Industrial Automation
FAQ – AC Motor Drives
Delta Electronics (Netherlands) B.V.
De Witbogt 20, 5652AG, Eindhoven, the Netherlands
Technical Support contact:
iatechnicalsupport@deltaww.com
www.delta-emea.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VFD Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Delt VFD Series

  • Page 1 Industrial Automation FAQ – AC Motor Drives Delta Electronics (Netherlands) B.V. De Witbogt 20, 5652AG, Eindhoven, the Netherlands Technical Support contact: iatechnicalsupport@deltaww.com www.delta-emea.com...

  • Page 2: Table Of Contents

    Table of Contents VFD series AC Motor Drives ··························································································3 Motors ·················································································································· 10 VFD-E ·················································································································· 15 VFD-L ·················································································································· 42 VFD-EL ················································································································ 45 C2000/CP2000/CFP2000 ························································································· 48 C200 ···················································································································· 69 MS300 ················································································································· 71 ME300 ················································································································· 77 VFD-ED ················································································································ 78 EMC-PG01O ········································································································· 78 Brake Units ··········································································································· 78 CMM-EIP01···········································································································...

  • Page 3: Vfd Series Ac Motor Drives

    VFD series AC Motor Drives What does the line start lockout function do? If Line Start Lockout is disabled, the AC motor drive will run when mains power is switched on if a RUN command was present at power off.
  • Page 4 Where can I find CAD drawings of the VFD series? You can find them on Delta’s download center. How to read/write parameters via serial communication? Which address to use? To read/write parameters in the drives via serial communication, the parameter number is also the address.
  • Page 5 more non-linear the response becomes, see the curves. As an engineering rule of thumb “a” should be ≤0.1 to have an acceptably linear response, although ≤0.2 is also often accepted. The next consideration is the current that can be supplied by the 10V terminal. This gives the minimum allowed potentiometer value.
  • Page 6 At 20mA the input voltage is 5V So the total supply voltage must be ≥13V (5VDC + 8V The supply voltage must be able to supply at least 20mA. Internal power supply In general the 24V power supply terminal can be used, except on VFD-L, VFD-M, VFD-S (A and D version) and VFD-VL.
  • Page 7 What are the available control modes in the different drives? Series C2000 CP2000 C200 * V/F+PG Sensorless Vector+PG FOC+PG for IM FOC+PG for PM TQC+PG for IM TQC+PG for PM FOC Sensorless PM Sensorless TQC Sensorless What is the slip compensation parameter? The slip to be compensated in all our drives is calculated as follows: where Slip = slip to be compensated...
  • Page 8 What is the maximum output frequency with the 599Hz limitation? - In VF Mode the maximum output frequency is 599Hz. - In SVC or Vector Mode the maximum output frequency, including slip compensation, is 599Hz. Therefore the max frequency command is 599Hz-Slip ! - In FOC mode (C2000) , the max frequency command is limited to (F + Pr10- 29)≤599Hz, to make sure the actual output frequency is limited to 599.00Hz.
  • Page 9 The maximum cable section that these terminals can accommodate is 12AWG or The minimum cable section that these terminals can accommodate is 18AWG or 0.75mm Because the terminals of a frame size are always the same, it means that the power terminals of any ME300 in Frame B can accommodate a wire section between 0.75~4mm The actual wire section, that should be used, depends on the application: Current and...

