Summary of Contents for Newworld NWCFD418
- Page 2 Welcome Dear users, this manual contains the product’s basic knowledge, how to use it, fault diagnosis and basic troubleshooting methods. In order to better understand and use this product, please take good care of this manual and read it carefully. Help and Guidance We’re here to help you get the most from your Refrigerator.
-
Page 3: Table Of Contents
Contents Safety Instructions Product Features III. Preparations for Use Functions Instructions For Food Storage Maintenance and Cleaning VII. Troubleshooting VIII. Certifications Product Support Guarantee * Varying with Different Products... -
Page 4: Safety Instructions
I. SAFETY INSTRUCTIONS WARNING: It is hazardous for anyone other than authorised service personnel to carry out servicing or repairs which involves the removal of covers. To avoid the risk of an electric shock, do not attempt to repair this appliance yourself. WARNING: Risk of fire / flammable materials. - Page 5 unless they are recommended by the manufacturer. • Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 6 Electrical Supply Connection • Connect the appliance to the electrical supply (220-240 V ~ 50 Hz) with the plug and lead, which are fitted. • Connections to the mains supply should be in accordance with local regulations. • DO NOT use plug adapter. •...
- Page 7 Climate Range The information about the climate range of the appliance is provided on the rated plate. It indicates at which ambient temperature (that is, the room temperature in which the appliance is working) the operation of the appliance is optimal (proper). Climate range Permissible ambient temperature from +10°C to +32°C...
-
Page 8: Product Features
II. Product Features This is a side-by-side inverter fridge-freezer is equipped with electronic controls. Its top compartment for fresh food storage, such as fruits, vegetables, eggs, milk, cooked foods, etc.; and its bottom freezer compartment where fish, meat, etc. can be frozen for long-term storage. - Page 9 Refrigerator Diagram Note: Due to technological innovation, the product descriptions in this manual may not be completely consistent with your refrigerator. Details are in accordance with the real product. 1 Light 2 Egg Tray 3 Bottle Rack 4 Refrigerator Glass Shelf 5 Salad Crisper 6 Upper Freezer Drawer 7 Freezer Room Glass Shelf...
-
Page 10: Preparations For Use
III. Preparations for use Installation location: 1. Ventilation condition When installing your refrigerator, ensure it is in a well ventilated location. Do not install the refrigerator near any heat source such as a cooker. Avoid locating the refrigerator in direct sunlight, this will ensure you reduce the energy consumption of the appliance. Do not locate the refrigerator in a damp place, this will prevent the refrigerator from rusting and leaking electricity. - Page 11 3. Level ground Place the refrigerator on a solid and flat ground (floor) to keep it stable, or else it will give rise to vibration and noise. Unobstructed ventilation shall be maintained around the appliance or in an embedded structure. Preparations for use 1.
-
Page 12: Functions
IV. Functions The display panel is designed on the fridge door, illustrated as the figures below: Function Setting When the refrigerator system is connected to the power supply for the first time, all icons on the display panel illuminate for 2 seconds, and the system will run in the Smart Mode by default. - Page 13 2. Freezer temperature setting Press the Temp. Zone key to select the Freezer zone until the corresponding icon flickers, then press the Temp. key to set the temperature as desire. Press the OK key or wait for 5 seconds to validate the setting. The freezer temperature setting cycles are as following: - 18 >...
- Page 14 5. Fast Freeze When the Fast Freeze function is enabled, the freezer temperature will be controlled at -32ºC automatically, and after 26 hours of running, the Fast Freeze function stops. Cooling down the freezer temperature in a rapid manner is beneficial to prevent loss of food nutrition and the preservation of foods freshness.
- Page 15 7. Child Lock (For the product of the PCM plate door only) - When the Child Lock function is enabled, the temperature and function are unable to be changed. - In case of no key operation within 3 minutes, the Child Lock function will be enabled automatically.
-
Page 16: Instructions For Food Storage
V. Instructions for food storage Precautions for use • The appliance might not operate consistently (if there is a possibility of defrosting or temperature becoming too warm in the frozen food compartment) when running for an extended period of time below the cold limit of the temperature range for which the refrigerating appliance is designed •... - Page 17 evaporation. Keep fresh fruits and vegetables on one section, this will help to prevent taint of odor in other sections of the refrigerator. Do not over crowd the refrigerator. Keep enough space between foods because if foods are too close, the cold air flow will be blocked, thus affecting the refrigeration effect. Do not store excessive or overweight foods, to avoid the shelf from being crushed.
- Page 18 Moving your Fridge/Freezer • Location Do not place your refrigerator/freezer near a heat source, e.g. cooker, boiler or radiator. Avoid it from direct sunlight in out-buildings or sun lounges. • Leveling Make sure to level your refrigerator/freezer using the front leveling feet. If not level, the refrigerator/freezer door gasket and sealing performance will be affected, or it may lead to the operating failure of your refrigerator/freezer.
-
Page 19: Maintenance And Cleaning
VI. Maintenance and cleaning Before cleaning, turn off power first then unplug the appliance from the wall socket. Do not plug in or pull plug out with wet hands, because there is a risk of electric shock and injury. Do not spill water directly on the refrigerator, to avoid rust, electricity leakage and accidents. - Page 20 Safety-check after maintenance Is the power cord broken or damaged? If yes, contact your after sales service centre Is the power plug firmly inserted into the socket? Is the power plug abnormally overheated? If yes, contact your after sales service centre Note: Electric shock and fire accident may be caused in case the power cord and plug is damaged or stained by dust.
-
Page 21: Troubleshooting
VII. Trouble Shooting With regard to the following small faults, not every failure needs to be fixed by the technical service personnel; you can try to solve the problem by referring to table below. CASE INSPECTION SOLUTIONS Completely non- refrigeration •... - Page 22 Note: If the trouble shooting advise does not resolve your problem, do not attempt to dissemble or repair this appliance. Repairs carried out by an inexperienced person may cause injury or serious malfunctioning. Contact your after sales service provider. This product should be serviced by an authorised engineer with only genuine spare parts.
-
Page 23: Certifications
VIII. Certifications Electrical information This electrical appliance must be grounded. This product is equipped with a plug, which is suitable for all houses equipped with sockets meeting the current specifications. If the fitted plug is not suitable for your socket outlets, it should be cut off and carefully disposed of by a qualified electrician. -
Page 24: Product Support
IX. Product Support Declaration of conformance to product standards This appliance conforms to all relavant standards applicable to domestic appliances sold in the UK Disposal This appliance/fitting is marked A according to the European directive 2012/19/ EU on Waste Electrical - and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
