Motorcycle Carrier
To avoid personal injury and/or property damage, please read and follow
1. Never overload ramp or carrier. Maximum capacity for this motorcycle carrier is 500 lb /or hitch
capacity, whichever is less. Please refer to your hitch manufacturer's maximum load capacity.
2. Carefully roll vehicle up or down the ramp. Never drive or ride your equipment while loading or
unloading. Erickson Manufacturing is not responsible for any damage or injuries that can
occur when loading and un-loading. USE AT YOUR OWN RISK!
3. Always load or unload on a solid, level and stable surface with the vehicle in gear, the parking/
emergency brake on, and engine off.
4. Use to haul a motorcycle or scooter only.
5. Ramp surface must be clean, dry and free from oil, grease or water.
6. Inspect ramp and carrier before each use. Tighten any loose hardware. Replace any worn/damaged
parts. Do not attempt to use if the ramp or carrier is damaged in any way. No modification, alteration,
or deviation to the motorcycle carrier are authorized by the manufacturer. Proper care and
maintenance of the unit are essential to safety.
7. Proper use of this product is critical to safety, and beyond the control of Erickson Manufacturing
Ltd. Erickson Manufacturing Ltd. neither guarantees nor is liable for any damage resulting from
improper use. The liability of this product is limited to its purchase price if it proves to be defective
in material and/or workmanship.
Rated Capacity
Dimensions
ALL instructions before assembling and operating.
WARNING
NEVER RIDE ON YOUR EQUIPMENT WHEN LOADING OR UNLOADING
MAY CAUSE INJURY OR DEATH
Specifications
500 lb.
44" x 76" x 7"
Item no: 07508
1/6
Advertisement
Summary of Contents for Erickson 07508
- Page 1 Proper care and maintenance of the unit are essential to safety. 7. Proper use of this product is critical to safety, and beyond the control of Erickson Manufacturing Ltd. Erickson Manufacturing Ltd. neither guarantees nor is liable for any damage resulting from improper use.
- Page 2 Parts (x4) (x1) (x2) (x4) (x2) (x4) (x2) (x1) (x2) (x2) (x2) (x16) (x1) (x4) (x10) (x4) (x4) (x8) (x1) (x4) (x2) (x2) Assembly Recommended Tools Adjustable W rench ( 2pc) Adjustable Wrench (x2) ...
- Page 3 Item no: 07508 Assembly STEP 1 - Use U type connection plate (2)to put ramps(1) (2pcs) together. Assemble the ramps and U plate by using 3/8”*1-3/4”hex bolt(3),3/8”wider washer (4) and 3/8”Locknut(5). Use 1/2”*7-1/2”Hex bolt(6) and 1/2”Lock- nut(7), clip(8) and hairpin(9) to secure the ramp as shown in FIG1.
- Page 4 STEP 2 - Place the ramp from Step 1 on top of the supporting bridge(10), use 3/8”*5”Hex bolt(13),3/8”washer (4) and 3/8”Locknut(5) to secure L type steel plate(12) under the supporting ridge(11). Use 3/8”*3”Hex bolt(14),3/8” washer (15) and 3/8”Locknut(5) to secure the supporting ridge(11) and L type steel plate(12). Screw all the 3/8”Locknut tight as shown in FIG2.
-
Page 5: Installation
Item no: 07508 STEP 5 Put ramp(23) the place shown in FIG 5, fix it by using C type safety pin(24). Remove C type safety pin (24) when using by putting ramp(23) on either side of the ramp(1) as shown in FIG6. -
Page 6: Warranty
Limits of implied Warranty and Consequential Damage Erickson Manufacturing Ltd. disclaims any obligation to cover any loss time, use of this product, freight, or any incidental or consequential claim by anyone from using this product. THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PAR- TICULAR PURPOSE.