  • Page 10: Motors

    Motors Can a 230V 3-phase motor be driven by a 400V drive? Yes, no problem. Just set the Max. Output Voltage Pr01-02=230V. The output rms voltage is in this case 230V but the peaks are still 560V (from the DC- bus).
  • Page 11 Do I need to connect the shielding on one end or on both ends? - Motor power cables need to be connected on both ends. - Encoder and control cables need to be connected only at one end. In both cases, the cable shield needs to have a 360° connection. Below are some examples of proper shielding connection.
  • Page 12 In order to enable these PID functions it is necessary to use the Special M contacts below. A working example of such a PID function.can be found on our ftp site (Industrial Automation Products\_Delta Application Guide\General information\Built-in PID function). How to read/write from/to the onboard PLC through Modbus TCP and Ethernet For the CMC-MOD01 and CMC-EIP01 cards this is supported starting with firmware V1.08 (date code: W1852).
  • Page 13 In C/CP2000 and MS300: What is the difference between M1042 Quick Stop and M1044 Pause in the PLC? Quick Stop M1042 = 1: Drive will stop with the shortest possible deceleration ramp. M1042 = 0: Drive start enabled. The drive will not restart by itself. Pause M1044 = 1: The drive will stop with the normal deceleration ramp.
  • Page 14 Series Code 2110h High byte 2110h Low byte Type VFD-M VFD-S VFD-B VFD-L VFD-V/VE VFD-F ID (as in Pr00-00) VFD-E VFD-E-C VFD-EL VFD-VL VFD-DD VFD-ED 14 of 81...

