HOT-137/HOT-139
IGA1680 PCI Bus
VGA Card
User's Manual
1
IGA1680 PCI VGA

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HOT-137 and is the answer not in the manual?

Questions and answers

Related Manuals for Shuttle HOT-137

Summary of Contents for Shuttle HOT-137

  • Page 1 HOT-137/HOT-139 IGA1680 PCI Bus VGA Card User's Manual IGA1680 PCI VGA...
  • Page 2 NOTICE Manual Ver. 1.0 Copyright 1995. All Right Reserved All information, documentation, and specifications contained in this manual are subject to change without prior notification by the manufacturer. The author assumes no responsibility for any errors or omissions which may appear in this document nor does it make a commitment to update the information contained herein.

  • Page 3: Table Of Contents

    These card have .............................. 6 What should you have inside the package ? ....................7 What you'll need ? ............................7 Document Conventions ..........................8 HOT-137 Card Layout ............................ 9 HOT-139 Card Layout ..........................10 Hardware Installation Hardware Installation ..................
  • Page 4 To install the drivers under windows NT 3.1 ................... 18 To install the drivers under windows NT 3.5 ................... 19 OS/2 2.1 & Warp Drivers Installation ......................20 Installing AutoCAD Drivers ........................... 23 Installing the Lotus 1-2-3 Drivers ........................24 Installing PCAD Drivers ..........................

  • Page 5: Introduction

    Congratulations !! You have just purchased the fastest and latest graphics and multimedia accelerator card available on the market -- the HOT-137/HOT-139. Under DOS, Windows and OS/2, it features up to 16.7 million colors at resolutions up to 1600 x 1280, and screen refresh rates up to 75Hz.

  • Page 6: These Card Have

    These cards have: High performance acceleration VGA card in PCI bus. High screen refresh rates up to 75Hz. Provide Flicker-Free environment for health eyes. High resolution modes include 1024 x 768 x 64K colors in 75Hz, and 1600 x 1200 x 256 colors in 60Hz.

  • Page 7: What Should You Have Inside The Package

    What should you have inside the package ? Your HOT-137/HOT-139 package includes the following hardware, software, and documentation: HOT-137 or HOT-139 PCI VGA card Software diskettes which include drivers and utilities This user's manual What you'll need ? Computer System - Intel 486, Pentium, or compatible.

  • Page 8: Document Conventions

    Type Style Used For bold A command name or text. You type it exactly as it appears. e.g., you type SETUPWIN to run the HOT-137/139 installation program. italic A variable parameter. You substitute it with an appropriate value or text.

  • Page 9: Hot-137 Card Layout

    HOT-137 Card Layout IGA1680 PCI VGA...

  • Page 10: Hot-139 Card Layout

    HOT-139 Card Layout IGA1680 PCI VGA...

  • Page 11: Chapter 2 Hardware Installation

    Hardware Installation Hardware Installation HOT-137/HOT-139 PCI VGA card automatically detects whether you are using a monochrome or color monitor. Therefore, the monitor must be turned on before the computer, or an incorrect monitor type may be detected. This card supports most analog monitors on the market. If monitor type is not detected during power-up, the card will default to support monochrome VGA.

  • Page 12: Installing The Hardware

    Installing the Hardware Jumper Setting The HOT-137/HOT-139 has one jumper to determine the IRQ9 setting. The jumper is preset at the factory and in most cases you will not need to change it. The jumper at location J6 enables or disables IRQ9.
  • Page 13 If the system successfully powers up and the normal DOS boot-up message appears on the screen, the HOT-137/HOT-139 is installed properly. If the system does not boot, there are a few things you can check in following "Hardware Troubleshooting".

  • Page 14: Hardware Troubleshooting

    Check BIOS at location U2. Make sure all the pin and pin #1 location are installed properly. Check display memory DRAM at locations U6 and U7 on HOT-137 (U6, U7, U8, and U9 on HOT-139). Make sure all the pin are installed or mounted properly.

  • Page 15: Software Installation

    HAPTER Software Installation Software Installation Software Driver Support The "Software Installation Diskette" supplies drivers for the following operating systems and programs. Windows 3.1 Windows NT AutoCAD PCAD 6.0 WordPerfect Lotus 1-2-3 V3.x Windows 95 ( available in the future ) Making Backup Disks Please make working copies from these installation disks and store the original disks for backup pur- poses.

  • Page 16: How To Install Iga1680 Drivers

    How To Install IGA1680 Drivers ? To begin installation, insert the "IGA1680 Utilities & Drivers Diskette" or "IGA 1680 Windows 3.x Drivers Diskette" in drive A: ( or drive B:). This will initiate the installation process for the Windows 3.1, Windows NT, OS/2 2.1 & Warp, AutoCAD, PCAD, WordPerfect, Lotus 1-2-3 V3.x, and IGA1680 Utilities.

