- Page 1 5137415/02 INSTALLER GUIDE BBU Wall fascia. Baxi Bermuda BBU15 HE For use with the Boiler. This guide must be read in conjunction with guide supplied with the firefront. Important: Please keep your guide in a safe place for future reference.
- Page 2 Warning: Any person who does any unauthorised act in relation to a copyright work may be liable to criminal prosecution and civil claims for damages. Valor Fires, Erdington, Birmingham B24 9QP. www.firesandstoves.co.uk Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication.
-
Page 3: Table Of Contents
INSTALLER GUIDE CONTENTS Section Heading Page 1. IMAGES 2. HANDLING AND UNPACKING 3. PACK CONTENTS 4. FITTING THE WALL FASCIA Where can you fit the wall fascia? What opening sizes is the wall fascia designed for? Do I need any tools? Fitting the lower wall bracket. -
Page 4: Images
INSTALLER GUIDE 1. IMAGES Shown with wall fascia recessed into opening and Innova firefront installed Shown with wall fascia forward of opening and Innova firefront installed © Baxi Heating U.K. Limited 2010. Page 4... -
Page 5: Handling And Unpacking
INSTALLER GUIDE 2. HANDLING AND UNPACKING Before continuing any further with the installation of this wall fascia please read the following: Important instructions. The approximate lifting weights (kg) of the wall fascia parts are listed below: Description Weight Rear wall plate 1.83 Spacer assembly 2.65... - Page 6 INSTALLER GUIDE 3. PACK CONTENTS Contents Quantity (Illustrations are not to scale) Rear Panel Spacer assembly M4 x 6mm head screw Woodscrew Wall plug © Baxi Heating U.K. Limited 2010. Page 6...
-
Page 7: Fitting The Wall Fascia
INSTALLER GUIDE 4. FITTING THE WALL FASCIA Where can you fit the wall fascia? The wall fascia is intended for use with the Baxi Bermuda BBU15 HE Boiler and where the boiler is in an elevated opening. Please note that the guide supplied with the firefront may not recommend fitting into elevated openings. -
Page 8: Fitting The Upper Wall Bracket
INSTALLER GUIDE Fitting the upper wall bracket. The upper wall bracket has four holes in its rear and a raised ‘U’ shaped edge at the top. The distance from the top surface of the lower wall bracket to the centres of the fixing holes is 650mm. Measure and mark this distance on the wall. -
Page 9: Fitting The Inner Frame Assembly
INSTALLER GUIDE Fitting the inner frame assembly. Method 1 of 2 - Fitting the Inner frame forward of the builders opening (See figure 4). 1. Insert the rear of the inner frame assembly into the opening in the rear panel. 2. -
Page 10: Fitting The Boiler Control
INSTALLER GUIDE Fitting the boiler control. Note: The boiler control is supplied with the firefront and is not part of this wall fascia. 1. Insert the boiler control lead through the opening in the spacer frame, then ensuring that the display is at the top, gently push the boiler control into place. -
Page 11: Removal Of The Firefront For Boiler Servicing
INSTALLER GUIDE 5. REMOVAL OF THE FIREFRONT FOR BOILER SERVICING. Removing the firefront. 1. Isolate the electric supply to the firefront. 2. Unscrew and remove the six M4 x 6mm screws that secure the firefront (See figure 3. Gently pull the firefront forward, ensuring that the mains cable is not trapped or damaged. - Page 12 © Baxi Heating U.K. Limited 2010.