  • Page 15: Vfd-E

    VFD-E How to use the PTC function? Please ask for the application note “VFD-E PTC.pdf”. It shows how to set up the VFD- E for use with PTC acc. to DIN44081/44082 for motor protection. Can an option card be used together with a fieldbus option on the VFD-E? Yes, there is room for one option card and one fieldbus option, which can be mounted together on the VFD-E.
  • Page 16 Dipswitch 2 (Free run to stop) This sets the stop mode. Its identical to setting Pr02 -02=1. It means the stop mode is free run or coast. Dipswitch 2 = OFF When keypad connected Pr02-02 can be set as needed. Dipswitch 2 = ON Pr02-02 is set to 1 automatically and when keypad connected other setting results in "Err"...
  • Page 17 What is the function of the dipswitches ACI/AVI? Dipswitch ACI/AVI Normally when you set Pr02-00=2 to select ACI/AVI2 and Pr04-19=0 (ACI) or 1 (AVI2), you can select with the dipswitch ACI/AVI the input to be ACI with 4-20mA or AVI2 with 0-10V. In case you want to use AVI2, you need to set Pr04-19=1, then Pr02- 00=2, then set switch ACI/AVI=AVI to avoid "AErr"...
  • Page 18 program by reading D1028, then it doesn’t work for frequency command anymore. In that case, the PLC program needs to include functionality to let the AVI input also function for frequency command. How to save variables in the PLC at power off? The VFD-E PLC cannot save variables when it is power off.
  • Page 19 How to set a negative slope in AVI-input? This is not possible. The parameters Pr04.00 ~ Pr04.03 can only be used to set Bias and Gain of the front potentiometer on the keypad. In the examples, however, it is inadvertently suggested that it also is possible for the AVI-input.
  • Page 20 displayed.The required action in case the signal is lost can be set in Pr10-09. Pr10.09=0. When feedback on ACI is lost, display shows blinking "FbE" and  ramps to stop after 60s, after reconnecting ACI it remains blinking. Press reset, give new RUN command, and it runs again.
  • Page 21 How to connect the new PLC editor WPLSoft to VFD-E? If you haven’t done so, please download the latest version of WPLSoft from our website and install it. Step 1: Start the program. Step 2: Open Options/Communication Setting Step 3: Select RS-232. If you use VFD-USB01, please connect your computer to the VFD-E.
  • Page 22 Step 7: Open a project with File/Open. Step 8: Select Options/Change PLC Type and select VFD-E and press OK. Note: VFRD-Eplus now has 500 steps (was 350) Step 9: On VFD-E press the MODE key several times until the display shows [PLC0]. With the ...
  • Page 23 Step 10: Select Communication/Transfer Setup. Step 11: Select PC => PLC and press OK Step 12: The transfer progress is shown as follows: Step 13: After completion of the transfer please set VFD-E with the  or  keys to [PLC1] and press ENTER for standalone operation or leave at [PLC2] for online operation and monitoring.
  • Page 24 Can individual inputs be inverted, so they can be operated from NC contacts? Yes, refer to the user manual, Pr04-09. Normally they are set for NO (Normally Closed) contacts (input is activated when contact is closed). Please see the example below: Inputs MI2 and MI5 too be set for NC (Normally Closed) contacts, e.g.
  • Page 25 is 47k/3=15.67kΩ. (Or, each input takes 10V/47k=0.2mA. Three inputs in parallel take 3x 0.2mA = 0.6mA, well below 2mA). It is best to tune the AFM output to have exactly 10V at 50Hz (or max freq) by Pr03.04. Then, to tune each AVI input to give 50Hz at 10V by using Pr04-13 and Pr04-14. This way gives much better performance and linearity.
  • Page 26 How can I read the EME-A22A analogue inputs in the PLC? AI1 can be read in D1031 and AI2 can be read in D1032. What does fault code 42“AcL” mean? “AcL” means communication error between power board and control board in STOP mode and “CP10”...
  • Page 27 EME-A22A: How to set 4-20mA for the analogue inputs? Please refer to Pr12.20 and Pr12.23 in the manual (Sensorless Vecotr Control Compact Drive VFD-E Series user manual) to select 0-20mA or 4-20mA. When Pr10-01=1, the PID set-point is via front potentiometer, but the manual says via UP/DOWN keys, why? This is an error in the manual (Sensorless Vecotr Control Compact Drive VFD-E Series user manual).
