WR133F-M20 Wireless Router
User Manual
Version：V1.0
Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108)
Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website:www.szceres.com
Advertisement
Table of Contents
Summary of Contents for CERES WR133F-M20
- Page 1 Wireless Router Products WR133F-M20 Wireless Router User Manual Version：V1.0 Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website:www.szceres.com...
-
Page 2: Table Of Contents
Content 1 Note..............................2 1.1 Installation Precautions......................2 1.2 Precautions for Use....................... 2 2 Brief..............................4 2.1 Product Features........................4 2.2 Product Specifications......................4 2.3 Device Interface Definition....................5 2.4 LED Description........................5 2.5 Device Connection........................ 5 3 WIFI Router Local Web Login Management..................6 3.1 Physical Connection of WIFI Router And PC or Phone............6 3.2 PC and Phone Access the WEB of WIFI Router.............. -
Page 3: Note
1 Note 1.1 Installation Precautions Do not place the equipment near flammable or conductive items, high temperatures (such as direct sunlight) or in wet conditions, or on a PC chassis, and check that the surrounding appliances are stable. Check the cable for aging. Check and verify that the AC or DC input voltage is within the ... - Page 4 Unplug the power supply before cleaning the equipment. Use a soft dry cloth to clean the equipment to avoid the use of liquids or sprays. Do not connect this product to any electronic product unless it is instructed by our ...
-
Page 5: Brief
2 Brief The WR133F is a wireless router, support one wan port,two 1000M lan ports. 2.4G WI-FI rate , allows you to quickly set up a 300 Mbps can reach 300Mpbs, 5G WI-FI rate can reach 867 Mpbs wireless network or 867 Mbps wireless network, and lets your computers can access to Internet.The wireless router is compatible with IEEE802.11b/g/n/ac/an standard,have four external antenna which supports data rate up to 867 Mbps,with the characteristics of strong penetrating power and wide coverage, it provides users with more efficient data transmission protection. -
Page 6: Device Interface Definition
2.3 Device Interface Definition LAN port: connect computers and other terminal devices. WAN port: connect the operators network . 2.4 LED Description Indicator Description On: The WIFI router is power on; Power status Off: The WIFI router is Power off; On：Open at least one of 2.4G WI-FI and 5G WLAN Status WLAN... -
Page 7: Wifi Router Local Web Login Management
3 WIFI Router Local Web Login Management 3.1 Physical Connection of WIFI Router And PC or Phone a) Connect wireless devices such as mobile phones to the wireless network of the router. The default wireless network name can be viewed on the sticker on the bottom of the router. b) Connect the computer to any LAN port of the router with a network cable Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) -
Page 8: Pc And Phone Access The Web Of Wifi Router
3.2 PC and Phone Access the WEB of WIFI Router Make sure computers and WIFI router connected in # 3.1, open PC Web browser (IE, firefox, Google), copy and paste the WIFI router to access the URL：http://192.168.10.1, then pop-up WIFI router prompt login page as follows: admin，... -
Page 9: View Wifi Router Status
4 View WIFI Router Status 4.1 View WIFI Router System Status 1. Entry WIFI router web main interface,then click Router ->System state ,then we can see WIFI router System time,firmware version and Running time： Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.szceres.com... -
Page 10: View Wifi Router Wireless Information
4.2 View WIFI Router Wireless Information 1. Input WIFI router web main interface,then click Wireless -> 2G WIFI name and password or 5G WIFI name and password,then we can view WIFI mode,Channel and Bandwidth and etc： 1# Click “2G WIFI name and password “ ,View 2G WIFI information. Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506... -
Page 11: Wifi Router Internet Wan Configuration
Click “5G WIFI name and password “ ,View 5G WIFI information. 5 WIFI Router Internet WAN Configuration For the WIFI router the internet access method is use routing mode,internet wan configuration is important things.WIFI router support 3 method internet access ways:PPPoE 、 Dynamic IP、Static IP . -
Page 12: Set Wifi Router Dhcp Access Internet Method
After finshed all of the configuration,click ‘Enable’ button to finish “PPPOE”setting. 5.2 Set WIFI Router DHCP Access Internet Method Login WIFI router web main interface,then click“Internet setup” ,then Select “Dynamic IP” in mode. After finshed all of the configuration,click ‘Enable’ button to finish “DHCP”setting. 5.3 Set WIFI Router Static IP Address Access Internet Method Login WIFI router web main interface,then click “Internet setup”,then Select ‘Static IP’... -
Page 13: View Wifi Router Internet Wan Connection Status
After finshed all of the configuration,click ‘Enable’ button to finish “Static IP”setting. 5.4 View WIFI Router Internet WAN Connection Status On WIFI router web main interface select Router ->System state ,in this interface,we can check the WIFI router whether get ip,if wan connect is successful and ip address information .etc: Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) -
Page 14: Wifi Router Lan Port Configuration
6 WIFI Router LAN Port Configuration 6.1 LAN IP Address And DHCP Server Configuration 1. In WIFI router web main interface select Router-> LAN Settings,then config parameter as follows: 【 IP 】 Set local management IP address of WIFI router. The default IP address is 192.168.10.1 【mask】Set the mask of local management IP address of WIFI router 【DHCP】Click the button to enable or disable Router DHCP Server function. - Page 15 After finshed all of the configuration,click ‘confirm’ button to finish “LAN IP”setting. Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.szceres.com...
