASSWORD SETUP AUDIO LANGUAGE AUDIO LANGUAGE ENGLISH ENGLISH SYSTEM RATING SYSTEM RATING ADULT ADULT SMART STREAM SMART STREAM MOVE ADJUST EXIT MENU MOVE ADJUST MENU...
- Page 21 SYSTEM SYSTEM RATING ADULT LAST MEMORY PLAYER PLAYER AUDIO LANGUAGE ENGLISH SMART STREAM SMART STREAM MOVE ADJUST EXIT MOVE ADJUST EXIT MENU MENU NOTE: The 3308 password is always accepted in the setup menu even after a new password has been entered. To avoid the possibility of others using the default password to set the parental level and change the password, TV SYSTEM NTSC...
- Page 22 SYSTEM SYSTEM RATING ADULT RATING ADULT AUDIO AUDIO PASSWORD SETUP PASSWORD SETUP PLAYER LAST MEMORY PLAYER LAST MEMORY SYSTEM SYSTEM RATING ADULT RATING ADULT AUDIO LANGUAGE ENGLISH AUDIO LANGUAGE ENGLISH LAST MEMORY LAST MEMORY PLAYER PLAYER SMART STREAM SMART STREAM MOVE ADJUST EXIT...
- Page 23 PICTURE PICTURE AUDIO AUDIO SYSTEM SYSTEM PLAYER PLAYER To choose an FM frequency for audio playback through your vehicle’s SMART STREAM SMART STREAM MOVE SELECT EXIT MOVE SELECT EXIT MENU MENU radio: Use the p q t or u cursor buttons to select a frequency not used by a radio station in the area.
-
Page 24: Playing Dvds And Audio Discs
PLAYING DVD AND AUDIO DISCS Playing DVDs When a disc is loaded. Press the DISPLAY button on the remote control to display the status banner. The status banner includes the disc title, chapter audio language , subtitle & angle. Title Selection: Some DVDs contain more than one title (e.g. sitcoms, collections, etc.) Press the numeric (0-9) buttons to initiate a change of chapter title selection. -
Page 25: Playing Mp3 Discs
The USB port can play AUDIO, PHOTO, VIDEO . The following formats are supported: Audio • • • Photo AUDIO • JPEG Enjoy your audio in this mode. • ex: mp3, wma, wav. . . Video* • AVI (MPEG4-DIVX (DIVX 4.0/5.0), MPEG4-XVID - (720 x 576 max resolution) •... -
Page 26: Dvd Basics
DVD BASICS To get the optimum use out of the DVD Player, please read the following: DVD Region Code The DVD player is preset to a region code at the factory depending on where the DVD player is sold. A DVD from a different region cannot be played in this unit and the unit will display "WRONG REGION”. -
Page 27: Hdmi Devices
NOTE: Some Samsung smartphones may require an additional 5-pin HDMI Device micro USB to 11- pin micro USB adapter in addition to the multimedia HDMI1 (HDMI Input located on the side of the unit) adapter. This input can be used for devices with HDMI output ports (such as smartphones, tablets, HDMI devices) and may require the For other smartphone makes and models check with your device purchase of an HDMI cable and HDMI adapter which is available from... -
Page 28: Usb Input
USB INPUTS USB1 Port (User Accessible) The USB port provides two functions: Media port for USB thumb drives: charging: • The USB port will not charge a portable device when the unit is turned OFF. • The USB port will charge a portable device in the following modes: •... -
Page 29: Troubleshooting
TROUBLESHOOTING Problem Solution IR remote inoperative • Verify that the battery in the remote is fresh. • Verify that the remote sensor eye is not obstructed. • Verify the proper mode (DVD/TV) button is selected on the remote control. Disc won't play • Insert a disc with the label side facing upwards. -
Page 30: Specifications
SPECIFCAITONS Type TFT Active Matrix LCD Resolution 1024 (RGB) (X3) x 600 Pixels 1,843,200 Operation Temperature 32 ~ 131º F (0 ~ 55º C) Storage Temperature -4 ~ 158º F (-20 ~ 70º C) Backlit life 20,000 Hours Video Display System NTSC / PAL / AUTO Video Output 1.0Vp-p @ 75 ohms... -
Page 31: Warranty
Applies to VOXX Mobile Video Products VOXX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that, should this product or any part thereof (except game controllers), under normal use and conditions, be proven defective in material or workmanship within 36 months from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company’s option) without charge for parts and... - Page 32 © 2020 VOXX ELECTRONICS CORP., 2351 J. Lawson BLVD. Orlando FL 32824 700091...
