  • Page 1 USER’S MANUAL CAP FRAME TUBULAR GOODS FRAME BORDER FRAME SINGLE HEAD TYPE TFMX-C TEMX-C TEJT II -C Original Instructions M-WHMGIC04-E (2009.10)
  • Page 3 Foreword This manual is a guide book for using cap frame, tubular goods frame and border frame correctly.Please read this manual thoroughly and use frames after understanding the contents. Frames to be used for cap embroidery include semi-wide cap frame besides wide cap frame, and cap frame unit that drives the semi-wide cap is common.
  • Page 4 Contents Changing procedure of the frame Turn OFF the power switch, or select sleep mode........ p.1-2 To change frame ................... p.1-2 Turn ON the power switch, or release sleep mode ......p.1-19 Change of setting on the operation panel ........... p.1-19 Set the frame.
  • Page 5 Changing procedure of the frame Turn OFF the power switch, or select sleep mode ......p.1-2 To change frame ................p.1-2 Turn ON the power switch, or release sleep mode....p.1-19 Change of setting on the operation panel........p.1-19...
  • Page 6 Changing procedure of the frame Turn OFF the power switch, or select sleep mode In case of TFMX-C/TEMX-C..............If you set the machine to sleep mode, later working will become efficient (p.1-19). Turn OFF the power, or select sleep mode.
  • Page 7 Loosen the screw (1) to detach the border frame (2). Switching of table position In case of TFMX-C................... Pull the table (1) to the front to take out, and attach the table to the position of cap frame/tubular goods frame spec. (A).
  • Page 8 Changing procedure of the frame Installation of cap frame unit When the wire of the cap frame unit (3) is loose, it is necessary to perform adjustment (p.3-6). Set the cap frame unit (3) so that the drive ring (1) fits in the bed (2). Connect the cap frame unit (3) and drive section (6) using the screws (4) and (5).
  • Page 9 Changing procedure of the frame Attaching of cap frame guide In case of TFMX-C................... Remove the screw (1) to detach the hook cover (2). It is not necessary to remove the attached cap frame guide (4) even when frame spec. is changed. However, if the cap frame guide has a disadvantage for embroidery work, return it to the hook cover (2).
  • Page 10 Changing procedure of the frame Check if the frame moves smoothly. CAUTION Check if the slide angle (1) moves smoothly to crosswise direction by hand. When it does not move smoothly, check abrasion of the contact point (3) between the cap Use with remaining load could cause the machine frame base (2) and slide angle (1) and/or the slide plate (4).
  • Page 11 Loosen the screw (1) to detach the border frame (2). Switching of table position In case of TFMX-C................... Pull the table (1) to the front to take out, and attach the table to the position of cap frame/tubular goods frame spec. (A).
  • Page 12 Changing procedure of the frame Attaching of tubular goods frame sash Fix the tubular goods frame sash (1) using the attaching screw (2). Proceed to the next work. Turn ON the power switch, or release sleep mode (p.1-19) and after KY01...
  • Page 13 Changing procedure of the frame From tubular goods frame to cap frame Detaching of tubular goods frame sash Loosen the screw (2) to detach the tubular goods frame sash (1). Installation of cap frame unit When the wire of the cap frame unit (3) is loose, it is necessary to perform adjustment (p.3-6).
  • Page 14 (1) is about 3 mm. 3 mm Attaching of cap frame guide In case of TFMX-C .................. Remove the screw (1) to detach the hook cover (2). It is not necessary to remove the attached cap frame guide (4) even when frame spec.
  • Page 15 1-11 Changing procedure of the frame In case of TEJTII-C/TEMX-C..............Loosen the screw (5). It is not necessary to remove the attached hook cover (6) Fix the hook cover (6) using the screw (5). even when frame spec. is changed. However, if the cap frame guide has a disadvantage for embroidery work, detach the hook cover (6).
  • Page 16 Loosen the screw (2) to detach the tubular goods frame sash (1). Switching of table position In case of TFMX-C .................. Pull the table (1) to the front to take out, and attach the table to the position of border frame spec.
