Page 10 Chapter 1 General Chapter 1 General 1.1 Guide to Use This Manual This manual includes specifications, functions and handling instructions for the PLC option card for dedicated iS7 inverter. This manual is divided up chapters as follows: Title Contents Describes configuration of this manual, unit’s for features Chapter 1 General and terminology.
Page 11: Chapter 1 General
Chapter 1 General 1.2 Features 1) iS7 PLC option card is compact type which is integrated the function of CPU, Input and output, and communication function. PLC option card has features of below described. (1) High speed processing High speed processing of 0.1μs/Step (2) Various built-in functions PLC option card can perform the various system by just using the one option card.
Page 12: Terminology
Chapter 1 General 1.3 Terminology The following table gives definition of terms used in this manual. Terms Definition Remarks A programming and debugging tool for the MASTER-K KGLWIN series. It executes program creation, edit, compile and debugging (A computer software). Internal memory area of the CPU module which is used I/O Image Area to hold I/O statuses.
Page 13: Chapter 2 System Configuration
Chapter 2 System Configuration Chapter 2 System Configuration 2.1 System Configuration 2.1.1 Basic System 6 Points (NPN/PNP)) Input points Relay output 4 points Output points 1 port (Program download from KGLWIN) RS232C 1 port (Modbus-RTU Master/Slave) RS485 2 ea (Green: RUN LED, Red: ERROR LED) Display LED 3 step switch for RUN, PAU/REM, STOP Switch...
Page 14: Product Block Diagram
Chapter 2 System Configuration 2.1.2 Product Block Diagram PLC option card for iS7 inverter series’ block diagram is as following. Input Signal Input Output Comm Built-in RS-485 Built-in RS-232C I/F Output Signal Classification Main Function • Signal processing -. Operating System function -.
Page 15: Exterior Of Product
Chapter 2 System Configuration 2.2 Exterior of Product Symbol Name Usage On state: Local Run (SW1 position is RUN) or Remote Run (SW1 RUN LED LED1 position is PAU/REM) and Select the RUN icon at KGLWIN. 1) Flickering : It flickering when Error is occurred. ERR LED LED2 2) OFF : It is Off at normal operation.
Page 16 Chapter 2 System Configuration Symbol Name Usage 1) NPN mode: Connect terminal input (P00~P05) with 24G. NPN mode NPN/PNP 2) PNP mode: Connect the terminal input (P00~P05) with Selection jumper 24P. PNP mode RS232C communication Connector to communicate with KGLWIN CON1 connector 1) Function : Maintaining of the Latch area data and RTC...
Page 17: Chapter 3 General Specification
Chapter 3 General Specifications Chapter 3 General Specifications 3.1 General Specifications The following table shows the general specifications of the PLC option card for iS7 inverter series. References Item Specifications Operating ambient 0 ~ 55 °C Temperature Storage ambient −25 ~ +70 °C Temperature Operating ambient 5 ~ 95%RH, non-condensing...
Page 18: Chapter 4 Cpu Function
Chapter 4 CPU Function Chapter 4 CPU Function 4.1 CPU Performance Specification The following table shows the general specifications of the PLC option card of iS7 inverter. Item Specifications Remark Cyclic execution of stored program, Time-driven interrupt, Process- Program Control Method driven interrupt Indirect mode(Refresh method), Direct by program command I/O Control Method...
Page 19: Operation Processing
Chapter 4 CPU Function 4.2 Operation Processing 4.2.1 Operation Processing Method 1) Cycle operation A PLC program is sequentially executed from the first step to the last step, which is called scan. This sequential processing is called cyclic operation. Cyclic operation of the PLC option card continues as long as conditions do not change for interrupt processing during program execution.
Page 20: Operation Processing At Momentary Power Failure Occurrence
Chapter 4 CPU Function 4.2.2 Operation Processing at Momentary Power Failure Occurrence The momentary power failure occurs when the input line voltage to the power supply falls down below the rated voltage. When momentary power failure occurs within 10ms, the PLC option card maintain operation processing.
