Summary of Contents for Gi Spark 2 Combo
- Page 1 Spark 2 Combo Quick Start Guide...
-
Page 2: Packing List
Packing list BOX 1pcs Remote 1pcs (Opt ional) HDMI Cable 1pcs Electric source 1pcs... -
Page 3: Remote Control Unit
Remote Control Unit 1. Power - Switch on or switch off receiver 2. MUTE - Switch on or switch off receiver's sound. 3. SETTING - A shortcut to run System Setting. 4. XBMC - A shortcut to run XBMC. 5. APP STORE - A shortcut to run APP STORE. - Page 4 Front Panel Rear Panel...
-
Page 5: Connecting Satellite Cables
Preparation 1. Connecting Satellite Cables Connect satellite cable from your satellite dish to the LNB input socket on the rear panel of Spark2 Combo box. 2. Connecting Terrestrial/Cable cables Connect Terrestrial or Cable to the Aerial IN socket on the rear panel of Spark2 Combo box. Note: Terrestrial and Cable using the same tuner, so they cannot be used at the same time. -
Page 6: First Time Installation
* Network Cable Spark2 Combo BOX has built-in WIFI, it can connect to the network through the WIFI as well. First Time installation When you switch the box on for the first time, the easy installation starts automatically with the language selection. - Page 7 2. Press >> key go to next network setting. If you are using the network cable to connect the LAN, You can set up the network settings through Ethernet submenu. When you have the option DHCP on, it will automatically detect the correct IP address. DHCP OFF is used when you want to use a certain IP address.
- Page 8 WLAN from the list, if it’s a secure network and it’s the first time you’ve used it, you will need to enter your wifi network password to be able to connect. The 3g submenu is used when Spark2 Combo connect to network via 3g network. Please note that an external 3g USB dongle is required plug into USB port of Spark2 Combo for this functionality.
- Page 9 Here you need select the desired resolution depending on your HD TV Set and confirm with OK. 5. When you have completed your settings by pressing the >> key, the Simple Install appears. This menu allows you to configure one satellite with direct connecting, 4 satellites with DiSEqC 1.0 or 16 satellites with DiSEqC 1.1 and one Terrestrial or Cable tuner.
-
Page 10: Mobile App
Multi-screen interactive functions Mobile APP With the free Spark2 Combo mobile app, you are able to control Spark2 Combo box by mobile phone, and transmit stream from your Spark2 Combo box to your iOS devices or android devices. Web interface With the Web interface you can Control your Spark2 Combo box using a browser on pc or mobile device, you can watch TV, look up EPG-information, set and handle timers, send messages, use its virtual Remote Control and much more. - Page 11 Once a DLNA media server exists on your local network, it allows you to set your Spark2 Combo as a client to play audio, video and photo files from DLNA media Server. You can also set your Spark2 Combo as a DLNA media Server to share your audio, video and photo files to the client devices, at this case you must make sure the Storage Share[Setting>Network>DLNA] is ON.
-
Page 12: Specifications
Specifications Main Processor Quad core Cortex-A7 CPU up to 1.5GHz Flash Memory Emmc : 8GBytes DDR SDRAM 1GBytes Tuner Type DVB-S / DVB-S2, DVB-T/T2/DVB-C Input Connector F-type Connector Female, IEC-type Connector Female Input Voltage DC 12V/2A Power Consumption MAX: 20W Standby:<0.5W S/PDIF Digital Audio or Dolby Digital Bit Stream Output... -
Page 13: Troubleshooting
Trouble shooting Before you contact your local service center, please read the following tips carefully. 1. No video on TV • Check first if the product is powered on and in operational mode. • Check if the video cable is properly connected between TV and Spark2 Combo. •...
