36cm 1050W Electric

Tiller

These instructions contain important information that will help you get the best

from your product, ensuring it is assembled correctly and safely. If you need help

or have damaged or missing parts, call the Customer Helpline on 01904 727 509.

53cm Self Propelled Petrol

Rotary Lawn Mower

577184

Instruction

Manual

IMPORTANT!

Please read these

instructions fully before

starting assembly.

Table of Contents

Need help?

Do you have a question about the 577184 and is the answer not in the manual?

Questions and answers

Summary of Contents for PowerBase 577184

Page 1 IMPORTANT! 36cm 1050W Electric Please read these Tiller 577184 instructions fully before starting assembly. These instructions contain important information that will help you get the best from your product, ensuring it is assembled correctly and safely. If you need help...
Page 2: Table Of Contents
Contents General safety warnings Intended use Warning symbols In the box Assembly Preparation Operation Maintenance and repair Troubleshooting Technical data Disposal Getting help Warranty...
Page 3: General Safety Warnings
General Safety Warnings Safety warnings WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Carefully read the instructions for the safe operation of the machine. Save all warnings and instructions for future reference.
Page 4 Safe operating practices for electric tiller IMPORTANT! READ CAREFULLY BEFORE USE KEEP FOR FUTURE REFERENCE Training • Read the instructions carefully. Be familiar with the controls and the proper use of the equipment. • Never allow children or people unfamiliar with these instructions to use this machine.
Page 5 • Thoroughly inspect the area where the machine is to be used, and remove all objects which can be thrown by the machine. • Before using, always visually inspect to see that the blade, blade bolt and the blade assembly are not worn or damaged. Replace worn or damaged components in sets to preserve balance.
Page 6 • Use extreme caution when reversing or pulling the machine towards you. • Do not change the motor governor settings or over speed the motor. • Never operate the machine with defective guards or shields, or without safety devices. • Carefully switch the motor on according to instructions and with feet well away from the cutting mean(s).
Page 7 • If the machine starts to vibrate abnormally, stop immediately and manually: • inspect for damage; • replace or repair any damaged parts; • check for and tighten any loose parts. Maintenance and storage • Keep all nuts, bolts and screws tight to be sure the machine is in safe working condition.
Page 8 Service • Have your machine repaired by an authorised service agent. This machine is manufactured in accordance with the relevant safety regulations. To avoid danger, equipment must only be repaired by qualified technicians. • Only use parts and accessories made for this machine by the manufacturer.
Page 9: Intended Use
Intended Use • This product is designed for small gardens and flower beds; this device effectively loosens and turns over new soil. It may also be used to mix coarse soil with fertiliser, peat, and compost. This product may not be used to till extremely dry or wet soil. The use of this product in rain or wet conditions is prohibited.
Page 10 • Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the machine. Keep the cord away from heat, oil, sharp edges and moving parts. Damaged or entangled cords increase the risk of electric shock. WARNING! This machine produces an electromagnetic field during operation! This field may, under some circumstances, interfere with active or passive medical implants! To...
Page 11: Warning Symbols
Warnings Symbols Caution/Warning. Read operator’s manual. There is a risk that some objects could be thrown out by the machine. Keep bystanders away. Rotating parts may cause serious injury. Make sure the blades come to a complete stop before transporting the machine or before inspecting, cleaning, or conducting any other maintenance.
Page 12 Wear eye protection. Wear hearing protection. Guaranteed sound power level value in 93dB. Recycle unwanted materials instead of disposing of them as household waste. All tools, cables and packaging should be sorted, taken to the local recycling centre and disposed of in an environmentally-friendly way.
Page 13: In The Box
In The Box Parts Right handle 2. Left handle 3. Frame 4. Fixing nuts and bolts x 4 5. Cord clips x 2 6. Screws x 4 Middle handle 8. Motor housing 9. Lower handle 10. Protection guard 11. Blades...
Page 14: Assembly