Page 21: Scan Watchdog Timer
Chapter 4 CPU Function (2) Scan time differs in accordance with the execution or non-execution of interrupt progr ams and communication processing, etc. 2) Scan time monitoring Scan time is stored in the following system flag area. • F50 : Maximum scan time (unit: 1 ms) •...
Page 22 Chapter 4 CPU Function 1) Current value update and Contact On/Off of On Delay Timer The current value of timer is updated when the input condition of TON instruction turns On. When the current value reaches the preset value (current value = preset value), the timer output relay (Txxx) turns On.
Page 23 Chapter 4 CPU Function 4) Current value update and Contact On/Off of Monostable Timer In general, its operation is same as off-delay timer. However, the change of input condition is ignored while the timer is operating (decreasing). When current value reaches preset value the timer output relay is turned off and current value is cleared.
Page 24: Counter Processing
Chapter 4 CPU Function 4.2.6 Counter Processing The counter counts the rising edges of pulses driving its input signal and counts once only when the input signal is switched from off to on. PLC option card have 4 counter instructions such as Up Counter (CTU), Down Counter(CTD), Up/Down Counter (CTUD), and Ring Counter (CTR).
Page 25 Chapter 4 CPU Function (4) Ring Counter • Input Condition (D), Reset Condition (R), and preset value must be existed. -. The current value is increased with the rising edge of the counter input signal, and the counter output relay is turned on when the current value reaches the preset value. Then the current value and counter output relay is cleared as 0 when the next counter input signal is applied.
Page 26: Program
Chapter 4 CPU Function 4.3 Program 4.3.1 Classifications of Program All functional elements need to execute a certain control process are called as a ‘program’. In PLC option card, a program is stored in the EEPROM mounted on a CPU module or flash memory of a external memory module.
Page 27: Program Execution Procedure
Chapter 4 CPU Function 4.3.2 Program Execution Procedure The following diagram shows that how the CPU module process programs when the CPU module is powered on or switched to RUN mode. Start Processing Subroutine Program It is executed when PDI Program the condition is Scan Program TDI Program...
Page 28: Interrupt Program
Chapter 4 CPU Function 4.3.3 Interrupt Program It describes the program structure of KGLWIN and Interrupt program to help your understanding of Interrupt function of PLC option card . (Please refer to KGLWIN user manual for KGLWIN programming.) Scan Program Interrupt 1 Interrupt routine 1 (Program 1)
Page 29 Chapter 4 CPU Function 1) Parameter Setting 2) Time-driven Interrupt Time-driven interrupt occurs periodically with the constant interval assigned in parameter setting. In PLC option card of iS7 inverter series, Available TDI is P000 ~ P007 (8 points) assigned in parameter setting and period can be designated for each other.
Page 30: Error Handling
Chapter 4 CPU Function 4.3.4 Error Handling 1) Classification of Errors Errors occur due to various causes such as PLC option card system defect, system configuration fault or abnormal operation result. Errors are classified into fatal error mode, which stops system operation for system stability, and ordinary error mode, which continues system operation with inf orming the user of its error warning.
Page 31: Operation Mode
Chapter 4 CPU Function 4.4 Operation Mode The CPU operates in one of the three modes - RUN, STOP, and PAUSE mode. The followi ng describes operation processing in each operation mode. 4.4.1 RUN mode In this mode, programs are normally operated. The first scan start in the RUN Initialize data area according to the preset restart mode.
Page 32: Stop Mode
Chapter 4 CPU Function ) Processing when the operation mode is changed. Initialization of data area is executed when the first scan starts and The possibility of exec ution of the program is decided with check on its effectiveness. 2) Operation processing contents I/O Refresh and program operation are executed.
Page 33 Chapter 4 CPU Function 2) Operation mode change by mode key The method of operation mode change by mode key is as below table. Mode Setting Key Position Operation Mode Local RUN STOP Local STOP Remote RUN: Select Run icon at KGLWIN PAU / REM Remote STOP: Select STOP icon at KGLWIN Remote PAUSE: Select PAUSE icon at KGLWIN...
