GFA ELEKTROMATEN FCP03 Instructions Manual

Fire control panel 03
Hide thumbs
Table of Contents

Advertisement

Quick Links

FCP03
Fire Control Panel 03
10.19

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FCP03 and is the answer not in the manual?

Questions and answers

Summary of Contents for GFA ELEKTROMATEN FCP03

  • Page 1 FCP03 Fire Control Panel 03 10.19...

  • Page 3: Table Of Contents

    Fig 9b ............................. 18 Fire Control Panel 03 – Set Up ....................19 To Enter the FCP03 Set-Up Menus ..................19 Fire Control Panel 03 – Fast Set Tables ..................20 Fire Control Panel 03 – Fast Set Drawings ................23 Fast-Set 1 ..........................

  • Page 4: Fire Control Panel 03 - General Layout

    Fire Control Panel 03 – General Layout General Layout of Drives and Controls WARNING WARNING FIRE FIRE SHUTTER SHUTTER CLOSING CLOSING Fig 1 03 Fire Door Control Systems...

  • Page 5: Fire Control Panel 03 - Connection Drawings

    Fire Control Panel 03 – Connection Drawings Fire Control Panel Mains Supply Connections PUSH MOTOR RESET BUTTON OUTPUT AUX 1 AUX 2 SOLENOID ZONE 2 ZONE 1 INPUT CONTROL 1 2 3 4 5 6 7 8 9 10 1112 13 141516 1718 19 20 2122 232425 26 2728 F100mA F1.0A F1.0A...

  • Page 6: Dla150W Mains Supply And Fire Control Panel Open, Stop, Close Command Wiring

    Fire Control Panel 03 – Connection Drawings DLA150W Mains Supply and Fire Control Panel Open, Stop, Close Command Wiring PUSH RESET BUTTON AUX 1 AUX 2 SOLENOID ZONE 2 ZONE 1 INPUT 1 2 3 4 5 6 7 8 9 10 111213 141516 171819 20 2122 232425 262728 F100mA F1.0A F1.0A...

  • Page 7: Dla250W Mains Supply And Fire Control Panel Open, Stop, Close Command Wiring

    Fire Control Panel 03 – Connection Drawings DLA250W and DLA500W Mains Supply and Fire Control Panel Open, Stop, Close Command Wiring PUSH RESET BUTTON AUX 1 AUX 2 SOLENOID ZONE 2 ZONE 1 INPUT 1 2 3 4 5 6 7 8 9 10 111213 141516 171819 20 2122 232425 262728 F100mA F1.0A F1.0A...

  • Page 8: Dla600 And Dla800 Mains Supply And Fire Control Panel Open, Stop, Close Command Wiring

    Fire Control Panel 03 – Connection Drawings DLA600, DLA800 and DLA1000 Mains Supply and Fire Control Panel Open, Stop, Close Command Wiring PUSH RESET BUTTON AUX 1 AUX 2 SOLENOID ZONE 2 ZONE 1 INPUT 1 2 3 4 5 6 7 8 9 10 111213 141516 171819 20 2122 232425 2627 28 F100mA F1.0A F1.0A...

  • Page 9: Dla150Wf, Dla150Wm. Dla150Wmf And Dla150Wa Solenoid Release Connection

    Fire Control Panel 03 – Connection Drawings DLA150W Alarm Release Mechanism Connection ACTUATOR CONNECTION SOLENOID CONNECTION PUSH MOTOR RESET BUTTON OUTPUT AUX 1 AUX 2 ZONE 2 ZONE 1 IN PUT CONTROL 1 2 3 4 5 6 7 8 9 10 1112 13 14 15 16 17 19 20 2122 23 24 25 26 27 28 F100mA F1.0A...

  • Page 10: Connection

    Fire Control Panel 03 – Connection Drawings DLA250W, DLA500W, DLA600, DLA800 and DLA1000 Alarm Release Mechanism Connection ACTUATOR CONNECTION SOLENOID CONNECTION PUSH MOTOR RESET BUTTON OUTPUT AUX 1 AUX 2 ZONE 2 ZONE 1 INPUT CONTROL 1 2 3 4 5 6 7 8 9 10 111213 141516 17 19 20 2122 232425 262728 F100mA F1.0A...

  • Page 11: Jesapz1-2T - Connecting A Key Switch

    Fire Control Panel 03 – Connection Drawings JESAPZ1-2T – Connecting a Key Switch. PUSH MOTOR RESET BUTTON OUTPUT AUX 1 AUX 2 SOLENOID ZONE 2 ZONE 1 INPUT CONTROL 3 4 5 6 7 8 9 10 111213 141516 171819 20 2122 232425 262728 F100mA F1.0A F1.0A...

