Summary of Contents for Vortex RAZOR AMG UH-1
- Page 2 The incredible features of the Razor UH-1 ® ™ ™ matched only by its tough, tenacious performance. Absolute zero image distortion and an impressive sight picture with un- obstructed view ensure rapid, instinctual target acquisition. Shockproof Housing The shatterproof XR plus fully multi-coated windows and holo- graphic elements are incredibly durable and promote optimal light transmission.
- Page 3 Operating the UH-1 ™ Powering Up To turn the UH-1 on press either button. It is set to the middle illumination setting. Use the plus and minus buttons to switch brightness levels. There are 15 brightness settings for extreme low light to daytime bright. Power On: Press either To turn off, simultaneously press both buttons.
- Page 4 Windage and Elevation Adjustments Use a coin or other flat head item to turn the knobs to adjust for point of aim. For both adjustment knobs, one click will change the point of aim approximately ½ MOA when zeroing. One click yields ½ MOA of adjustments ¹/ (3.18mm) at 25-yds (23.75 meters) 8-inch...
- Page 5 Using the EBR-CQB Holographic Reticle The EBR-CQB is designed to take full advantage of both the Use the center dot for zeroing your rifle and as the point of aim center dot and the bottom triangle for targeting. for targets at 25 to 400 yards/meters. The bottom triangle will be your point of impact for close quar- ters distances of 10 yards/meters or less.
- Page 6 Trajectory and Ballistics Examples This example is based on M855 ammunition. This example is based on M855 ammunition.
-
Page 7: Battery Information
Battery Information One CR123A battery powers the UH-1. Charging the Battery The UH-1 also runs on the While charging a LFP 123A battery in the sight, the reticle will LFP123A, the high-end rechargeable version of the CR123A. Charge pulse back and forth between dim/bright. The actual brightness the battery using the Micro USB port and it will recharge while in the values for the pulsing will be one setting above the “on”... -
Page 8: Laser Safety
When cleaning the lenses, be sure to use products specifically designed Very Important Person. for use on coated optical lenses such as the Vortex Lens Pen, the Fog Free Cleaning kits, or the included microfiber cloth. Rest assured that in the event your optic becomes damaged or •... - Page 9 rd_RZR-AMG-UH-1_2016_V1...
