- Page 1 Envy JVC Setup Guide www.madvrenvy.com Revision 1.01 madVR Envy – JVC Setup Guide Copyright © madVR Labs, LLC. All rights reserved.
- Page 2 Dynamic Tone Mapping for HDR content. But since the Envy will now be handling this for you, and doing a much better job, these features will simply not be used.
- Page 3 JVC Configuration The following steps are recommended to best configure the JVC for use with the Envy: 1. Set the Input Level to “16-235 (Video)” as shown below. Selecting “Auto” should also work, as it will normally select video levels. However, there have been cases where the JVC selects the wrong levels when set to Auto.
- Page 4 Envy. This small increase in the Dark Level setting can improve shadow detail. If you are using calibration software to calibrate the JVC through the Envy, there is no need to create a Custom Gamma, as you can pick your own target Gamma curve in the calibration software and use a standard Gamma such as 2.2 or 2.4 in step 1.
- Page 5 Generally, the recommended Gamma Setting for use with Envy HDR dynamic tone mapping is 2.4, when not performing a 3D LUT. Important: If you set the Gamma to something other than 2.4, be sure to change the Transfer Function setting in the Envy’s Display Calibration menu to match the Gamma setting selected...
- Page 6 “HDR10 Auto Select” menu option, the available Picture Modes are shown. In this case, SDR- BT2020, which we created in the preceding steps, is selected as the one to be used for HDR content. madVR Envy – JVC Setup Guide Copyright © madVR Labs, LLC. All rights reserved.
- Page 7 B. Aspect should be set to Auto. Regardless of the Aspect Ratio of the Screen or content, the Envy can be configured to optimize the picture size with the use of its Profile system, along with its Black Bar Detection and Management options. For more information see the Introduction to Profiles guide and the Scope Screen Setup guide at www.madvrenvy.com.
- Page 8 10. Under the Motion Control section, we recommend Low Latency Off, Clear Motion Drive on Low, and Motion Enhance Off. These settings, however, should be set to taste by the user. madVR Envy – JVC Setup Guide Copyright © madVR Labs, LLC. All rights reserved.
- Page 9 This concludes the setup of the JVC projector. Be sure to review the Envy Quick Start Guide as well for how to set up the Envy in general. madVR Envy – JVC Setup Guide Copyright © madVR Labs, LLC. All rights reserved.
-
Page 10: Appendix A - Envy Settings
Envy Display Calibration and Display Configuration menus as well. Display Calibration menu: 1. If you are not using a 3D LUT, you must set the Transfer Function in this Envy menu to match the Gamma value you set in the JVC in step 4. - Page 11 The Envy uses the peak luminance measure to render dark scenes according to director's intent and to render bright scenes accurately as well. Therefore, the most critical HDR setting in the Envy is the peak luminance. The best way to determine your peak luminance is to display a 100% white pattern and measure it using 3 party calibration software or a handheld lux meter.
- Page 12 “sanity check” to help ensure everything is set up optimally: A. Play any 4K HDR movie (except Gemini Man or Billy Lynn). Check the Envy Incoming Signal Menu (press OK on the Envy remote when no Envy menu is active) and make sure that the “Framerate”...
