- Page 1 Doorphone Installation Guide...
- Page 3 Northern Telecom or by one of its authorized dealers. Address of repair facilities USA: Canada: Northern Telecom Northern Telecom Product Service Center 30 Norcelco Drive 640 Massman Drive Weston, Ontario Nashville, Tennessee M9L 2X6 37210 Attn: Repairs Department Ph: 1-800-466-7835 Ph: 416-744-5201 FAX: 416-744-5227 Norstar Doorphone Installation Guide...
- Page 4 Norstar Doorphone Installation Guide...
- Page 5 About the Doorphone What is the Doorphone? The Doorphone connects to a digital Meridian Norstar™ telephone port to provide call notification and handsfree communication from a premise entry location to other stations on the system. Door opening functionality can be achieved if installed with one of two optional hardware devices.
- Page 6 Compact and Modular systems. Installation Overview The Doorphone will identify itself to the KSU as an M7208 Norstar telephone. There are five steps to follow when installing a Doorphone: 1. Select a station port for the Doorphone and determine the Directory Number.
- Page 7 Installation Step 1: Determine the Doorphone Directory Number Up to four Doorphones can be installed on a Norstar system. Each is assigned a Directory Number (DN) by the KSU. To determine the DN of the port to which the Doorphone will be connected, use the...
- Page 8 Norstar configuration must be performed before wiring the Doorphone. Startup defaults can cause the Doorphone to automatically answer incoming calls which were not intended to be heard over the Doorphone. 1. Enter Norstar Configuration programming from a Norstar M7310 or M7324 telephone. To do so, ƒ••Ç؈ÏÈÌ...
- Page 9 Installation Step 2: Program Station Ports (cont’d) 2. Perform the following configuration assignments. Refer to the Norstar Installer Guide for details. A. Configuration 1.Trunk/Line Data ensure the Doorphone is not the prime set for any line 2. Line Access remove all line appearances and line ringing assigned to the Doorphone. If you do not remove all line appearances, incoming calls will automatically be answered by the Doorphone.
- Page 10 Doorphone is not a control set ensure the Doorphone is not assigned as an extra-dial set ensure the Doorphone is not assigned as a ringing set Note: Configuration headings may not be exactly as shown, depending on the KSU software version. Norstar Doorphone Installation Guide...
- Page 11 Valid page zones for Doorphone chimes are zones 1, 2 and 3. Note: The Norstar Page feature may be used to deliver the Doorphone chime immediately or after a prescribed number of rings. It is good practice to assign more than one telephone to the page zone used by the Doorphone.
- Page 12 If the wiring between the Doorphone and the KSU is routed outside a building such as aerial or buried cable then protection devices must be installed at each end of the exposed cable for safety and protection. Northern Telecom recommends the ITW LINX MP1A–90–27 secondary protector for this purpose. Norstar Doorphone Installation Guide...
- Page 13 Main Surface Mount Main Wall Housing Bracket Housing Assembly Assembly Face Face Plate Plate Surface Mount Gasket Flush Mount Gasket Figure 4 – Surface Mount Figure 5 – Flush Mount Norstar Doorphone Installation Guide...
- Page 14 Fasten the main housing assembly to the surface mount bracket or electrical box (customer supplied), then fasten the faceplate to the main housing assembly. Norstar Doorphone Installation Guide...
- Page 15 Installation Step 4: Program Doorphone Once you have finished programming Norstar Station Port parameters and connecting the Doorphone, you must specify parameters for the Doorphone's Chime Type, Volume and, if applicable, Door Opening Capabilities. Note: It may take up to four minutes for the Doorphone to initialize. The Doorphone will not initialize or allow programming during an active **CONFIG session.
- Page 16 NEXT display button will be presented if more than one Doorphone is installed. If the Doorphone is not connected or fails, the display shows: F9XX: inactive NEXT REMOVE REMOVE F9XX Use the display button to remove from the system’s memory if a Doorphone is permanently removed. Norstar Doorphone Installation Guide...
- Page 17 1. Select an unequipped station port DN (for example: DN 36) as the Call DN in step 6 above. A.Configuration 2. Enter **CONFIG programming. Navigate to 2. Line Access for telephone 21. Add an Answer DN for DN 36. Norstar Doorphone Installation Guide...
- Page 18 FRONT>DOOR Telephones 21, 22 and 23 will display when the Doorphone’s Call button is pressed. Refer to the Norstar Installer Guide for more details. 7. Press to accept the number of rings before page chimes are presented, or CHANGE none press to select the number of rings.
- Page 19 DONE 11. Press if no other Doorphones need to be programmed. ® ® QUIT 12. Press to end this session. Pressing at any time during the programming session will save any changes before quitting. Norstar Doorphone Installation Guide...
- Page 20 ) from any station will activate the release mechanism. The DOC screw terminals are connected to the Doorphone using one pair of wire. The DOC receives data from the Doorphone and must be dip-switched for proper operation. Norstar Doorphone Installation Guide...
- Page 21 Open time: 3s The display shows: CHANGE CHANGE 12. Press to accept 3 seconds or press to change the number of seconds to 0.25, 6 or 15 then ® QUIT 13. Press to end this session. Norstar Doorphone Installation Guide...
- Page 22 To establish the voice path, dial the Doorphone’s DN from any Norstar telephone, or answer a ringing call from the Doorphone.
- Page 23 With a SAPS installed, the distance can be increased to 780 m (2600 ft). After connecting the Doorphone to the KSU station port, allow up to 4 minutes for initialization. Check that the Norstar port connecting the Doorphone is properly configured. See the Norstar Configuration section of this document for proper configuration parameters.
- Page 24 3. Verify that the connection from the Doorphone to the KSU is functioning properly by making an intercom call to another Norstar telephone. Note: If no dial tone is present, refer to the appropriate Norstar Installer Guide, Troubleshooting Section. 4. Connect the Doorphone into a different port and configure Norstar for the Doorphone.
