Summary of Contents for Geyer Fill-Master 5000
- Page 2 Packaging Enterprises Inc. Filler Machine Division 12N. Penn Ave., Rockledge, PA 19046 Telephone (215) 379-1234: Fax (215) 379-1166 Web site: www.packagingenterprises.com Parts Email: parts@packagingenterprises.com Machine Sales Email: fillers@packagingenterprises.com...
-
Page 3: Table Of Contents
Table of Contents Table of Contents Page 2 Inspection upon Arrival Page 3 Locating the Machine Page 3 Leveling the Machine Page 3 Assembling the Machine Page 3 Air Connections Page 3 Machine Speed Page 4 Altering the Machine Speed Page 4 Continuous Mode Page 5... -
Page 4: Inspection Upon Arrival
30 days, in case machine needs to be returned for repair or exchange. B. LOCATING THE MACHINE Your GEYER filler should be set up in a location which will allow enough space around the machine for the operator and provide easy access for maintenance purposes. -
Page 5: Machine Speed
F. MACHINE SPEED The Fillmaster has been designed to operate on demand. In other words, a fill cycle is initiated when the operator presses the foot pedal. The machine will go through and complete one fill cycle and then automatically shut off until the foot pedal is pressed again. -
Page 6: Continuous Mode
H. CONTINUOUS MODE Note: Disregard the following if your machine was supplied with the optional single cycle / continuous switch. The machine has been sent to you equipped with a foot pedal. Once the foot pedal is depressed, the machine will complete one cycle and then shut off, until the foot pedal is depressed again. -
Page 7: Startup
I. ADJUSTMENT FOR QUANTITY OF FILL - CONTINUED Each size cylinder has a particular fill "range". The smaller the diameter of cylinder the smaller the range of fill. In general, the best accuracy of fill achieved when the cylinder has a small diameter and a long piston stroke is taken. -
Page 8: Safety Procedures
Safety Procedures Please make sure that all operators use extreme caution when operating, cleaning, and repairing the filling machine. Make sure that all operators and maintenance personnel read and understand all warning stickers that have been placed on your machine. NEVER REMOVE THESE STICKERS!!! GENERAL SAFETY GUIDELINES: Never operate machine with out all guarding securely in place. - Page 9 Machine Cleaning / Maintenance These Procedures should be performed at least twice a week to keep the machine in top running order and to maintain cleanliness. (Food Plants must perform this cleaning procedure once a day, after run is complete, to prevent growth of bacteria.) If there are any questions on part names in this section, refer to the drawing on page 7 and photo on page 9.
-
Page 10: Machine Cleaning / Maintenance
Machine Cleaning / Maintenance – continued Start by screwing the piston on the air cylinder rod. Apply some lubricant on the piston and just at the Open end of the cylinder (see section "Lubricating Your Machine" page 11) Slide the cylinder over the piston. (Don’t cover the opening in front or you won't be able to push it on the because, the air needs to escape) Lubricate the valve rotor(pallet) and valve and then reassemble. -
Page 11: Lubricating Your Machine
Lubricating Your Machine After cleaning the product contact parts and prior to reassembling the machine, make sure to apply a small amount of Sana-Lube #2000 or other food grade lubricant to the piston and valve rotor (Pallet). Make certain to coat the entire part, but do not over apply it. -
Page 12: How It Works
How it works! Piston takes an intake stroke drawing product from the hopper through a three way valve. The valve Rotor (pallet) shifts position, and the piston moves the product from the cylinder to the filling nozzle and into the container. III. -
Page 15: Fillmaster 5000 Machine Parts List
Fillmaster 5000 filling machine parts list Item Number Description Size Material Unit Diagram - Page 1 Three Way Valve Stainless Steel Pallet (Valve Roter) Chrome Plated Pallet Stainless Steel Pallet O-Rings (not visible) Pallet Crank Stainless Steel Pallet Crank Pin Stainless Steel Pallet Air Cylinder Stainless Steel... - Page 16 Fillmaster 5000 filling machine parts list Item Number Description Size Material Unit Pallet Air Valve 1/4" Tube Main air valve Air Supply Tube 3/8" Male Tube Fitting 3/8" Tube Muffler - Main Air Valve Sensor Signal Tube Male Tube fitting - Sensor Line Main Air Cylinder Tube Tube Tee with Reducer 3/8"...