  • Page 28 If needed the AFM output voltage can be adjusted by Pr03-04. How to use preset speed as PID setpoint? The preset speeds can be used as follows as PID setpoint. Pr05-00=15 Preset speed 1=15Hz Pr05-01=25 Preset Speed 2=25Hz Pr05-02=35 Preset Speed 3=35Hz (to have 3 set points) Pr04-05=1 MI3=Select Preset Speed 1 Pr04-06=2 MI4=Select Preset Speed 2...
  • Page 29 On EME-D33A, is it possible to switch between NPN and PNP? The inputs can be switched from NPN to PNP by the switch. The outputs are NPN only with MCM as common. How to read the analogue inputs and outputs of EME-A22A? Both inputs and outputs can be read via the following PLC registers (it is not possible to read them directly via Modbus): D1031...
  • Page 30 starts running when the power comes back, provided there’s an active RUN command. How to display the motor speed in rpm? To be able to display the speed in rpm, an encoder must be used (and the option card EME-PG01). Pr00-04=14 (Press MODE until display shows [G xxx].
  • Page 31 How to set a digital input for NC operation? Normally the digital input is activated when the input is closed (to DCM for NPN inputs or to 24V for PNP inputs). Sometimes it is useful to activate an input when its contact is opened (NC operation), For instance, when an input is used for EF and the connected switch (or clixon) opens in case of a fault.
  • Page 32 Which brake resistors to use for VFD-E ? The brake resistors are given in the VFD-E manual (Chapter B1) but not all types are specified or stated. You can either buy it locally or "build" them from several individual brake resistors. Please also refer to the Datasheet Brake Res Version8 Mar2019.pdf on the ftp-site (Industrial Automation Products\AMD-Options\AMD Brake units &...
  • Page 33 Is it possible to use CME-USB01 to connect to WPL and at the same time use RS-485 port for control of the drive (by an external PLC or even VFDSoft)? Yes, they can be used at the same time. After OV fault the drive doesn’t restart. Why? E.g.
  • Page 34 When is FbE fault generated? FbE (feedback error) is generated when the signal on ACI (4-20mA) is lost (input < Pr04-15 during > Pr10-08 seconds). In Pr10-09 you can set the response. When Pr10-09=2, the drive keeps running and FbE is automatically cleared when feedback is normal again. When Pr10-09=0 or 1, the drive stops and you have to reset.
  • Page 35 What is the effect of the S-curve settings? Pr01-17 must be smaller than Pr01-09/01-11 and Pr01-18 must be smaller than Pr01- 10/01-12. Higher values of Pr01-17/01-18 will have no effect. Why does DC-braking not work at start-up? When started with frequency command < F , DC braking doesn’t work.
  • Page 36 How to reset VFD-E with a Modbus Multi-write instruction? 01 10 2000 0003 06 0011 1388 0002 Doesn’t allow to reset the drive, gives error message. 01 10 2000 0003 06 0000 1388 0002 Allows to reset the drive. How to set the PLC registers D1041 and 1042? The PLC registers D1041 (AO1) and D1042 (AO2) can be set as follows: Set switch to 0~10V: D1041 = 0000hex ...
  • Page 37 What is the function of register 210Ch~210Fh ? 210Chex: AVI 0~3FFhex or 0~1023dec 210Dhex: ACI or AVI2 0~3FFhex or 0~1023dec 210Ehex: ACI2 or AVI3 0~FFFhex or 0~4092dec 210Fhex: ACI3 or AVI4 0~FFFhex or 0~4092dec EME-PG01: What is the number of output pulses on A0 and B0? The ratio of input/output pulses is 1:1.
  • Page 38 What is the 2101h bit assignment? Bit 7 shows “reserved” in the manual but its assignment is Operation via External Terminals. When Bit7=1, operation is via external terminals. The other bits “reserved” are not assigned. VFD-E brake units: BUE or VFDB? In the VFD-E user manual (Sensorless Vector Control Compact Drive VFD-E Series User Manual), the brake units are stated as VFDB.
  • Page 39 How to activate an output/relay in case of a warning? Set Pr03-00/03-01=20. Why does Pr07-01 display the wrong value? This is a bug in firmware 1.23/2.23. After setting Pr07-01, it shows the wrong value after power off/on. The internal value of Pr07-01 is still correct, only the display value is wrong.
  • Page 40 This is “Detection Current Level”. 100% is drive rated current. Setting range 0~100.0% with default 2.0%. When the setting is 0.0%, there’s no OPL detection. When Pr06-13=1, the drive will decelerate (ramp down) by DC-braking (This is the only way because only 2 phases are available). The DC-brake current level is set in Pr08-00.
  • Page 41 Press STOP (Bit 1) Press UP (Bit 5) Press DOWN (Bit 6) Press MODE (Bit 0) Press ENTER (Bit 7) 41 of 81...