Page 34: Function
Chapter 4 CPU Function 4.5 Function 4.5.1 Self-diagnosis 1) Function (1) The self-diagnosis function permits the CPU module of PLC option card to detect its own errors. Self-diagnosis is carried out when an error occurs during PLC option card power supply is turne d on or operating process.
Page 35 Chapter 4 CPU Function -. Select the ’Set forced I/O’ from KGLWIN Select ‘Set Forced IO’. -. Select the I/O area and then double click. Set ‘forced I/O data’ by bit. Set ‘forced I/O data enable’ by bit. 4 - 18...
Page 36 Chapter 4 CPU Function -. When forced I/O set enables, forced I/O function is executing. Click 2) Special data register for forced I/O The contents of forced I/O setting is registered to special data register as below. It is possible to use ‘forced I/O function’ to program. Items Special Device All Forced I/O enable...
Page 37: Direct I/O Operation Function
Chapter 4 CPU Function (3) Precaution Turning the power off and on, changes of the operation mode or operation by reset s witch does not change the previous force on/off setting data. They remain within the CPU module and operation is executed with the same data. Forced I/O data will not be cleared even in the STOP mode.
Page 38 Chapter 4 CPU Function 3) Clear error data Use a ‘data clear’ function of KGLWIN. REMARK Refer to the KGLWIN user’s Manual Chapter 7, for details. 4 - 21...
Page 39: Memory Configuration
Chapter 4 CPU Function 4.6 Memory Configuration The CPU module includes two types of memory that are available by the user. One is pr ogram memory, which is used to store the user programs written to implement a system by the user. The other is data memory, which stores data during operation. Bit Data Area Word Data Area User Program Area...
Page 40: Rtc Function
Chapter 4 CPU Function 4.7 RTC Function PLC option card for iS7 inverter series supplies RTC(Real Time Clock) module for the time- scheduling control. Clock operation by the RTC function is continued with a super capacitor when the CPU is powered off. The time of RTC is updated in every scan by operation information of system flag.
Page 41 Chapter 4 CPU Function (2) Read RTC data from special register The followings are the memory address of preset data. Description Special register Data Area (Word) (BCD format) Upper byte Lower byte F053 Lower 2 digits of year Month H0207 F054 Hour H2313...
Page 42: Chapter 5 Input And Output Function
Chapter 5 Input and Output Function Chapter 5 Input and Output Function 5.1 Input and Output Specification Digital input that PLC option card of iS7 inverter offers are made to use both electric current sink and electric current source. (NPN/PNP types) To keep using the coil load as an output module, maximum opening and shutting frequency is 1 second On and 1 second Off.
Page 43: Digital Input Specification
Chapter 5 Input and Output Function 5.2 Digital Input Specification 1) Specification Model PLC Option Card of iS7 Inverter Specification 6 Points Number of Input Points Photo-coupler Insulation Insulation Methods DC24V Rated Input Voltage Rated Input Current DC20.4 ~ 28.8V (Ripple: less than 5%) Operating Voltage Range 100% simultaneously On Max.
Page 44 Chapter 5 Input and Output Function This product provides the six terminal inputs P00~P05 of external terminal block (TB1). ◆ NPN mode 1) Set the J3 (NPN/PNP selection jumper) as below figure. Terminal input is operated to NPN type. 2) Wire the external terminal bock (TB1) as below figure. P0 wiring is a sample wiring. Please do wire P1~P5 terminal as same method.
Page 45: Digital Output Specification
Chapter 5 Input and Output Function 5.3 Digital Output Specification 1) Specification Model PLC Option Card of iS7 Inverter Specification Output Points 4 points Insulation Method Relay Insulation Rated Load Vol./Cur. DC24V / 2A (resistor load), AC220V / 2A (COS Ψ = 1) /1 point 5A/COM Min.
Page 46 Chapter 5 Input and Output Function...
