ID SERIES COMPONENT SYSTEM
ID65cs
OWNERS MANUAL
Please read through this manual to familiarize yourself with your new amplifi er. Should your Image Dynamics
mobile amplifi er ever require service, you will need to have the original dated receipt.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ID Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Image Dynamics USA ID Series

  • Page 1 ID SERIES COMPONENT SYSTEM ID65cs OWNERS MANUAL Please read through this manual to familiarize yourself with your new amplifi er. Should your Image Dynamics mobile amplifi er ever require service, you will need to have the original dated receipt.
  • Page 3: Technical Features

    In the interest of safety, Image Dynamics USA highly recommends listening at lower volume levels when driving.
  • Page 4 SPECIFICATIONS for Image Dynamics ID65cs Driver (Due to Constant Improvements, Specifi cations and Parameters are subject to change without notice.) Model Size Nominal Frequency Sensitivity Magnet Mounting Power RMS/Peak Impedance Response 1W/1M Size Depth ID65cs 6.5” 4-ohm 55Hz-25kHz 89 dB 21oz.
  • Page 5: Preparing For Installation

    TIPS TO GET THE MOST OUT OF YOUR Image Dynamics SYSTEM Your Image Dynamics speakers have been meticulously engineered and designed to han- dle high power musical reproduction. Despite their rugged construction, it is possible to damage your speaker if they are improperly used. In general, you will hear distortion as a so-called warning before any damage occurs.
  • Page 6: Installation Precautions

    INSTALLATION PRECAUTIONS NOTE: Proceed only if you are a qualified installer otherwise; let your dealer do it. • Always wear protective eyewear when using tools. • Turn off all stereo and other electrical devices before you begin. • Disconnect the (-) negative lead from your vehicle’s battery. •...
  • Page 7 COMPONENT SYSTEM INSTALLATION Component Woofer The proper installation procedure for mounting these high performance mid-range speak- ers is to secure the speaker to the vehicle’s speaker mounting hole. Once the speaker is in place, determine if the supplied grill needs to be installed. If so, place the grill in place over the speaker and screw the speaker into the mounting hole.
  • Page 8 INSTALLATION PROCEDURES By mounting the tweeter separately from the woofer (or mid-range driver) the installer can choose the best location for sound quality and imaging. Three mounting types are possible allowing more versatility for the tweeter location. These are flush mount, surface mount, and angle mount.
  • Page 9 COMPONENT TWEETERS These high quality tweeters come complete with several mounting housings for installa- tion versatility. Typically tweeters should be mounted on axis and as close to ear level as possible. After you have chosen the housing to be used, gently press the tweeter in the proper mounting base.
  • Page 10 TO THE CROSSOVER NETWORK TERMINALS. This manual is the exclusive property of Image Dynamics USA, Inc. Any reproduction of this manual, or use other than its intentions is strictly prohibited without the express consent of Image Dynamics USA, Inc. Copyright 2016 Image Dynamics USA, Inc.
  • Page 11: Limited Warranty Policy

    Image Dynamics LIMITED WARRANTY POLICY Image Dynamics USA, Inc. offers limited warranty on Image Dynamics products under normal use on the following terms: Image Dynamics Speakers are to be free of defects in material and workmanship for a period of one (1) year.
  • Page 12 Image Dynamics USA 2133 S. Green Privado – Ontario, CA 91761 Tel. (909) 930-1377 – Fax (866) 239-4399 www.imagedynamicsusa.net...
