M-system B6U-LCD Instruction Manual

INSTRUCTION MANUAL

BEFORE USE ....

Thank you for choosing M-System. Before use, please check
contents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System's Sales Office or representatives.

■ PACKAGE INCLUDES:

LCD Display ........................................................................(1)

■ MODEL NO.

Confirm Model No. marking on the product to be exactly
what you ordered.
■ INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation and basic main-
tenance procedures.
Please refer to the instruction manual of B6U/B6U-B (EM-
7451-A) for detailed procedures of LCD display

POINTS OF CAUTION

■ CONFORMITY WITH EU DIRECTIVES
• The actual installation environments such as panel con-
figurations, connected devices, connected wires, may af-
fect the protection level of this unit when it is integrated
in a panel system. The user may have to review the CE
requirements in regard to the whole system and employ
additional protective measures to ensure the CE conform-
ity.
■ GENERAL PRECAUTIONS
• Before you remove the module or mount it, turn off the
power supply and input signal for safety. Do not touch
connector terminal of the module.
■ AND ....
• The unit is designed to function as soon as power is sup-
plied, however, a warm up for 10 minutes is required for
satisfying complete performance described in the data
sheet.
LCD DISPLAY
(for B6U use)
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
MODEL

COMPONENT IDENTIFICATION

NEXT Key
B6U-LCD
Specifications
Lever
LCD Module
ENTER Key
EM-9182 P. 1 / 2