Page 47: Chapter 6 Usage Of Various Function
Chapter 6 Usage of Various Functions Chapter 6 Usage of Various Functions 6.1 Built-in Functions 6.1.1 Pulse Catch Function In the main unit, 6 points (P0000~P0005) of pulse catch input contact points are internalized. Through using this contact point, 150 μs, short pulse signal, can be taken which can not be executed by general digital input.
Page 48 Chapter 6 Usage of Various Functions Remark 1) Pulse catch input contact points operate as general digital input if they are not designated as pulse catch input. Pulse catch input contact points can be used 6 points from P000 to P005.
Page 49: Input Filter Function
Chapter 6 Usage of Various Functions 6.1.2 Input Filter function External input of PLC option card selects Input Filter Time from the range of 0-1000ms of KGLWIN. Credibility secured system may be established by adjustment of input correction no. through using environment 1) Usage Input signal status affects the credibility of system in where noise occurs frequently or pulse width of input signal affects as a crucial factor.
Page 50: External Interrupt Function
Chapter 6 Usage of Various Functions 6.1.3 External Interrupt Function PLC option card for iS7 inverter Series can perform 6 points of external contact interrupt by using input of main unit without special interrupt module. 1) Usage This function is useful to execute a high speed execution regardless of scan time. 2) External Interrupt processing time ㆍ...
Page 51 Chapter 6 Usage of Various Functions 5) Usage (1) Click twice the parameter on the project window of KGLWIN. (2) Designate contact point, no. of priority and movement condition of the task program which is moved by interrupt inputting. Time driven Interrupt execution periodic set Interrupt Type Setting Interrupt input executing...
Page 52: Pid Control Function
Chapter 6 Usage of Various Functions 6.1.4 PID Control Function 1) Introduction This chapter will provide information about the built-in PID (Proportional Integral Derivative) function of PLC option card of iS7 inverter series. The PID control means a control action in order to keep the object at a set value (SV). It compares the SV with a sensor measured value (PV : Present Value) and when a difference between them (E : the deviation) is detected, the controller output the manipulate value (MV) to the actuator to eliminate the difference.
Page 53 Chapter 6 Usage of Various Functions 2) Specification (a) Proportional Operation (P operation) ① P action means a control action that obtains a manipulate value which is proportional to the deviation (E : the difference between SV and PV) × ②...
Page 54 Chapter 6 Usage of Various Functions (b) Integral Operation (I Operation) ① With integral operation, the manipulate value (MV) is increased or decreased continuously in accordance time in order to eliminate the deviation between the SV and PV. When the deviation is very small, the proportional operation can not produce a proper manipulate value and an offset remains between PV and SV.
Page 55 Chapter 6 Usage of Various Functions It takes long time to get the set value. Fig. 7.4 The system response when a long integration time given If the integration time is too short, oscillations will occur. Fig. 2.6 The system response when a short integration time given Fig.
Page 56 Chapter 6 Usage of Various Functions (c) Derivative operation (D action) ① When a deviation occurs, due to alteration of SV or external disturbances, D action restrains the changes of the deviation by producing MV which is proportioned with the change velocity (a velocity whose deviation changes at every constant interval) in order to eliminate the deviation.
Page 57 Chapter 6 Usage of Various Functions (d) PID action ① PID action controls the control object with the manipulation quantity produced by (P+I+D) action. PID action when a given deviat ion has occurred is shown as the following Fig. 7.7. ②...
Page 58 Chapter 6 Usage of Various Functions There are several methods to avoid the windup of actuator. The most popular methods are adding another feedback system to actuator, using the model of actuator and stop integrating when actuator is saturated. 시간 Time Integral Term...
Page 59 Chapter 6 Usage of Various Functions 3) Realization of PID control on the PLC option card In this chapter, it will describe how to get the digitized formula of the P, I, and D terms. (a) P control The digitized formula of P control is as following; −...
