ClareOne Rate of Rise Heat Detector
Installation Sheet
Last modified: 05/28/20
Model Number: CLR-C1-HT
Description
The ClareOne Rate-Of-Rise heat detector uses a built-in
thermistor to sample and report on a specific set temperature
or a sudden rise in temperature.
Heat – selectable 135F or 200F
Rate of Rise – rapid temp rise 12F per minute
Note:
The device is powered by a 3V lithium battery providing
up to 10 years of battery life.
Installation
Heat detectors are normally installed in areas that are prone to
smoke such as kitchens and garages.
Installation notes:
•
Avoid areas that may have rapidly increasing
temperatures such as fireplaces, stoves, heaters, etc.
•
When mounting the detector should be placed on a ceiling
at least 4 inches away from any wall. If placed on a wall
the detector must be within 6 inches of the ceiling.
•
If using the sensor with the heat setting at 135°F make
sure the ceiling location does not exceed this temperature.
© 28MAY20 Clare Controls, LLC.
Setup:
The detector can be setup to detect a fixed temperature of
either 135F or 200F.
Low – 135F
High – 200F
Note:
if no jumper is installed the detector is set to 200F
To set detection temperature: Use the jumper to select Low
or Hi.
Programming
To add the sensor to your panel and for detailed programming
instructions, refer to the
Home Panel User Manual (DOC ID 1871)
To add the detector:
Put the ClareOne panel in "add mode" and follow the
1.
displayed instructions for adding the sensor.
2.
Open the sensor body case and depress the tamper
switch.
Exit "add mode."
3.
1 / 3
ClareOne Wireless Security and Smart
.
DOC ID – 1945 • Rev 03
Advertisement
Table of Contents
Related Manuals for clare ClareOne Rate of Rise
Summary of Contents for clare ClareOne Rate of Rise
- Page 1 ClareOne Rate of Rise Heat Detector Installation Sheet Setup: The detector can be setup to detect a fixed temperature of either 135F or 200F. Low – 135F High – 200F Note: if no jumper is installed the detector is set to 200F To set detection temperature: Use the jumper to select Low or Hi.
- Page 2 Locate the base mounting holes and mount the base to the wall or ceiling with the appropriate hardware. Regulatory information Attach the detector to the mounting base. Manufacturer Clare Controls, LLC. 7519 Pennsylvania Ave, Suite 104 Sarasota, FL 34243 \FCC compliance This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 3 Warranty information LIMITED TO) ANY WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A Clare Controls offers a two (2) year limited warranty on original PARTICULAR PURPOSE WITH RESPECT TO Clare Controls components, from the date of shipment from THESE PRODUCTS AND ANY RELATED Clare Controls.
