- Page 1 PRESS PUMP CONTROLLER Auto Manual Installation & Operating Manual...
- Page 3 INDEX SPECIFICATIONS 2. WARNINGS & SYMBOLS 3. INSTALLATION 4. OPERATION 5. TROUBLE SHOOTING 6. TERMS OF WARRANTY © Davis & Shirtliff Ltd 2020 Contents herein are not warranted...
-
Page 4: Specifications
Congratulations on selecting a Dayliff Press Pump Controller. They are manufactured to the highest standards and if installed and operated correctly will give many years of efcient and trouble free service. Careful reading of this Installation Manual is therefore important, though should there be any queries they should be referred to the equipment supplier. -
Page 5: Warnings And Symbols
2. WARNINGS AND SYMBOLS The water column between the controller and highest outlet must be below 15m. No outlet should be installed between the pump and the unit. Max. The controller is preset by the manufacturer at a pressure of 1.5 bar. The pump pressure CAUTION must be normally 0.8bar h i g h e r t h a n t h e p r e s e t... -
Page 6: Installation
3. INSTALLATION Take the controller out of the packaging and check the following; Ÿ 1.) Visible damage. 2.) Ratings correspond with those required. 3.) Cable bushings and screws are in place. 4.) Inlets and outlets are clear and free of debris. 5.) The check valve moves freely. -
Page 7: Operation
If you are using a pump with pressure higher than 10 bar, install a pressure reducer on the inlet . NOTE 4. OPERATION The four screws Three Wire Cable with The two nuts for xing must be fastened the OD of 7.5 - 8.5mm cables must be fastened Outlet Power... -
Page 8: Troubleshooting
5. TROUBLE SHOOTING PROBLEM POSSIBLE CAUSE SOLUTION Faulty P .C.B Replace P .C.B Power failure Check power source and rectify Pump does not start Inverted electric cables Connect cables correctly Faulty pump Replace or repair the pump Faulty P .C.B Replace P .C.B Blocked flow detector Unblock the detector... -
Page 9: Terms Of Warranty
6. TERMS OF WARRANTY i) General Liability In lieu of any warranty, condition or liability implied by law, the liability of Dayliff in Ÿ respect of any defect or failure of equipment supplied is limited to making good by replacement or repair (at the Company’s discretion) defects which under proper use appear therein and arise solely from faulty design, materials or workmanship within a specified period. - Page 12 www.davisandshirtliff.com INS416B-07/20...