  • Page 42: Vfd-L

    VFD-L Can the digital inputs be operated from 24V? Yes, this is possible. VFDxxxL21A or ...B: They have NPN inputs that are activated by shorting them to ground. VFDxxxL21D or ...E: They have PNP inputs. Either the internal 15V or an external 24V supply can be used.
  • Page 43 Bug: Pr09-02 and Pr09-03 do not work. When Pr09-02=1 or 2 and Pr09-03=1s (or other value), when the drive communication is interrupted (by pulling the connector for example, nothing happens. Acc. to manual the drive should stop after Pr09-03 time. But it doesn’t work. Why does VFD-L2 show cF2 after power on? When the value of Pr07-01 >...
  • Page 44 What is the class and max. motor length for VFD-L2? For VFDxxxL21B/E the class is EN61800-3:2011 C2 with 10m shielded motor cable both for conducted and radiated emission. How do Pr06-02, 06-03 and 06-04 work together? OL2 happens always when output current >Pr06-03 for time Pr06-04 and the conditions below are met.

  • Page 45: Vfd-El

    VFD-EL Pr00-03 setting is different in the summary and description, which one is right? There is a difference in the settings for Pr00-03 in the Summary of Parameter Settings and in the Description of Parameter Settings. The latter is correct. It will be corrected in the next version of the user manual.
  • Page 46 When are parameters saved in EEPROM? We save the parameters in EEPROM at power off, except some special frequently written parameters, such as Fcmd & Fpid. They are written in RAM. How to set Pr10-00 for PID set-point? In VFD-EL Pr10-00=1 means it follows Pr02-00 setting. Pr10-01=1 and: Pr02-00=0: Setpoint via keypad UP/DOWN Pr02-00=1: Setpoint AVI (same as Pr10-00=2)
  • Page 47 SG+ & SG- are for RS-485 communication wiring For multi-pump communication application, we could only connect SG+ ,SG- ,GND(option) with customized RJ45 or RJ11 cable, or use CAT5 cable cutting off pin2(EV). CAT5 A or B cross-over cables cannot work. What is DEV fault? DEV means the PID feedback deviates too much from the setpoint.