  • Page 12: Ge3A - Connecting A 3 Push Button Station

    Fire Control Panel 03 – Connection Drawings GE3A – Connecting a 3 Push Button Station. PUSH MOTOR RESET BUTTON OUTPUT AUX 1 AUX 2 SOLENOID ZONE 2 ZONE 1 INPUT CONTROL 3 4 5 6 7 8 9 10 111213 141516 171819 202122 232425 262728 F100mA F1.0A F1.0A...

  • Page 13: Fire Control Panel 03 - Alarm Connection Drawings

    Fire Control Panel 03 – Alarm Connection Drawings The Fire Control Panel 03, FCP03, will accept DC or Volt Free Fire Alarm Signals from a central Fire Alarm System or Local Heat or Smoke Detectors. The FCP03 can be set for: ...

  • Page 14: Connection Of Single Smoke / Heat Detector For Full Close Activation

    Fire Control Panel 03 – Alarm Connection Drawings Connection of Single Smoke / Heat Detector for Full Close Activation AUX 1 AUX 2 SOLENOID “Engineering Set-up” Closing Style “Full Drop” 1213 141516 171819 20 2122 232425 262728 Double Knock “Off” ZONE ZONE Zones “NC”...

  • Page 15: Connection Of Dual Alarm Zone 1 And Zone 2 Alarm Full Close Activation

    Fire Control Panel 03 – Alarm Connection Drawings Connection of Dual Alarm Zone 1 and Zone 2 Alarm Full Close activation In this configuration both Alarms must be triggered to activate the Fire Control Panel 03. If only 1 Alarm is triggered the Aux 1 relay is energised. PUSH MOTOR BUTTON...

  • Page 16: Stage Alarm, Zone 1 Alarm Part Close, Zone 2 Alarm Full Close

    Fire Control Panel 03 – Alarm Connection Drawings Stage Alarm, Zone 1 Alarm Part Close, Zone 2 Alarm Full Close. (2 Stage Alarm operation only functions when mains power is available) In this configuration the Shutter closes to a set height on activation of Zone 1 Alarm and closes completely on activation of Zone 2 Alarm.

  • Page 17: Fire Control Panel 03 - Photo Beam Connection Drawings

    Fire Control Panel 03 – Photo Beam Connection Drawings Connection of a Reflective Photo Beam PUSH MOTOR RESET BUTTON OUTPUT AUX 1 AUX 2 SOLENOID ZONE ZONE 1 INPUT CONTROL 1 2 3 4 5 6 7 8 9 10 111213 141516 17 1819 20 2122 232425 262728 F100mA F1.0A F1.0A...

  • Page 18: Connection Of A Thru-Beam Photo Beam

    Fire Control Panel 03 – Photo Beam Connection Drawings Connection of a Thru-beam Photo Beam PUSH MOTOR RESET BUTTON OUTPUT AUX 1 AUX 2 SOLENOID INPUT CONTROL 1 2 3 4 5 6 7 8 9 10 111213 1415 16 1718 19 20 2122 23 2425 262728 F100mA F1.0A F1.0A...

  • Page 19: Fire Control Panel 03 - Set Up

    19 - 24) N.B. Pressing ‘SELECT’ sets the FCP03 to the Fastset last displayed. ONLY PRESS SELECT IF YOU ARE SURE THAT YOU WANT TO CHANGE THE FCP03 FUNCTIONS. Press ‘Down’ to scroll back through Fastset 5 to 1. From Fastset 1 press ‘DOWN’ to ‘EDIT DELAYS’.

  • Page 20: Fire Control Panel 03 - Fast Set Tables

    Fire Control Panel 03 – Fast Set Tables Fast-sets are a quick means of setting the FCP03 Fire Control Panel to commonly used configurations. Fast-sets Door Type Solenoid Drop Full Control Closing Style 2 Stage Close Full Drop Double Knock...
  • Page 21 Fire Control Panel 03 – Fast Set Tables Fast-sets Part Close Set Up Sign Off Sign On Flashing Off Flashing On Sounder Off Sounder On Aux 1 Off Aux 1 On Part Close End Set Up Sign Off Sign On Flashing Off Flashing On Sounder Off...
  • Page 22 Fire Control Panel 03 – Fast Set Tables Fast-sets Reset, Setup Auto Reset Reopen Time Mins Secs Button Press Power Failure Both Low Battery Mains Aux 2 Setup None Imitate Stop Relay Imitate Close Relay Imitate Open Relay Imitate Trigger Relay Indicate Mains Failure Indicate Battery Failure PEC Alarm...