Page 60 Chapter 6 Usage of Various Functions 4) Instruction and Parameter Setting For the PID operation of PLC option card, following 2 instruction are included in the KGLWIN software. Name Description PID8 Perform the PID operation PID8AT Perform the auto tuning operation (a) PID8 instruction parameter setting and explanation.
Page 61 Chapter 6 Usage of Various Functions (5) High Frequency Noise Depression Ratio High frequency noise removal ratio is used for derivative control operation, and shows the ratio of high frequency noise depression. If there is a lot of high frequency noise in the control system, select the value as higher value.
Page 62 Chapter 6 Usage of Various Functions (10) Bias The Bias data is used for the compensation of offset in the proportional control. The range of input is 0 ~ 4000 or D area. Be cautious that The actual range of Bias is –2000 ~ 2000. namely, 0~2000 represents 0 ~ +2000 and 2001 ~ 4000 represents -1 ~ -2000.
Page 63 Chapter 6 Usage of Various Functions (2) Setting Value, Process Value SV (set value : the designated value) and PV (process value : present value) of PID operation have the range integer 0 ~ 4000. The range is set with the consideration of the resolution of A/D and D/A module of PLC option card (12 bits) and offset value.
Page 64 Chapter 6 Usage of Various Functions 5) Instruction (1) PID8 Available device Flag Instruction No. of Error Zero Carry integer Steps (F110) (F111) (F112) PID8 Flag Set Error flag turns on when designating Error (F110) area is over and the instruction isn’t executed.
Page 65 Chapter 6 Usage of Various Functions (2) PID8AT Available device Flag No. of Instruction Error Zero Carry inte Steps (F110) (F111) (F112) PID8AT Flag Set Error flag turns on when designating Error area is over and the instruction isn’t (F110) PID8AT executed.
Page 66 Chapter 6 Usage of Various Functions 6) Example Program (1) System Configuration Expansion I/O or PLC option card for Remote I/O iS7 inverter series KGL-WIN Above V 3.4 Present Value (PV: DC4~20mA) RS-232C Manipulated Value Signal Converter Temp. Sensor (MV: DC4~20mA) Electric Oven (0~200 ℃) Heater...
Page 67 Chapter 6 Usage of Various Functions b) Auto-tuning Control function (parameter setting by built-in function of PLC option card) ■ Setting Value (when Resistor Thermal Detector sensor is used) 960(60 C),1120(70 C),1280(80 C),1600(100 ■ Operation Scan Time: Set by 1 second (Setting value = 10) ■...
Page 68 Chapter 6 Usage of Various Functions (4) Parameter Setting and Program a) In case of using PID function only When PWM set is selected, Scan When PWM is designated, this window time parameter is disabled and is activated and PID function operates this value is ignored.
Page 69 Chapter 6 Usage of Various Functions b) In case of using combined function of PID operation and Auto tuning. This program shows the PID operation with the Auto-tuning value of P, I, and D. After Auto-tuning is completed, PID operation will start with calculated PID parameter When RPC Method is selected, the scan time fixed to 1 sec.
Page 70 Chapter 6 Usage of Various Functions When M0000 turns on, auto When M0001 turns off, tuning starts. When auto tuning ends at Calculated P,I,D parameters are output 0 to D4982. D0010, M0001 turns on and saved to D0012, D0013, D0014. PID control starts.
Page 71: Chapter 7 Exclusive Functions For Is7 Inverter Control/Monitoring
Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring 7.1 Outline and Installation 7.1.1 Outline and Major Components of the Product LED1, LED2 CON1 Battery Housing T/B 1 Symbol Name Description ON state: local run (SW1 is at RUN position) or remote run (SW1 RUN LED LED1 is at PAU/REM position, and RUN icon is selected in KGLWIN)
Page 72 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring Symbol Name Description 1) NPN mode: connects terminal block input (P00~P05) and 24G. for details, see page 7-5. Terminal input acts as NPN. NPN/PNP Selection Jumper 2) PNP mode: connects terminal block input (P00~P05) and 24P. for details, see page 7-5.
