- Page 1 TDS-G200VLDB 8 IN. VARIABLE SPEED BENCH GRINDER WITH LIGHT IMPORTANT: INSTRUCTION For your own safety, read and follow all of the Safety Guidelines and Operating Instructions before operating MANUAL this product.
- Page 2 TDS-G200VLDB TABLE OF CONTENTS TABLE OF CONTENTS ....................SPECIFICATIONS ...................... SAFETY GUIDELINES ....................ELECTRICAL SAFETY ....................PACKAGE CONTENTS ....................KEY PARTS DIAGRAN....................ASSEMBLY INSTRUCTIONS..................OPERATION ......................... MAINTENANCE ......................TROUBLESHOOTING GUIDE ..................EXPLONED VIEW ......................PARTS LIST ........................WARRANTY ........................SPECIFICATIONS...
- Page 3 TDS-G200VLDB BD4603 SAFETY GUIDELINES - DEFINITIONS WARNING ICONS Your power tool and its Instruction Manual may contain “WA R N I N G I C O N S ”(a picture） symbol intended to alert you to and/or instruct you how to avoid a potentially hazardous condition).
- Page 4 TDS-G200VLDB 8. DO NOT FORCE THE TOOL to perform an 19. MAINTAIN YOUR BALANCE. DO NOT extend operation for which it was not designed. It yourself over the tool. Wear oil resistant rubber will do a safer and higher quality job by only soled shoes.
- Page 5 TDS-G200VLDB BD4603 or lay on your skin may promote absorption DO NOT remove the blotter or label on both of harmful material. Always use properly sides of the grinding wheel. Tighten the spindle fitting NIOSH/OSHA approved respiratory nut just enough to hold the grinding wheel firmly protection appropriate for the dust exposure, to the Bench Grinder.
- Page 6 TDS-G200VLDB 9. ALWAYS USE A WHEEL DRESSER TO Use a proper extension cord. Only use cords listed by Underwriters Laboratories (UL). Other RESURFACE THE FACE OF THE GRINDING extension cords can cause a drop in line voltage, WHEEL. resulting in a loss of power and overheating of tool.
- Page 7 TDS-G200VLDB BD4603 THIS ADAPTER IS PROHIBITED IN CANADA. WARNING THIS TOOL MUST BE GROUNDED WHILE IN USE FIG. A TO PROTECT THE OPERATOR FROM ELECTRIC SHOCK. IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least resistance for electric current and reduces the risk of electric shock.
- Page 8 TDS-G200VLDB Fig. C No. Description Qty. Qty. Description Grinder (not shown) Pan head screws w/ washers M5 x 10 Eyeshield assembly, left Flat Washer M6 Eyeshield assembly, right Tool rest,left Wheel dresser Tool rest,right Tool rest support, left Eyeshield knob...
- Page 9 TDS-G200VLDB BD4603 Fig. D No. Description Qty. LED Work Light Eye Shield Adjustment Knob Eye Shield Assembly Wheel Cover 8” Grinding Wheel, 60 Grit Tool Rest Tool Rest Adjustment Knobs Variable Speed Dial Water Tray On/Off Switch with Removable Key 8”...
- Page 10 TDS-G200VLDB WARNING THE MACHINE MUST NOT BE PLUGGED IN AND THE POWER SWITCH MUST BE IN THE OFF POSITION UNTIL ASSEMBLY OF THE PARTS AND ALL ADJUSTMENTS ARE COMPLETE. ASSEMBLE THE GRINDER PARTS TOOL RESTS (Figs. E and F) FIG. F Tool Rests assemblies for use with the two different wheels.
- Page 11 TDS-G200VLDB position. See Figure H. FIG. H FIG. I 3. The eye shields should be positioned over the wheels to protect the user against any sparks or debris that may be thrown during use. WARNING 4. Adjust the eye shield bracket and eye shield...
- Page 12 TDS-G200VLDB BD4603 CHANGING THE GRINDING WHEEL(Fig. K) FIG. J FIG. K DO NOT use the Wheel Dresser on the Wire Wheel. It is for trueing abrasive wheels only. Due to normal wear, both wheels will need to be 1. Adjust tool rest (A) until it is in the flat replaced occasionally.
- Page 13 TDS-G200VLDB BD4603 8. Replace the abrasive wheel, outer wheel flange and arbor hex nut. NOTE: The left hand arbor hex nut is left hand threaded and is tightened by rotating it counter-clockwise. The right hand arbor hex nut is right hand threaded and is tightened by rotating it clockwise.
- Page 14 TDS-G200VLDB MAINTENANCE OF THE BENCH GRINDER WARNING Turn the power switch “OFF” and unplug the power cord from its power source prior to any maintenance. LUBRICATION The Bench Grinder has sealed lubricated bearings in the motor housing that do not require any additional lubrication from the operator.
- Page 15 TDS-G200VLDB BD4603 WARNING TO PREVENT INJURY TO YOURSELF or damage to the Bench Grinder, turn the switch to the “OFF” position and unplug the power cord from the electrical receptacle before making any adjustments. 1. Plug power cord into electrical receptacle 1.
- Page 16 TDS-G200VLDB BD4603...
- Page 17 TDS-G200VLDB BD4603 Description Size Q’ty Phillips screw+ flat washer (white) M4x6 Coolant tray Coolant tray plate PC board Phillips screw (white) ST2.9x5 PC board cover I type hex + spring washer (white) M8x22 Hex nut Phillips screw+flat washer (white) M5x16...
- Page 18 TDS-G200VLDB Description Size Q’ty Label (logo & data) Flange Wire wheel 200x16x15.88 Lamp label I type hex Right guard cover Dome screw M5x51 Phillips screw M5x48 Phillips screw +flat washer M5x160 Left end motor cover Wave washer Ball bearing 6203...
- Page 19 TDS-G200VLDB BD4603 Description Size Q’ty Left inner guard cover Wheel 200x25x15.88 60 grit Left Fixing tool rest Left movable tool rest Lamp (40w) Flat washer (black) Hex nut (white) Phillips screw (black) M2.5x6 Hex socket set screws (black) M5x6 Flat washer (black)
- Page 20 TDS-G200VLDB BD4603 ONE-YEAR LIMITED WARRANTY Having Problems ? Give us a chance to help you before returning this product info@toolots.com Email : After the phone：(844) 866-5687...
