Summary of Contents for Forte FGRT304
- Page 1 RANGETOP FGRT304 & FGRT366 & FGRT488 INSTALLATION GUIDE SPECIFICATIONS, INSTALLATION, AND MORE...
- Page 2 Thank you for choosing FORTE Appliances. At FORTE Appliances, we are proud to provide you with innovative technology and exceptional quality to simplify the way you live. Among other things, registration of your appliance ensures that we can deliver important product information and warranty details when you need them.
-
Page 3: Table Of Contents
Contents Safety Instructions ……………………………………………………………. 4~5 Installation Instructions ………………………………………………………. 6~13 Cooktop Operation …………………………………………………………… 14~16 Care & Cleaning ……………………………………………………………… 17 Troubleshooting ………………………………………………………………. 18 Ng to LPG Conversion ……..………………………………………………… 19-22 Warranty……..……………………………………….………….......23 WARNING If the information in this manual is not followed exactly, a fire or an explosion may result causing property damage, personal injury or even death. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS Definitions This is a safety alert symbol. It will alert you to potential personal or property safety hazards. Obey all safety messages to avoid any property damage, personal injury or death. WARNING indicates a potentially hazardous situation which, if not avoided, could result in serious injury or death. - Page 5 SAFETY INSTRUCTIONS What to do if you smell gas? Do not try to light any appliance. Do not touch any electrical switch. Do not use any phone in your residence. Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
- Page 6 INSTALLATION AND OPERATION INSTRUCTIONS To ensure proper and safe operation, read all instructions before using the product. Install or locate the product only in accordance with the provided Installation Instructions. All servicing should be performed to a qualified technician. Do not attempt to adjust, repair, service or replace any part of your appliance unless it is ...
-
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS IMPORTANT Keep appliance area clear and free from combustible materials, gasoline, and other flammable vapors. Gas Supply Requirements Installation of this rangetop must conform with local codes, or in the absence of local codes, the National Fuel Gas Code, ANSI Z223.1 / NFPA 54. In Canada, installation must conform to the current natural Gas Installation /code, CAN 1-1.1-M81 and with local codes where applicable. - Page 8 INSTALLATION INSTRUCTIONS Dimensions and Clearances The rangetop may be installed flush to the rear wall. You may install a non- combustible material on the rear wall above the rangetop and up to the vent hood. It is not necessary to install non-combustible materials behind the rangetop below the counter top height.
- Page 9 *Product features may not match. Image meant for dimension reference only.
- Page 10 *Product features may not match. Image meant for dimension reference only.
- Page 11 Installation Electric Power Supply Requirements Your rangetop must be electrically grounded in accordance with local codes or, in the absence of local codes, in accordance with the National Electrical Code (ANSI/NFPA 70, latest edition). In Canada, electrical grounding must be in accordance with the current CSA C22.1 Canadian Electrical Code Part 1 and/or local codes.
- Page 12 INSTALLATION INSTRUCTIONS Grounding The power cord is equipped with a three-prong (grounding) plug which mates with a • standard three-prong grounding wall receptacle to minimize the possibility of electrical shock hazard from the rangetop. • All cord connected appliance shall include instructions relative to location of the wall receptacle and a warning to the user to disconnect the electrical supply before serving the appliance.
- Page 13 Hood/Composite Overlay Install The bottom of the hood should be 30′′ min. to 36′′ above the counter top. This would typically result in the bottom of the hood being 66′′ to 72′′ above the floor. These dimensions provide safe and efficient operation of the hood. After Installation: Check ignition of cooktop burners.
-
Page 14: Cooktop Operation
COOKTOP OPERATION Surface Burner Ignition Push to release gas. Turn to Ignite and ‘Hi’ position. Adjust to appropriate flame height. To light the surface burners, push and turn the appropriate control knob counter clockwise to a “Hi” position. You will hear a clicking noise – the sound of the electric spark igniting the burner. Once burner ignition has been achieved, turn the burner control knob to adjust the flame size. - Page 15 Cooktop Operation Simmer and Boil • A smaller flame will give the best simmer results. Small flames offer precise cooking performance for delicate foods, keeping food warm, melting chocolate or butter, and for cooking that need to cook over low heat for a long time. •...
- Page 16 Cooktop Operation WARNING FOOD SAFETY According to the United States Department of Agriculture: DO NOT hold foods at temperatures between 40 F to 140 F more than 2 hours. Cooking raw foods below 275 F is not recommended. Never use this appliance doors or drawers such as stepping. Leaning or setting on the doors or drawers, may result in hazards and injuries Burner Grates...
-
Page 17: Care & Cleaning
Care and Cleaning Rangetop • To avoid electrical shock or burns, turn off all controls and ensure the cooktop is cool before cleaning. • Before cleaning the cooktop, ensure that all burners are turned off and that all components are cool enough to safely touch. •... -
Page 18: Troubleshooting
Troubleshooting Before you call for service, please review the potential problem / possible causes and remedies shown in the table below. Have an electrician check the Power supply is not energized. Nothing works power supply, including the house circuit breaker, wiring and fuses Make sure the unit is properly Plug on rangetop is not completely connected to the power supply... -
Page 19: Ng To Lpg Conversion
Instructions for Converting Rangetop to Operate on Liquefied Petroleum Gas INSTALLATION AND SERVICES MUST BE PERFORMED BY A QUALIFIED INSTALLER IMPORTANT: SAVE INSTRUCTION MANUAL FOR THE LOCAL INSPECTOR’S USE. INSTRUCTIONS READ AND SAVE THESE FOR FUTURE REFERENCE This conversion kit must be installed by a qualified service technician in accordance with the manufacturer's instructions and all applicable codes and requirements of the authority having jurisdiction. - Page 20 Instructions for Converting Rangetop to Operate on Liquefied Petroleum Gas 1. Convert the Pressure Regulator 2. Convert Top Burner for LP/ Propane Gas To access the gas regulator, pull the rangetop away from the Save the natural gas orifices cabinet wall. The gas regulator is removed from the appliance for possible future located at the bottom right corner conversions to natural gas.
- Page 21 Instructions for Converting Rangetop to Operate on Liquefied Petroleum Gas 5. Convert Gas Valves for LP/Propane Remove control knobs. Using a flat screwdriver, adjust main burner bypass jets toward to ¼ circle for LP until the flame is normal. Care should be taken when removing and replacing gas components. Use proper support to prevent damage to components.
- Page 22 Instructions for Converting Rangetop to Operate on Liquefied Petroleum Gas 6. Reconnect Gas and Electrical Supply to 7. Installation of New LP / Propane Rangetop Rating / Serial Plate Leak testing of the appliance shall be Record the model and serial number conducted according to the installation on the LP / Propane Rating serial instructions provided with the rangetop.
-
Page 23: Warranty
This warranty is null and void if the appliance is used for commercial purposes. FORTE Appliances will not pay for: 1. Service calls to correct the installation of your RANGETOP, to instruct you how to use your RANGETOP, to replace house fuses or correct house wiring or plumbing, or to replace light bulbs other than as noted above.