  • Page 17: Microsoft Windows 3.1 Drivers

    Microsoft Windows 3.1 Drivers This make installation more user friendly. The installation disk provides an easy ways for Windows 3.1 driver installation. Before you install the windows 3.1 drivers, make sure that you change your display setting to standard VGA mode. Installing the Windows 3.1 Drivers from Windows Step 1.

  • Page 18: Installing Windows Nt 3.1 & Nt 3.5 Display Drivers

    Installing Windows NT 3.1 & NT 3.5 Display Drivers To install the drivers under Windows NT 3.1: Step 1. Run Windows NT (Assume Windows NT 3.1 has been installed in your hard drive). Step 2. Run Windows NT SETUP program in MAIN window. Step 3.

  • Page 19: To Install The Drivers Under Windows Nt 3.5

    To install the drivers under Windows NT 3.5: Step 1. Run Windows NT (Assume Windows NT 3.5 has been installed in your hard drive). Step 2. Double Click on DISPLAY icon in Control Panel. Step 3. Select “Changing Display Type”. Step 4.

  • Page 20: Os/2 2.1 & Warp Drivers Installation

    OS/2 2.1 & Warp Driver Installation HOT-137/HOT139 IGA1680 OS/2 2.1 & Warp Display Driver Installation: Step 1. Install InteGraphics IGA1680 Graphics Card in your system. Step 2. Install OS/2 Operating System in normal VGA mode. Step 3. Open a DOS full screen session. Insert "IGA1680 Utilities & Drivers Diskette" into driver A...
  • Page 21 Step 7. Follow the instruction to proceed installation. When ‘Display Driver Install’ dialog box appears, select ‘Primary Display’ and then click on the O.K. button. Step 8. When ‘Primary Display Adapter Type’ dialog box appears, select “InteGraphics Systems, Inc. IGA1680” and then click on the O.K. button. Step 9.
  • Page 22 Remove floppy diskette and reboot your system. If you have a high quality monitor and you want to run it at a higher refresh rate, you could do it by following the above procedure to select a higher refresh rate. But, remember to run the command “svga on dos”...

  • Page 23: Installing Autocad Drivers

    Installing AutoCAD Drivers Driver File: RCP_IGS.EXP To install the driver: Step 1. Insert the "IGA1680 Utilities & Drivers Diskette" in drive A: Step 2. Go to drive A: Step 3. Type A:\SETUPDOS <Enter> Step 4. The IGS installation menu will be displayed on screen Select "AutoCAD", and double click.

  • Page 24: Installing The Lotus 1-2-3 Drivers

    Installing the Lotus 1-2-3 Drivers Driver Files: 1) LIGS1024.DLD - 1024x768 16 colors 2) LIGS800.DLD - 800x600 16 colors Configuration Files: a. VGA831CC.VBD b. VGA843CC.VBD for 800x600x4 c. VGA875CC.VBD d. VGA140CC.VBD e. VGA154CC.VBD for 1024x768x4 f. VGA196CC.VBD To install the drivers: Step 1.
  • Page 25 Step 5. After you've done with step 4. The installation program will ask you if all the utilities will be O. K. to install in C:\LOTUS directory. To continue by pressing <Enter> key. Step 6. Directly copy LIGS1024.VRS, LIGS800.VRS and *.VBD configuration files into Lotus123 directory.

  • Page 26: Installing Pcad Drivers

    Installing PCAD Drivers Driver Files PVGA800.DRV - 800x600 16 colors PVGA1024.DRV - 1024x768 16 colors PVGA1280.DRV - 1280x1024 16 colors To install the drivers: Step 1. Insert the "IGA1680 Utilities & Drivers Diskette" in drive A: Step 2. Go to drive A: Step 3.
  • Page 27 Step 7. Modify PCADDRV.SYS (usually located in root directory, e.g. at c:\): Use any text editor to change the following two lines: PDISPLAY C:\PCAD\DRV\DIBMVGA.REX DISPLAY C:\PCAD\DRV\DTEXT.DRV to one line below: DISPLAY C:\PCAD\DRV\PVGA1024.DRV Note: The above change is for 1024x768 resolution and does similar changes for 800x600 or 1280x1024 resolution.

  • Page 28: Installing Wordperfect 6.0 Drivers

    Installing WordPerfect 6.0 Drivers Driver Files: 1) Graphics Drivers: IGS1024.VRS - 1024x768 16 colors IGS800.VRS - 800x600 16 colors 2) Text Drivers: TIGS.VRS - IGS 80x60 16 colors IGS 132x25 16 colors IGS 132x43 16 colors IGS 132x50 16 colors IGS 132x60 16 colors To install the drivers: Step 1.
  • Page 29 Step 5. After you've done with step 4. The installation program will ask you if all the utilities will be O. K. to install in C:WP directory. To continue by pressing <Enter> key. Step 6. Directly copy IGS1024.VRS, IGS800.VRS and TIGS.VRS to WordPerfect 6.0 directory. Step 7.