Assembly WARNING! Always take care when removing the packaging to prevent causing damage to the machine. Remove all parts of the electric tiller from the box and carefully remove all packaging. Take care not to lose any instructions which may be affixed to the parts. These provide important information which will be required when assembling the electric tiller.
Page 15 Assembling the handles Align the upper handle frame with the middle handle. Use the nuts and bolts to fix the upper and middle handles firmly together. Align the middle handle frame with the lower handle. Use the nuts and bolts to fix the middle and lower handles firmly together. NOTE: Make sure that the control handle is on the side of the cable holder of the connectors.
Page 16: Preparation
Clamping the cable with cable clip Clamp the cable in the cable clip and fasten this to the bar. Preparation Preparing to operate the electric tiller WARNING! Read all of the instructions in this manual before connecting the machine to a power supply. WARNING! If the insulation on a power cable or extension lead is found to be cut or damaged, do not touch it! Disconnect from the power supply immediately and have the damaged...
Page 17 NOTE: For extension cables up to 15 metres, use a wire cross section of 1.5mm . For extension cables over 15 metres but less than 40 metres, use a wire cross section of 2.5mm WARNING! This product is designed to operate on 230-240 VAC 50Hz.
Page 18 Switch on/off NOTE: For your safety, this machine is equipped with a double switch system. This system prevents starting the machine inadvertently. You must press the switch button (A) firstly, and then hold the switch trigger (B). Switching on 1. Press the lock button (A). 2.
Page 19: Operation
Operation Operating WARNING! Do not touch the gearbox, as it may become hot during operation. WARNING! Always keep a firm grip on the machine with both hands and watch your feet; the blades may cause an accident. Take care when moving backwards to prevent tripping! WARNING! To avoid damage to the machine: Never lift or drag the machine with the motor running.
Page 20: Maintenance And Repair
Maintenance and Repair Maintenance and Repair WARNING! Always switch the product off and let the product cool down before performing inspection, maintenance and cleaning work! If you need to replace the fitted plug, then follow the instructions below. IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Blue –...
Page 21 5. Regularly check for obvious defects, such as loose, dislodged or damaged cutting devices, loose fixings and worn or damaged components. 6. Check that covers are undamaged and correctly fitted. Carry out necessary maintenance or repairs before using the product. Cutting Device WARNING! Wear safety gloves when working on the cutting blades!
Page 22 Storage Clean the product as described above. 2. Store the product and its accessories in a dark, dry, frost-free, well-ventilated place. 3. Always store the product in a place that is inaccessible to children. The ideal storage temperature is between 10 and 30°C. 4.
Page 23: Troubleshooting
Troubleshooting General Troubleshooting WARNING! Only perform the steps described within these instructions! All further inspection, maintenance and repair work must be performed by an authorised service centre or a similarly qualified specialist if you cannot solve the problem yourself! Suspected malfunctions, disturbances or damages are often due to causes that the user can resolve themselves;...
Page 24: Technical Data
Technical Data Technical Data Table Property Value Model no. TLEG08CHR Motor voltage 230-240V~/50Hz Power input 1050W No-load speed 390rpm Working width 360mm Max. working depth 180mm Net weight Measured sound pressure level 80.4dB(A), K=3dB(A) Measured sound power level 89.95dB(A), K=1.4dB(A) Guaranteed sound power level 93dB(A) Vibration (m/s...
Page 25: Disposal
For health & safety reasons, we should include the HAVS warning - attached. WARNING! This machine may cause Hand-Arm Vibration Syndrome (HAVS) if its use is not adequately monitored and managed. Preventative measures include, among others, regular maintenance and care of the product and cutting attachments, keeping hands warm and periodical breaks, as well as proper planning of work processes.
Page 26: Warranty
Warranty This product is covered by a 2 year warranty. The warranty covers any manufacturing defect in materials, workmanship and finish. Any claim under this warranty must be made by going to your nearest Homebase store, taking your proof of purchase with you, and claims must be made within 2 years of the date of purchase.