  • Page 48: C2000/Cp2000/Cfp2000

    C2000/CP2000/CFP2000 WPL cannot make connection to C2000. Why? Please check the setting of Pr09-35. The default station address for PLC is 2. You need to select station address 2 when setting up the connection to WPL *VFDSoft uses station address 1 (as set in Pr09-00). Which elements are supported by KPC-CC01? In the latest firmware KPC1021-20110720 and higher, the following elements are available.
  • Page 49 Support constant setting and jump page only , The Call function Buttons and User level are not available The setting of refer device is useless , cause the keypad have Clock display build-in RTC Multi-status bitmap Support bit type of device only Unit Totally supported When the referred value is from PLC then the integer/decimal...
  • Page 50 How to set a range of 42~50Hz on the AVI analogue input? Due to the limited bias range of -100% to +100% Pr03-03, it is not possible to set this range of 42~50Hz.Therefore an alternative way of scaling the analogue inputs by setting 3 points is introduced in C2000 and CP2000.
  • Page 51 Pr05-00=6: For IM motor dynamic auto-tuning. You can get the motor parameters , Lx and no-load current and the field weakening flux table. This is for FOC Sensorless mode. The motor runs and must be unloaded. Pr05-00=12: For IM motor inertia auto-tuning in FOC Sensorless. After finishing Pr05-00=6 auto-tuning, if you want to use Pr11-03, Pr11-04, and Pr11- 05 as ASR, you must set Pr05-00=12 for inertia auto-tuning.
  • Page 52 Select the right COM port and press OK. If a table is already loaded, then a message will pop up and ask if you want to save it. Then, the transfer begins and the table is read into VFDSoft until Completed 100%. After connecting the keypad again to the drive, via MENU, 2.
  • Page 53 How do Sleep and Wake-up work in CP2000? The relevant parameters are: There are 3 different Sleep/Wake-up modes: 1. Frequency command (PID off, Pr08-00=0) When the Frequency Command < Sleep Frequency, the output frequency will remain at the sleep frequency. Once the setting of Pr08-12 Sleep Time is reached, the drive will go to sleep at 0Hz.
  • Page 54 3: Percentage of PID’s Target Value (Set PID, Pr08-00 ≠ 0) Once reaching the percentage of PID’s target value and the percentage of the feedback value, the motor drive starts to calculate the sleep time. The output frequency decreases immediately. If the motor drive passes the preset sleep time, it will go to sleep at 0Hz.
  • Page 55 What is the effect of motor cable length on motor insulation? When the motor is driven by an AC motor drive with PWM modulated output voltage, the motor terminals will experience surge voltages due to cable capacitance. When the motor cable is very long (especially for the 460V series), surge voltages can reduce the insulation quality.
  • Page 56 How to connect Open Collector signals to PG card Channel 2? Please refer to the following diagram for wiring information. V depends on type of encoder card. Pull-up resistor: 1~2kΩ 0.5W Can EMC-BPS01 also be used in CP2000? Yes, but the info is not in the user manual. Please consult the info in the Delta Vector Control Drive C2000 Series User Manual.
  • Page 57 You can use two methods: 1. Pr03-50=0 (default setting). In that case you use bias and gain for AVI1. Pr03-11=166.7% (=10/6) The feedback range is now 0~6.00bar for the 0~10bar sensor. (or 0~6.000bar) 2. Pr03-50=1. To set AVI1 via 3 points. Pr03-51=0V Pr03-52=0% Pr03-53=3V...
  • Page 58 price list. Are C/CP2000 suitable for flange mounting on a panel for heat dissipation? See Delta Vector Control Drive C2000 Series User Manual and Delta Fan/Pump Vector Control Drive CP2000 Series User Manual - Chapter 7 for the flange mounting kits for Frame A~C: MKC-AFM(1), -BFM, -CFM.
  • Page 59 What is the relationship between duty and the max. output frequency on C2000? Contrary to what is stated in the manual, it is: Valid for firmware 1.20. How to control AFM1&2 via Modbus? There are no Modbus registers to directly control AFM1&2. But it can be done in this way: Please follow the steps below: Set Pr 03-20/03-23 = 23 for constant voltage.
  • Page 60 How to read the kWh value in Pr05-28~05-30? Pr05-28 shows the Wh value in xxx.x Wh. When it exceeds 1000.0Wh, Pr05-28=0 and Pr05-29 is incremented. Pr05-29 is kWh low word from 0~65535 (the decimal point has no meaning). When it exceeds 65535, it becomes 0 and Pr05-30 is incremented.
  • Page 61 Fan control: Can changing ID cause damage? C/CP2000 Frame A and B have on/off fan control. Frame C and up have PWM fan control. When the ID is (re)set on a Frame A and B drive to e.g. prepare the control board for a drive of Frame C and up, the fan control changes but it won’t cause any damage.
  • Page 62 RY13 Pr02-39 2016-41 Bit8 RY14 Pr02-40 2016-41 Bit9 RY15 Pr02-41 2016-41 Bit10 Fieldbus option Output Setting 52 for: Register Pr02-13 H2640 Bit0 Pr02-14 H2640 Bit1 (CP2000 only) Pr02-15 H2640 Bit2 (C2000 only) Pr02-16 H2640 Bit3 (C2000 only) Pr02-17 H2640 Bit4 MO10/RY10 Pr02-36 H2640 Bit5...
  • Page 63 The correct way to address this is by using the function block below to write in the Inter-Com master PLC program: This FB is written in the master PLC and it is used to write a value inside one of the slave drives as follows: S1 = Select Slave 1 S2 = Device (0: converter, 1: internal PLC)
  • Page 64 What does fault CE3 mean? What is the function of Pr08-15? Contrary to what’s in the C2000 and CP2000manual, Pr08-15 is reserved and has no function. What is the function of Pr03-14 in C2000? Pr03-14 sets the gain for the negative input on AUI. If you put a negative value to the negative input, you will get a positive gain.
  • Page 65 How to copy the PLC program into the keypad? For C family, we need to disable PLC first. Please see the steps below: Disable PLC On the keypad, go to Menu #4 PLC. Then, select 1=Disable PLC Upload PLC program On the keypad, go to Menu #5 Copy PLC and select the file (001, 002, etc).
  • Page 66 The heatsink fans are always controlled by Pr07-19, the capacitor fan acc. to the table. Is it possible to run the C2000 in torque mode and use a pulse train as speed limit? Yes, this is possible by setting the following parameters: Pr00-20 = 4 or 5 Pr11-36 = 2 Pr10-16 = 1 ~ 5 (depending on the type of pulses you are using)
  • Page 67 What is the compatibility of CP2000 firmware and CMC-EIP01/-MOD01 option cards? There is a compatibility issue between the newer CMC-EIP01/CMC-MOD01 cards and the older CP2000 firmware. When a card with firmware version 1.08 or newer is placed on a CP2000 firmware version 2.03 or older, the card will not be recognized (Pr09-60=0) Solution: Update the CP2000 firmware to the latest version V2.06.
  • Page 68 The minimum settings required to enable this function are: - Pr06-82=1 and Pr06-83≠0 - One relay output must be set to function 54. This will be the function that controls the contactors that switch the motor to mains supply - Parameter 06-83 is the delay time from when a fault occurs to when the drive enables Bypass: - In addition, the drive can attempt to auto-reset the fault that occurred during fire mode and prevent it from going into Bypass mode.