  • Page 17 1-13 Changing procedure of the frame Attaching of border frame Fix the border frame (2) using the screw (1). Proceed to the next work. Turn ON the power switch, or release sleep mode (p.1-19) and after KY01...
  • Page 18 1-14 Changing procedure of the frame From cap frame to tubular goods frame Detaching of cap frame unit Loosen the screws (1) and (2) to detach the cap frame unit (3). Attaching of tubular goods frame sash Fix the tubular goods frame sash (1) using the attaching screw (2). KY01...
  • Page 19 1-15 Changing procedure of the frame Attaching of hook cover (In case of TFMX-C) In case of TEJTII-C/TEMX-C: Proceed to “Detaching of cap frame guide” (p.1-15). Remove the screw (1) to detach the cap frame guide (2). You may let the cap frame guide (2) remain as it is.
  • Page 20 Loosen the screws (1) and (2) to detach the cap frame unit (3). Switching of table position In case of TFMX-C .................. Pull the table (1) to the front to take out, and attach the table to the position of border frame spec.
  • Page 21 Insert the table fitting (6) to the entry of the cover. Attaching of border frame Fix the border frame (2) using the screw (1). Attaching of hook cover (In case of TFMX-C) In case of TEJTII-C/TEMX-C: Proceed to “Detaching of cap frame guide” (p.1-18).
  • Page 22 1-18 Changing procedure of the frame Attach the hook cover (4) using the screw (3). You may let the cap frame guide (6) remain as it is. Detaching of cap frame guide (TEJTII-C/TEMX-C) However, if has a trouble for embroidery works, detach it. Loosen the screw (5).
  • Page 23 Change of setting on the operation panel Change to drive mode that is suitable for the frame to use. In case of TEJTII-C ..............to p.1-21 In case of TFMX-C/TEMX-C.......... Following works Change of frame type After the setting, the power will be turned OFF/ON 7 Frame Type automatically.
  • Page 24 1-20 Changing procedure of the frame Change of frame type Select frame type you use. Example Cap frame After the setting, the power will be turned OFF/ ON automatically. Frame origin memory When a memorized position of absolute origin is wrong, the This operation makes the machine memorize the absolute origin of the embroidery following problems will occur.
  • Page 25 1-21 Changing procedure of the frame In case of TEJTII-C ................. Switch to "FRAME SETTING" * * * * E M B S T A R T * * * * T A J I M A 1 2 . D S T 0 / 1 0 2 7 Frame 0 1 / 1 5 : 2 3 4 5 6 7 8 9 A B <...
  • Page 26 1-22 Changing procedure of the frame...
  • Page 27 Set the frame. Cap frame ..................p.2-2 Tubular goods frame..............p.2-5...
  • Page 28 Set the frame. Cap frame [Setting procedure] Set the cap frame (1) to the setting frame (2). Push into the cap frame (1) until it is fixed by the lock pin (3) of the setting frame (2). In case of semi-wide cap frame, although the shape is different, the same manner is applied to the working.
  • Page 29 Set the frame. Pull the sweat band (6) of cap outside. Perform setting so that the sweat band (6) is clipped between the bracket (7) and interlining cloth (5). Align the center of cap with the mark-off line of the bracket (7) so that the visor (8) of cap comes directly above. After positioning the cap, close the lid frame (9) and fix the cap using the lock (10).
  • Page 30 Set the frame. Fix embroidery area using the clip (11) after stretching it so that roundness of cap still remains. Push the attach/detach lever (4) to detach the cap frame. Set the cap frame (1) to the drive base frame (12). Push the cap frame (1) into the drive base frame (12) until the cap frame is fixed by the lock pin (3).
  • Page 31 Set the frame. Tubular goods frame [Setting procedure] Loosen the screw (1) to adjust the position of the fabric stretching arm (2) so that the tubular goods frame gauge fits to the size of fabric. Place the outer frame (4) on the tubular goods frame gauge (3) and lay the fabric (sweat shirt in this example) over the frame gauge.
  • Page 32 Set the frame.
  • Page 33 Adjustment of each part Wide cap frame................p.3-2 Semi-wide cap frame ..............p.3-3 Tubular goods frame..............p.3-5 Adjustment of tension of drive wire..........p.3-6...
