Summary of Contents for Cartoni UV-C BOXER
- Page 1 PROFESSIONAL CAMERA SUPPORT USER’S MANUAL & Maintenance PLEASE REFER TO THIS INSTRUCTION MANUAL BEFORE USE!
-
Page 3: Table Of Contents
1. INTRODUCTION CARTONI UV-C BOXER 1.2 W UV-C hat is light 1.3 a dVantages of germiCidal 1.4 h UV-C oW does destroy germs 2. COMPONENTS LIST 3. WARNINGS & CAUTION RECOMMENDATIONS 4. MOVING & TRANSPORT 5. PROCEDURES 5.1 PREPARATION 5.2 THE DOSIMETRE CARD... -
Page 4: Introduction
COVID-19 can live on metal and plastic surfaces for up to 3 days. In response CARTONI introduces the UV-C BOXER, the first device specially designed & certified to disinfect Film & Video equipment as cameras, lens, Steadicam, batteries, monitors and microphones - just to name a few - from microorganisms, including COVID-19. -
Page 5: A Dvantages Of Germicidal Uv
UV SPECTRUM Visible Light Spectrum UV-C UV-B UV-A UV-C causes phochemical UV-B and UV-A light causes Blue light inhibits bacterical reactions in DNA and RNA oxidation of proteins and lipids growth by prompting generation of resulting in inactivation of resulting in cell death. reactive oxygen species, which are microbes and failure to reproduce. -
Page 6: Components List
• UV-C BOXER • User’s manual • Set of Dosimeters • Power converter & cables... - Page 7 ❶ ❼ ⓬ Emergency switch Main switch Grid ❷ ❽ ⓭ Lamp on Led indicator 10 Lamps status Cable hooks for Led indicator hanging items ❸ Timer ❾ ⓮ Handles Five pivoting wheels, ❹ Switch On/Off two with lock break ❿...
-
Page 8: Warnings & Caution Recommendations
CARTONI declines all responsibility if the consumer does not strictly observe the instructions, WARNING & CAUTION signs for use of the UV-C BOXER. It is therefore recommended that these instructions should be strictly observed in order to avoid any damage to people, animals or objects. -
Page 9: Moving & Transport
The maximum load safely operated by a single individual is 25 kg (55 lbs). Use the pivoting wheels to move the UV-C BOXER around the studio or set. The two right wheels are equipped with a brake, make sure that the brake is on when the UV-C BOXER is positioned for opera-... -
Page 10: Procedures
A recent study from Boston University and Signify has shown that SARS-CoV-2, the virus that causes COVID-19, can be inactivated by UV-C in 25 seconds with a dose of 22 mJ/cm². The UV-C BOXER can irradiate an average of 15mJ/cm per minute so you can set the timer to 3 minutes to be in safety mar- gin. -
Page 11: Disinfection Process
IsInfeCtIon roCess WARNING! WARNING! Always operate the UV-C BOXER in a clean and dry location. Do not expose to rain, humidity, saline water, sand or dust. ❻ • Connect the power cable to the power connector • Connect the power supply to the main power or to a battery. -
Page 12: How To Set Timer Ezm-3735
5.4 h eZm-3735 oW to set Imer START Button Use it as a START button or to increase the value on the four digit display. Gradual silencing BUZZER & STOP button: Use to decrease the value on the four digit display; Use to silence the BUZZER; Use to stop the timer display. -
Page 13: Maintenance
6.1 r outIne AIntenAnCe To clean the exterior casing of the UV-C BOXER use a damp soft cloth. Hygienizing hydro-alcoholic detergents are also suitable. To clean the inside reflecting panels, use a soft damp cloth. For more thorough operation wash with neutral soap and warm water. -
Page 14: Technical Specifications
7. t eChnICAl peCIfICAtIons 7.1 d ImensIons Width: 100 cm 39.4 in. Depth including handle: 66 cm 26 in. Depth excluding handle: 61 cm 24 in. Height including wheels: 88 cm 34.6 in. Height excluding wheels: 76 cm 30 in. Weight: 60 kg 132 lbs... -
Page 15: Safety Devices
Max 90% 7.5 C ertIfICAtIon CARTONI UV-C BOXER is CE certified and comply with EN 61326-1 (2013) (Electromagnetic compat- ibility); EN 61010-2-040 (2015), EN 61010-1 (2010) (Electrical safety). Biological Tests & Certifications by MICROCHEM Laboratory, Round Rock, Texas (USA) www.microchemlab.com and University of Siena Department of Molecular Biology, Siena (Italy) www.dmms.unisi.it/en... -
Page 16: Warranty
The warranty covers replacement of any defective component and the labour required, excluding trans- port/duty costs. CARTONI warrants that the product supplied will – under proper use – be free from defects in work- manship and materials and agrees that it will, as its option, either repair or replace any defective part during the duration of the warranty from date of purchase.