  • Page 69: C200

    C200 Is Pr02-11 Digital input response time also valid for MI7, 8? Yes it is. However, when encoder feedback is used (Pr10-02≠0), Pr02-11 is disabled for MI7&8. How to select RS-485 Modbus or CANopen? When Pr09-36=0, CANopen is disabled and RS-485 Modbus is enabled. When Pr09-36≠0, CANopen is enabled by assigning a CANopen slave address and RS-485 Modbus is disabled.
  • Page 70 - D1058 Starts MI8 counting Read/Write - D1059 Reset MI8 count value Read/Write For the last step, the internal PLC instruction FREQ will send a frequency command to the drive. Note: C200 doesn’t support PG cards. Once MI7 and MI8 are used for pulse train frequency commands, the drive cannot support closed-loop operation.

  • Page 71: Ms300

    MS300 What does Pr07-20=5 (System deceleration) mean? For MS300, there is the function Forced to stop (Pr02-01 ~ 02-06 = 18 or 10). Then, Pr07-20 needs to be set. Pr07-20=5 means the drive stops with the actual deceleration time. What is the crane function (MO=42)? The crane function is as follows.
  • Page 72 How to set pulse train frequency command? Set the following parameters to use a pulse train as frequency command:. - Pr02-07=0 (MI7 no function, therefore can be used for pulse train input.) - Connect a 24VDC pulse train signal to MI7 (PNP or NPN depending on wiring). The max.
  • Page 73 In firmware 1.05 3 additional settings were introduced for Pr02-00. Select 4-5-6 instead of 1-2-3 to avoid this problem. The response with these settings is faster and with higher initial output voltage. ►Pr00-21≠1 Operation command not via terminals - Select Pr03-50≠0. - Using AVI or ACI:0~10V: Set Voltage Lowest Point to 1V (Pr03-57 or 03-63).
  • Page 74 How to wire for Y-Δ switch-over? The picture as shown for Pr05-25 in the user manual is for indication only and is not complete. Here’s how it should be connected. This applies also to C/CP/CFP2000. What is the difference between the Traditional OV stall prevention (Pr06-02=0) and the Smart OV stall prevention (Pr06-02=1)? Over Voltage stall prevention is a function commonly used in applications where the goal is to decelerate the motor as quickly as possible without using a braking resistor.
  • Page 75 In smart OV stall, during Acceleration/Deceleration/Normal state, the drive will maintain and/or increase the output frequency when the VDC > Pr06-01. When VDC<Pr06-01 the drive will change the slope by which it decelerates (Hz/s not constant). In this mode the drive will calculate a new deceleration slope with the aim of maintaining a stable DC bus voltage.
  • Page 76 Mounting position 2 (Frame A~D) Cable Why do I get LV-error even if the voltage is >LV-level (supplying 230VAC to a 400V drive)? In Pr06-00 you can set the LV-level. For a 400V drive, the minimum setting value is 300VDC. When the drive is supplied with 230VAC, the DC-bus voltage is around 230*√2=325V which is higher than 300V so LV is not expected.

  • Page 77: Me300

    How to use the TORQ command in the PLC? The TORQ command works in the same way as in C2000. ME300 What class and motor cable length for the ME300 built-in filter? 230V 1phase: Class C2 20m shielded motor cable. 400V: Class C3 30m shielded motor cable.

  • Page 78: Vfd-Ed

    VFD-ED How to connect the encoder in case of non-differential signals? If the encoder only has non-differential output signals A1, B1, and Z1, please do the following: Connect the encoder signals to the inputs A1, B1, and Z1. Connect the unused inputs /A1, /B1, and /Z1 to DCM to avoid interference problems. EMC-PG01O How to connect an encoder with OC outputs to EMC-PG01O? The encoder outputs A, /A, B, /B, Z, /Z should be connected to the following pins of...

  • Page 79: Cmm-Eip01

    The dipswitch Master-Slave tells the unit if it is used as master or slave. When it is used as the master, it responds to the DC-bus voltage. When it is used as the slave, it responds to slave input (S1-S2) which has to be connected to the masters M1-M2 output.

  • Page 80: Afe Series Active Front End

    AFE Series Active Front End AFE2000 To reduce harmonics we want to use AFE2000. We do not need regeneration; do we still need the input reactor? Yes, AFE2000 does not only reduce harmonics, correct the power factor and regenerate braking energy back into the mains power supply, but also stabilises its DC output voltage.
  • Page 81 Does AFE start running if MI1 is active at power on? Yes. Which fuses are recommended? Each drive must be fused at the DC-bus terminals. Please select the fuse value acc. to (AC rated input current/0.78)*1.5. We recommend to use fast DC fuses. 81 of 81...
