Rane 1010 Series Manual

Halogen Wizard
Restaurant Configuration Template
This walk-through will help you implement this template, designed specifically for the Rane Terminal
1010x and configured using Halogen software 7.0.
Visit ranecommercial.com
Features
•
Master control from reception with paging to one or more zones
•
Source selection and volume control for dining, bar, and garden
•
Local auxiliary input for guests in private room
•
Wireless control via smartphone/tablet with password access
•
Priority for when managers turn up the TV volume to override background music
•
Mute all logic relay for integration with alarm and safety systems
Layout Example
This configuration will suit small to large restaurants and environments that require background
music and acoustic control for each zone. This setup utilizes a touchscreen paging feature for the
Reception area to page customers waiting for their tables, a Private Room area with a priority input
for personal music content, and a Web remote for easy control from a smartphone or mobile device.
To illustrate a possible layout, see below:
WC
Terrace
Tip: You can rename these and/or add more sources and zones using Halogen software.
to download Halogen and learn how to customize your template.
Garden
Dining Room
Private Room
Sources = 5
Reception
(3) CD/Media Players
(1) Microphone
BAR
(1) TV
Zones = 8
1. Reception
2. Bar with TV/Karaoke
3. Dining Room
Kitchen
4. Private Room
5. Garden
6. Terrace
7. Kitchen
8. Restroom (WC)