  • Page 23: Fire Control Panel 03 - Fast Set Drawings

    Fire Control Panel 03 – Fast Set Drawings Fast-Set 1 WARNING FIRE SHUTTER CLOSING Fig 11a Fast-Set 2 WARNING FIRE SHUTTER CLOSING Fig 11b 03 Fire Door Control Systems...

  • Page 24: Fast-Set 3

    Fire Control Panel 03 – Fast Set Drawings Fast-Set 3 WARNING FIRE SHUTTER CLOSING Fig 11c Fast-Set 4 WARNING FIRE SHUTTER CLOSING Fig 11d 03 Fire Door Control Systems...

  • Page 25: Fast-Set 5

    Fire Control Panel 03 – Fast Set Drawings Fast-Set 5 WARNING FIRE SHUTTER CLOSING Fig 11e 03 Fire Door Control Systems...

  • Page 26: Fire Control Panel 03 - Engineers Set Up

    Fire Control Panel 03 – Engineers Set Up Description of Functions Guthrie Douglas Fig 12 03 Fire Door Control Systems...
  • Page 27 3. DOUBLE (KNOCK) NOC (Only if Closing Style = Full Drop) – Off or On Ignores the Double Noc Option. Alarm Zones 1 & 2 must both be triggered before the FCP03 will activate the Alarm closing Sequence. If only one of the Zones triggers the AUX 1 relay is energised.
  • Page 28 **SUB MENU OPTIONS (Only if Safety Circuit = ON, BOTH, FULL or PART) 5a. NO OF RETRIES During an Alarm if the Photo Beam is continuously obstructed the FCP03 can be programmed to ignore the Photo Beam after checking “x” times to see if the obstruction has been removed.
  • Page 29 Fire Control Panel 03 – Engineers Set Up 6. DOOR DELAYS 6a. Part Close Delay (Only if Closing Style = 2 Stage Drop) On activation of Zone 1 the Part Close Delay timer starts to count down. The shutter will start to close when the Part Close Delay time elapses. 6b.
  • Page 30 Fire Control Panel 03 – Engineers Set Up 8. Part Close End Set Up Select the operation, ON / OFF and Flashing, of the Lamp, Sounder and Relay ‘Aux 1’ when the Shutter has stopped at the Part Close Position 8a.
  • Page 31 Re-Open Timer (Only if Reset Set-Up = Auto Reset If the Re-Open Timer is set to 000 minutes, 000 seconds the Shutter remains closed when the FCP03 is Reset. If a Time is set the Shutter will Automatically Open for the Time set by the Re- Open Timer.
  • Page 32 FPC03 Sounder will operate. Photo Beam obstruction ignored. 16. Trigger Delay The Alarm signal must be present for 10 seconds before the FCP03 will activate. Can be used to prevent nuisance tripping. When there is a Fire Alarm signal the FCP03 activates immediately.

  • Page 33: Fire Control Panel 03 - Trouble Shooting

    Check the Motor Safety Circuit, i.e. Manual Operator, Over travel The Motor will not run. Limits, Motor Thermal. FCP03 Stop Circuit, terminal 3 – 5, is closed. Check FCP03 Fuse F4. The Alarm Solenoid will not Check that the FCP03 is set to: operate, Shutter does not close in Door Type = Solenoid Drop.

  • Page 34: Fire Control Panel 03 - Your Settings

    Fire Control Panel 03 – Your Settings Door Type Solenoid Drop Sounder On Power Failure Aux 1 Off Full Control Door Delays Part Close Delay Both Aux 1 On Mins Low Battery Closing Style 2 Stage Close Secs Full Close Set Mains Full Drop Sign Off...

  • Page 35: Fire Control Panel 03 - Replacing The Batteries

    Fire Control Panel 03 – Replacing the Batteries Replacing the Batteries 1. Turn Off the Mains Supply. 2. Remove the Fire Control Panel 03 front cover. PUSH MOTOR RESET BUTTON OUTPUT AUX 1 AUX 2 SOLENOID ZONE 2 ZONE 1 INPUT CONTROL 1 2 3 4 5 6 7 8 9 10 111213 141516 171819 20 2122 232425 262728...
  • Page 36 Supplied by: GfA ELEKTROMATEN UK Ltd Agincourt Road, Warwick, CV34 6XZ, United Kingdom. Telephone: 01 926 452452 Fax: 01 926 336417 E-mail: sales@ gfa-elektromaten.co.uk Web Site: www.gfa-elektromaten.co.uk...