  • Page 34 Adjustment of each part Wide cap frame Adjustment of depth of cap It is possible to adjust the frame to the depth of cap by changing the attaching position of the needle plate guide (1). Depth Adjustment to fit to material thickness of cap CAUTION Adjust the fixing position of the lid frame fitting according to thickness of cloth of cap.
  • Page 35 Adjustment of each part Semi-wide cap frame Adjustment of depth of cap Remove the screw (1) and detach the base frame B set (2). It is not possible to use sequin device. Round shape caps are not suitable for semi-wide cap frames. Attach the base frame B set (2) to the position where depth of cap is fitted.
  • Page 36 Adjustment of each part Adjustment to fit to material thickness of cap CAUTION Adjust the fixing position of the fitting according to fabric thickness of cap. Neglect of the adjustment according to fabric thickness of cap could cause damage of the frame and/or displacement of design. Remove the nut (1) and detach the pinch lock (2) from the clamp base (3).
  • Page 37 Adjustment of each part Tubular goods frame Position adjustment of frame presser spring Move the tubular goods frame (1) back and forth and perform adjustment if there is a play. Loosen the screw (2) and push the tubular goods frame arm (3) to touch the pawl (4). The shape of the tubular goods frame arm differs depending on type of frame.
  • Page 38 Adjustment of each part Adjustment of tension of drive wire When the center of the cap frame is misaligned or tension of the drive wire became loose during storage of cap frame unit and so on, perform this work. When the drive wire comes off or you change the drive wire, refer to “Assembling of cap frame unit” (p.4-2). CAUTION Since you must perform this work with the power turned ON, pay enough attention to operation on the panel each other when plural persons perform works.
  • Page 39 Adjustment of each part Detach the nut (10) and base presser roller (11), and loosen the nut (12). Fix the tension block (14) of the wire tension gauge (13) at the position of A using the thumbscrew (15). Turn the tension nut (16) to move the tension block (17) to the innermost. Put the wire tension gauge (13) between the slide nuts (7) and (18), and make the tension block (17) touch the inner face of the slide nut (18) on the right side.
  • Page 40 Adjustment of each part Turn the tension nut (16) by hand to the direction where the tension block (17) moves outside, and apply further 4/6 turn from the position where the tension nut stops by using the wrench. To rotate the tension nut (16), take engraved numbers as rough standard. After tightening the screw (5) of the slide nut (18) on the right side, detach the wire tension gauge (13).
  • Page 41 Assembling of cap frame unit Assembling of cap frame unit ............p.4-2 Adjustment of tension of drive wire..........p.4-4...
  • Page 42 Assembling of cap frame unit Assembling of cap frame unit Attaching of drive ring unit Fix the drive ring unit (1) to the cap frame base (3) using the screw (2) temporarily. Tighten the screw (2) in the state of touching the rear face (5) of the stepped section of the base bracket (4) to the front face of the cap frame base (3).
  • Page 43 Assembling of cap frame unit Slide the slide angle (6) and set it to the cap frame base (3). Detach the nut (7) and base frame presser roller (8), and loosen the nut (9). Attaching of drive wire Remove the screw (1) and loosen the screws (2) and (3). Align the inner side of the slide nut (4) with the position of the punched hole (5), and then tighten the screw (2).
  • Page 44 Assembling of cap frame unit Wind the wire (6) to the drive ring (7) by one turn. After reversing the drive wire (6) by the wire guide ring (8), tighten the end part (9) using the screw (10) temporarily. Put the drive wire (6) on the left side in the rear groove (A) of the wire guide ring (8), and put the drive wire (6) on the right side in the front groove (B) of the wire guide ring (8).
  • Page 45 Tokai Industrial Sewing Machine Co., Ltd. NO.1800, Ushiyama-cho, Kasugai, Aichi-pref., 486-0901, Japan Telephone:568-33-1161 Fax:568-33-1191 Distributed by: Tajima Industries Ltd. 19-22, Shirakabe, 3-chome, Higashi-ku, Nagoya, 461-0011, Japan Telephone:52-932-3444 Fax:52-932-2457 Authorized Distributor: Copy, reprint, or reform of a part or whole of this manual without permission is prohibited.