  • Page 30: Installing Iga 1680 Utilities

    Installing IGA 1680 Utilities The IGA1680 utilities installation program is included inside the "Software Installation Diskette". The IGA1680 utilities have included the following functions: SETMODE.EXE : Set VGA and SuperVGA mode utility. SETFREQ.EXE : Set monitor refresh rate utility. FREQ.EXE : Refresh rate read back utility.

  • Page 31: Windows Drivers Setup

    HAPTER Windows Driver Setup Windows Driver Setup IGA Windows Driver Setup The Integrated Graphics Accelerator (IGA) is a 64 bit high performance Windows Graphics User Inter- face Accelerator. Its powerful hardware graphics drawing engine provides the fastest speed for running Windows applications.

  • Page 32: Normal Setup

    Normal Setup To setup your IGA Graphics Accelerator without Virtual Desktop, you have to make sure that the check box "Virtual Desktop Enable" is unchecked. For normal setting up, you have four parameters to select for configuring your IGA Graphics Accelerator: resolutions, refresh rates, color depths and font sizes. The highest resolution you can choose is 1600x1200.
  • Page 33 Step 2. Use the combo box "Color Depth" to choose a color depth. For most software and appli- cations, 256 colors will be a good choice. If you need to display real life video or photo, you may need 64k or even 16.7 million colors. Step 3.

  • Page 34: Configure Virtual Desktop Environment

    Cofigure Virtual Desktop Environment The IGA Graphics Accelerator is a powerful graphics interface card. A 2 Mb board can support as high as 1600x1200 resolution in 256 colors. But, a monitor running at that high resolution may cost a lot of money.
  • Page 35 Step 3. Use the combo box "Viewport Size" to choose a display mode for your monitor -- a resolution and refresh rate combination. This is the actual resolution and refresh rate that your monitor will work on. The setup program has a few default display modes. If those default display modes do not satisfy your requirement, please refer to Define Viewport Mode for defining your own Viewport modes.

  • Page 36: Accept Selection

    Accept Selection When you finish your setup, you can simply click on the " OK" button to accept your selection. The setup program will modify system.ini and win.ini files in your Windows directory (the driver and other font files should already be copied to your system by the installation program). If you are running virtual desktop, you can use the setup program to switch your Viewport from one resolution to another on the fly.

  • Page 37: Define Viewport Mode

    Define Viewport Mode The button "Define Viewport Mode" will bring you another dialog window to assist defining Viewport modes for your virtual desktop. The left list box of the dialog window has all the modes available for IGA graphics accelerator. In the right list box are the modes you defined for your Viewport.

  • Page 38: Display Screen Centering

    Display Screen Centering The Screen Centering provides an easy way to adjust the position of your screen on the monitor. The program not only centers the screen, it will also record the position you have set into a file. This is particularly useful when using virtual desktop to switch from one resolution to another resolution.

  • Page 39: Virtual Desktop Control

    Virtual Desktop Control The program "VD Control" (Virtual Desktop Control) is a convenient tool for virtual desktop users to do their daily work in virtual desktop environment. When the program starts, it will freeze the Viewport even you did not set your Viewport to be freeze. By moving the small red rectangle in the program control panel, you can easily move your Viewport around the virtual desktop.

  • Page 40: Video Mode Table

    When discussing color depth, 8 bits per pixel (8bpp) is the same as 256 colors, 16 bits per pixel (16bpp) is the same as 65,000colors, and 24 bits per pixel (24bpp) is the same as 16.7 million colors. HOT-137/ 139 also supports 15bpp (32000 colors). Any resolution and refresh settings that support 16bpp will support 15bpp.
  • Page 41 IGS Mode Vesa Mode Refresh Memory Resolution Color (Hex) (Hex) Rate(Hz) Size 80 x 60 Char 256KB 132 x 25 Char 256KB 132 x 43 Char 256KB 132 x 50 Char 256KB 132 x 60 Char 256KB 1280 x 1024 1280 x 1024 87 ( I ) 1024 x 768...
  • Page 42 IGS Mode Vesa Mode Refresh Memory Resolution Color (Hex) (Hex) Rate(Hz) Size 1024 x 768 1024 x 768 1024 x 768 1024 x 768 87 ( I ) 1280 x 1024 1280 x 1024 87 ( I ) 1600 x 1200 1600 x 1200 87 ( I ) 640 x 480...

  • Page 43: Windows Drivers Setup

    PPENDIX Analog Color Display Pinouts Analog Color Display Pinouts Table listed below shows the IGA1680 GUI accelerator analog color display pinouts. Function Note 1: Analog monochrome type monitors use Red Video note1 green video for all video input and ignore Green Video note1 red video and blue video.