-
Page 16: Wlan Configuration
7 WLAN Configuration 7.1 Wireless 2.4G wifi configuration Login to WIFI router web main interface then click Wireless->2G WIFI name and password ,then config wireless as follows parameter: Click the button next to switch to control the on and off of WIFI. 【Wifi】Set the name of the WIFI；Check hide wifiless, then others cannot find this wifi;... -
Page 17: Wireless 5Gwifi Configuration
Wireless 5Gwifi configuration Login to WIFI router web main interface then click Wireless->5G WIFI name and password ,then config wireless as follows parameter: Click the button next to switch to control the on and off of WIFI. 【Wifi】Set the name of the WIFI；Check hide wifiless, then others cannot find this wifi; 【password】Set WIFI password 【Channel】Default is Auto,we can select a suitable channel refer to surrounding wifi environment；... -
Page 18: Config Parental Control Strategy
7.3 Config Parental Control Strategy 1. Login WIFI router web main interface,then click Parental controls-> Add,config rules “MAC” and “Limited Time”and “Repeat”: Click “Confirm” button to make configuration effect. Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.szceres.com... -
Page 19: Wifi Router Management
8 WIFI Router Management 8.1 Time Zone Config Login WIFI router web main interface,click Router -> Time Setting,in this interface,we can config “local time” and “Time zone”： Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.szceres.com... -
Page 20: Backup And Restore Configuration Files
8.2 Backup And Restore Configuration Files Login WIFI router web main interface,click Router-> Backup and development,then we can config WIFI router as follows: 1.Click “ backup ”button to save the system configuration locally. 2.Choose WIFI Router backup File to restore 3.Click“Configuration”... -
Page 21: Firmware Upgrade
8.3 Firmware Upgrade Login WIFI router web main interface,click Router-> Software upgrade ,then click “Choose file” button,Choose the version you want to upgrade,then click “Confirm” button to ungrade firemware： Upgrade WIFI router need about four minuters,then WIFI router will auto reboot,don’t need reboot manually. -
Page 22: Reboot And Restore Default Settings Wifi Router
8.4 Reboot And Restore Default Settings WIFI Router Login WIFI router web main interface,click Router -> Restart and reset 【Factory reset 】Click “Reset” button to reset WIFI router 【Reboot router】Click“reboot” button to reboot WIFI router. Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.szceres.com... -
Page 23: Config Wifi Router Login Password
8.5 Config WIFI Router Login Password Login WIFI router web main interface,click Router -> Admin password login password： Finish config,click “confirm” button to make config effect. Note :After change the WIFI router login password, we need input new password login WIFI router web interface again. Concluding Remarks Company Address: Flat 6, Bldg 4,South 2 of Honghualing Industrial Zone,Liuxian Road, Xili Town, Shenzhen, Guangdong, China(518055) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) - Page 24 Thanks for using products of Shenzhen Ceres Technology Co., Ltd. Contact Information: Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: 1 floor, Building B, Wentao Industrial Park, Yingrenshi Community,...
