- Page 1 SPECIFICATION Product Name: Indoor Air Quality Controller Item No.: AM6108B Version: V0.3 Date: 2019-10-12 Writer Audit Approved Mei Yang...
- Page 2 Revision Version Content Reviser Date V0.1 2019-5-10 First edition Mei Yang V0.2 Add product communication protocol 2019-8-13 Mei Yang 1:Standby current change to 90mA V0.3 2: Add the WIFI connection mode 2019-10-12 Mei Yang 3:Update the UI key icon www.gassensor.com.cn 1/11...
- Page 3 Industrial ventilation system Description AM6108B is an indoor air quality controller with screen provides customers with visual indoor air quality readings, such as PM2.5, CO2, temperature, humidity, etc.; It can control the HVAC system directly. For example: Adjust the fan speed, control air supply / exhaust， set mode and other functions. It is widely used in residential, commercial and industrial applications, and can effectively improve air quality and create a healthy, comfortable, efficient, environmentally friendly, energy-saving living and working environment.
-
Page 4: Specifications
Specifications ：NDIR Working principle PM：Laser scattering principle PM2.5：0~1000μg/m³ ：0~5000ppm Measurement range Temperature：-10℃~50℃ Humidity：0%~95%RH ≤ 100μg/m³：±10μg/m³ PM2.5 Measurement accuracy > 100μg/m³：±10% reading （Reference Instrument TSI 8530，25±2℃，50±10%RH） Measurement accuracy ±（50ppm+5% of reading）@ 0~50℃ Temperature Measurement ±1℃ accuracy Humidity Measurement accuracy ±8%RH PM Response time T90 ≤8s Response time T90 <120s... - Page 5 Dimensions and Interface Definition 1. Dimensions (Unit ：mm, tolerance： ±0.2 mm) 2. Pin definition Description Communication port（RS485_TA） Communication port（RS485_TB） +12V Power input（+12V） Power input（GND） www.gassensor.com.cn 4/11...
- Page 6 UI Interface Description Parameter Range corresponding to color LIST Level Range Color Good 0~75 PM2.5 Just so so 75~115 (μg/m³) ≥115 Good 0~600 Just so so 600~1000 (ppm) ≥1000 www.gassensor.com.cn 5/11...
- Page 7 Controlling Instructions 1 Working Mode Manual Mode: The user can adjusts the fan speed switch manually (high, middle and low);； Intelligent Mode: According to the setting value of PM2.5 or CO2, it can switch the fan speed automatically. Mute Mode: Operation at low speed;...
- Page 8 ①Without CO2 sensor: the controller automatically adjusts the fan speed according to the air quality (PM2.5 4 Intelligent Mode： concentration); when the PM2.5 concentration is higher than the set value of 115μg / m³, the fan runs at high speed; when the PM2.5 concentration is between 75-114μg / m³, the fan runs at medium speed; when the PM2.5 ②With CO2 sensor: When the CO2 concentration is higher than the set value of 1000ppm, fan will run at high concentration is lower than the set value of 75 μg / m³, and the fan runs at low speed.
-
Page 9: Installation Instructions
Installation Instructions Step 1: Fix the wall mounted bracket with screws on the 86 box which in the embedded wall, as shown below Step 2: Connecting Cable, connect the corresponding cable to the controller's RS485 interface according to the interface definition, as shown below: Step 3: Match the two holes in the controller with the hooks in the wall mount bracket and slide the controller down to ensure that the controller is tightly locked with the bracket. -
Page 10: Precautions For Use
Precautions for use ▪ Do not place the controller in an environment where the ambient temperature is too high (above 60 ° C) or too low (below -20 ° C). ▪ Keep it out of reach of children as much as possible to prevent injury from collision and fall. ▪... -
Page 11: Communication Protocol
Communication Protocol 1. General Statement 1） The AM6108 controller is connected to the HVAC controller through 485, it sends a command to the HVAC controller to achieve the AM6108 control the HVAC system by communication protocol. Baud rate：9600, Data Bits: 8, Stop Bits: 1, Parity: No； 2）... - Page 12 Reserved DF17- DF18 Reserved DF19- DF20 CheckSum After-Sales Services and Consultancy Cubic Sensor and Instrument Co.,Ltd Tel: +86 (0)27 81628827 Fax: +86 (0)27 81628821 Add: Fenghuang No.3 Road, Fenghuang Industrial Park, Eastlake Hi-tech Development Zone, Wuhan 430205, China E-mail: info@gassensor.com.cn www.gassensor.com.cn...
