  • Page 1 3DVision-985 User's Manual...
  • Page 2 Version 1.1 Copyright © July 1997 All rights reserved Portions copyright ELITEGROUP Computer Systems Co., LTD. This publication may not be copied, reproduced, transmitted or reduced to any printed or electronic medium or to any machine readable form, or stored in a retrieval system, either in or electronic medium or to any machine readable form, or stored in a retrieval system, either in whole or in part without the written consent of the copyright holders.
  • Page 3: Table Of Contents

    Contents 3DVision-985 Package & Product Information....1 Manual Features............1 Package Contents............1 Online Manual Format...........2 Component Information..........3 New Features ..............3 Resolution and Frequency ..........5 Picture................6 Layout................6 Installing the Card ............7 Before The Basic Procedure.........7 The Basic procedure of the installation.......7 Using your card..............9 Software Setup...............9...
  • Page 4: 3Dvision-985 Package & Product Information

    3DVision-985 Package & Product Information This manual contains all the information you’ ll need to use the 3D vision card. Please take a moment to familiarize yourself with the design and organization of the manual. Manual Features This manual also uses some icons to call your attention to important information.
  • Page 5: Online Manual Format

    Online Manual Format If the support disk for your AGP Card is a CD-ROM disc, a copy of the printer manual stored on the disc in Adobe Acrobat format. If so, it requires Adobe Acrobat Reader ver- sion 3.0 or later to view it. Acrobat Reader for Microsoft Windows95 may also be supplied on the Support Disk.
  • Page 6 n4KB texture cache n100MHz SGRAM nMore pipelined Support for AGP Slot n2X(133 MHz) transfer mode support nPipelined & side band Extensive validation 4 MB 100 MHz (10ns) SGRAM Pass Trilinear And Texture Compositing nTexture Morphing nReflections & Shadows nSearchlights/spotlights TV-Out (Optional) nTV-Out Encoder AD724 or AD722 n+5V Operation nAccepts FSC Clock or Crystal, or 4FSC Clock...
  • Page 7 Video-in (Philip SA7111a for 64 pin QFP&LQFP )(Optional) nFour analog inputs, internal analog source selectors, e.g. 4xCVBS or 2xY/C nTwo analog preprocessing channels nFully programmable static gain for the main channels or automatic gain control for the selected CVBS or Y/C channel nSwitchable white peak control nTwo built-in analog anti-aliasing filters...
  • Page 8: Resolution And Frequency

    Resolution and frequency Resolution Colors Refresh Rate (Hz) 640x480 256, 16bit, 32bit 60, 72, 75, 85, 100 720x480 256, 16bit, 32bit 800x600 256, 16bit, 32bit 60, 75, 85, 100 1024x768 256, 16bit, 32bit 44, 60, 70, 75, 80, 1280x1024 256, 16bit 44, 60, 75, 85, 100 1600x1200 256, 16bit...
  • Page 9: Picture

    Layout The illustration as the followings shows the connectors, chipset and header of the card. TV-out (Optional) CON1 CON3 Trident 3DImage9850 Video-In (Optional) Picture The illustration as the following shows the chipset, con- nectors, and sockets of the card.
  • Page 10: Installing The Card

    Installing the Card Before The Basic Procedure To install a VGA Card on the mainboard you need to notice the following items. J Unplug after switch off power. MMake sure your hands dry JDo not touch other parts inside computer when using "Screw driver"...
  • Page 11 3.Align your card with an empty expantion AGP slot, and grasp the card by the top edge and carefully seat it firmly into the selected expansion slot. 4.Replace the screw to fasten the card in place. Replace the computer cover. 5.Plug the monitor back into your card.
  • Page 12: Using Your Card

    Using your card The Standard Computer System Requirements 1.Mainboard with AGP Slot 2.At least 16Mbytes EDO/SDRAM 3.Using the Windows 95 4.DirectX 3 or above (DirectX 5 suggested) 5.CD-ROM 6.Speaker or Earphone(Unnecessary) 7.Sound Card(Unnecessary) (Appendix is for your reference) Software Setup When you insert supported CD, it will autorun the screen, 3DVision installation as it follows, it includes DIY Guide, User's manual, Windows95,...
  • Page 13: Ms Windows 95 Installation

    Besides, we also supply Windows NT and OS/2 installation guide. You can follow the following procesure. Software Setup Before installing the 3DVision Card onto your computer, make sure that the card is properly connected. MS Windows 95 Installation 1. Start the installation program "instal.exe" on the 2.
  • Page 14: Installing Under The Windows Nt

    Installing Under the Windows NT This driver package containing: - SGIUL40.SYS (Trident linear addressing video miniport driver) - SGIUL40.DLL (Trident 256/64K/16M colors accelerated video display driver) - 3DVision.INF (setup files used by Windows NT Setup program) - README (This README file for Windows NT Version 4.0) - TDISPLUS.DLL (Trident Utility program, for TV output)
  • Page 15 5. Windows NT will prompt you for the correct path where the driver is loaded. 6. Choose "3DVision-985” from the list of drivers. 7. Then follow the procedures provide by Windows NT to complete installation. 8. Restart Windows NT. Windows NT will start up with default mode using the Trident drivers.
  • Page 16: Installing Under The Os/2

    Installing Under the OS/2 This Trident OS/2 Display Drivers utility supports the following color monitor resolutions with OS/2. The required memory is shown in parentheses. 640x480x65K 640x480x256 800x600x65K 800x600x256 1024x768x65K (2M) 1024x768x256 1280x1024x65K (4M) 1280x1024x256 (2M) 640x480x16.7M 1600x1200x256 (4M) 1024x768x16.7M (4M) 800x600x16.7M (2M) This utility includes Trident OS/2 Display Drivers installation and Trident OS/2 Display Drivers setting.
  • Page 17 B. Installation procedure from the OS/2 Desktop: 1. Insert the Trident OS/2 Display Driver diskette in diskette drive A: or diskette drive B: 2. Open the OS/2 System folder, double-click on the Drives object, and then double-click on drive A. 3.
  • Page 18 This page is Refresh Rate selection page. . Click on Refresh tab to go to this page. . The refresh rates displayed are those supported at each resolution by the monitor specified in the Moni- tor Model selection page. . You can change the refresh rates by clicking on down arrow button and then clicking on the desired refreshrate.
  • Page 19 Appendix A : [ Procedure of Installing AGP VGA card ] Before installing AGP VGA driver, you need to setup the Windows 95 environment with installing the following items : • OSR2.1 • USB supplemental driver • Direct X5 driver HOW TO INSTALL THIS PRODUCT In order to install Universal Serial Bus support on a PC, Windows 95 version OSR2.0 must be running and you have...
  • Page 20 GENERAL INFOM For the latest information on Support ability and Trouble sho o t ing t he USB Supplement , check out ht t p:// WWW.MICROSOFT.COM/KB for access to our online Knowledge Base. For USB device specific issues, contact your OEM or Vendor of the device.
  • Page 21 Video In & TV-Out Illustration CON1 CN1 CN2 TV-Out: J1 : RCA Jack J2 : S-Video Video-In: CN1:RCA Jack(Composite) CN2:S-Video CON1:VGA Connector ******************************************* Please connect CN1 to run Video In function ******************************************** -18-...
