1143900
Instruction Sheet – SmartPAC PRO
Second Ethernet Port Installation
The following procedure shows you how to install the mini PCIe network card with second
ethernet port into the SmartPAC PRO Standard and Pendant Configuration units (Figure 1
below). SmartPAC PROs, with HMI assembly revision greater than or equal to D, can have
a second ethernet port by inserting a card (Wintriss part number 4353001) into its mini PCIe
slot. The main advantage of having a second ethernet port is it allows for separating the
network activity. For example, the default onboard network port can be used for data
collection over the factory network while the second port can be dedicated to a control
network. The control network can thus be isolated from the factory network which
eliminates the need for assigning more IP address and keeps the traffic local to itself.
Please read all instructions below before proceeding with the installation.
Unpacking the Replacement Board
Perform the following steps as soon as you receive your SmartPAC PRO Second Ethernet Port
mini PCIe network card:
CAUTION
DAMAGE TO BOARD FROM STATIC DISCHARGE
Ground yourself before touching circuit boards by touching a large metal object such as the
press or wearing a connected ground strap.
components.
Failure to comply with these instructions could result in property damage.
1. Making sure you are statically discharged, carefully unpack the mini PCIe network card, and
remove it from its anti-static bag.
The 4353001 kit consists of the following:
1x PCIe Mini Card hardware assembly.
1x Gigabit RJ-45 Ethernet adapter cable.
1x Hardware kit which contains (2) mounting screws.
NOTICE
Be sure to save the shipping box and anti-static bag in case you need to return the mini PCIe
network card for any reason.
Instruction Sheet
Second Ethernet Port Installation
Wintriss Controls Group
SmartPAC PRO Second Ethernet Port Installation
Static electricity can destroy electronic
June 2021
Rev. A
978-268-2700
1143900
Page 1
toll free 800-586-8324
Advertisement
Table of Contents
Summary of Contents for Wintriss SmartPAC PRO 4353001
- Page 1 SmartPAC PROs, with HMI assembly revision greater than or equal to D, can have a second ethernet port by inserting a card (Wintriss part number 4353001) into its mini PCIe slot. The main advantage of having a second ethernet port is it allows for separating the network activity.
- Page 2 SmartPAC PRO Second Ethernet Port Installation 2. Verify that the board has not been damaged during shipment. If damage has occurred, contact Wintriss Tech Support immediately. Figure 1. Mini PCIe NIC Module with RJ45 Socket Pigtail Installing the Replacement Board...
- Page 3 HMI board and tie wrap to the standoff as shown in Figure 3 below. Figure 3. Mini PCIe Module Pigtail with RJ45 Socket Installed Instruction Sheet June 2021 1143900 Second Ethernet Port Installation Rev. A Page 3 Wintriss Controls Group 978-268-2700 toll free 800-586-8324...
- Page 4 USB extender below the HMI board as shown in Figure 4 below. Figure 4. Mini PCIe Module Pigtail with RJ45 Socket Installed into USB Extender Flange Instruction Sheet June 2021 1143900 Second Ethernet Port Installation Rev. A Page 4 Wintriss Controls Group 978-268-2700 toll free 800-586-8324...
- Page 5 If you do not see “Local Area Connection 2” and instead see “Not Installed” as shown in Figure 6, then something is wrong. Power down and check that the card and cable are properly inserted. Instruction Sheet June 2021 1143900 Second Ethernet Port Installation Rev. A Page 5 Wintriss Controls Group 978-268-2700 toll free 800-586-8324...
- Page 6 “Connected”. You must exit this screen and go back into it to refresh the status. NOTICE SmartPAC PRO will annunciate the loss of the communication if it detects a loss of connection. Instruction Sheet June 2021 1143900 Second Ethernet Port Installation Rev. A Page 6 Wintriss Controls Group 978-268-2700 toll free 800-586-8324...