Page 73: Detail Description Of The Components
Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring 7.1.2 Detail description of the components (1) Mode Selection Switch (SW1 in the outline drawing) The SW1 shown in the product outline drawing is for mode selection. PLC Option Settings of the Mode Selection Switch and KGLWIN Operation Status 1.
Page 74 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring (3) Serial (RS232C) Communication (CON1 in the outline drawing) This part is designated with CON1 in the outline drawing. In the RS232C used in this PLC option, No. 2 and No.3 lines are cross-linked as shown below, while No. 5 is interconnected.
Page 75 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring (5) Terminal input (P00~P05 terminals of TB1 in the drawing) Total 6 terminal inputs are supported from P00~P05 on the external terminal block (TB1). ◆ NPN (Sink) mode 1) Set the J3 (NPN/PNP selection jumper) as shown below. Terminal inputs are in NPN mode...
Page 76 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring (6) Terminal output (P40~P43 terminals of TB1 in the outline drawing) This product provides total 4 terminal output contacts (4 relay contacts) which are P40~P43 on the TB1. Connection method is as shown below. 1) Output functions of PLC option under inverter LV (low voltage) trip (default) When the iS7 inverter is tripped by LV(low voltage), the contacts which have been ON remain the ON status.
Page 77 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring (8) Battery Housing 1) Battery specification Coin-type, lithium ion battery (Type: CR2032). 2) Service life of battery A new battery (capacity 220mAh, at 20℃) can supply power to this product for about 4 years without external power supply.
Page 78: Functions Of Plc Option Card Exclusively For Is7 Inverter
Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring 7.2 Functions of PLC Option Card exclusively for iS7 Inverter 7.2.1 List of the special D registers for iS7 inverter control and monitoring Classific Area Description Ref. Page ation D4454 Using the digital loader of the inverter, register the addresses D4455 (see Appendix, page 4, App.
Page 79: Control
Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring 7.2.2 Control (PLC Option Inverter) (1) iS7 Inverter Frequency Reference PLC option can change the inverter’s frequency reference. Here, the DRV07 (Freq Ref Src) must be se to “PLC.” ▶ Common area of the iS7 inverter Referring to the parameters (exclusively for control) of inverter common area in the “App.
Page 80 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring (2) iS7 Inverter Operation Reference PLC option can provide operation reference to an inverter. ▶ Common area of inverter Referring to the parameters (exclusively for control) of inverter common area in the “App. 4-6, page 4, Appendix,”...
Page 81 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring 3) In the ladder program below, when the M0002 contact is ON, the inverter operates forward at the frequency of 11.52Hz (frequency 11.52Hz reference from keypad). (3) Using inverter digital output contact points (basic 10: 3 points, with 10 extensions: basic 10 + 3 points) as the digital output contact points of PLC option.
Page 82 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring ▶ Special D registers of PLC for inverter control corresponding to APO60 ~ 67 Register Use of the Register Remark Data to inputted in the common area parameter option → Inverter D4454 address set up by AP060 (PLC Wr Data 1).
Page 83 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring (4) Writing other common area parameters frequently used (e.g.: acceleration and deceleration times, etc.) PLC option can write all the common area parameters of inverter. In this manual, PLC option will set up (write) acceleration and deceleration times. ▶...
Page 84 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring 3) The APO60 (PLC Wr Data1) and APO61 (PLC Wr Data2) correspond to D4454 and D4455 which are the special registers of PLC option, respectively, by 1:1 relation. Because, the APO60 (PLC Wr Data1) and APO61 (PLC Wr Data2) are registered with the common area address (0383Hex) of inverter acceleration time and the common area address (0384Hex) of inverter deceleration time, respectively, if a specific value is entered in D4454 or D4455, the value will be inverter’s acceleration or deceleration time, respectively.
Page 85: Inverter)
Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring 7.2.3 Monitoring (PLC Option Inverter) (1) Using inverter digital input points as the digital input points of PLC option Maximum 11 digital input points of inverter (with basic 10 points mounted: 8 points, with 10 extension points: basic 10 + 3 points) can be used as the digital input points of PLC option.
Page 86 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring 2) The APO76 (PLC Rd Data1) corresponds by 1:1 with the D4474 which is the special register of PLC option. Therefore, the value in the D4474 is the data (inverter digital input status) stored in the 0320Hex which is the address of the inverter digital input status registered in the APO76 (PLC Rd Data1).
Page 87 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring (2) Monitoring inverter operation statuses (forward/reverse, constant speed, accelerating/decelerating, stopped, etc) It is possible to monitor the operation status of iS7 inverter, and make out a ladder program for the sequence suitable for the operation status with PLC option card. ▶...
Page 88 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring ▶ Application and exemplary program 1) Set up inverter parameters as follows. Especially, enter 0305Hex which is the address of the inverter operation status (app. 4-1, page 4, Appendix) in the APO76 (PLC Rd Data1). Code Function Name Set Value...
Page 89 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring 6) During forward constant speed, the D4474 is h0031 (see common area of inverter) Stop Status Forward Accelerating Constant Speed Forward Forward Decelerating 7) With the digital loader of the inverter, change DRV01 (Cmd Frequency) to 5.00 Hz for forward deceleration.
Page 90 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring ▶ Application and exemplary program 1) Set up inverter parameters as follows. Especially, enter 0311Hex which is the address of the inverter’s current output frequency (app. 4-1, page 4, Appendix) in the APO76 (PLC Rd Data1). Code Function Name Set Value...
Page 91 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring (4) Monitoring the current trip status of iS7 inverter PLC option card can monitor up to 4 active trips of iS7 inverter. If a further trip occurs, it will over-write the oldest trip. ◎...
Page 92 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring ▶ Application and exemplary program 1) Make out following program with the KGLWIN. Check that the IN68 (P4 Define) is set to External Trip, and turn on the multifunction input P4 to trigger an External Trip. The D4490 area becomes 4 (External trip), as shown below.
Page 93 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring (5) Isolating PLC option output when the inverter is tripped by LV (Low Voltage) As described in page 7-7, (6) Terminal output, the method of isolating PLC output when the inverter is tripped by LV (Low Voltage) is described below with an exemplary program.
Page 94 Chapter 7 Exclusive Functions for iS7 Inverter Control/Monitoring ▶ Application and exemplary program 1) Set up inverter parameters as follows. Code Function Name Set Value Remark If the BIT0 of OUT30 is 1, the LV trip signal (1 for trip trigger, OUT30 Trip Out Mode 0 for trip reset) is sent to PLC...
Page 95: Chapter 8 Modbus Communication
Chapter 8 Modbus Communication 8.1 Modbus Communication 8.1 Introduction PLC option card of iS7 inverters’ built-in communication supports Modbus, the Modicon product’s communication protocol. It supports ASCII mode, using ASCII data and RTU mode using Hex data. Function code used in Modbus is supported by instruction and especially function code 01, 02, 03, 04, 05, 06, 15 and 16.
Page 96 Chapter 8 Modbus Communication 3) Address area (1) PLC option card supports 0 to 31. 4) Function code area (1) PLC option card supports only 01, 02, 03, 04, 05, 06, 15, and 16 among Modicon products’ function code. (2) If the response format is Confirm+(ACK), it uses the same function code. (3) If the response format is Confimr-(NCK), it returns as it sets the 8 bit of function code as 1.
Page 97 Chapter 8 Modbus Communication 7) Function code type Modicon PLC Code Function Code Name Remark Data Address 0XXXX(bit- Read Coil Status Read bits output) Read Input Status 1XXXX(bit-input) Read bits 4XXXX(word- Read Read Holding Registers output) words 3XXXX(word- Read Read Input Registers input) words 0XXXX(bit-...
Page 98: Parameter Setting
Chapter 8 Modbus Communication 10) Wiring Use S+ and S - terminals. RS485(-) terminal: Modbus-RTU Master RS485(+) terminal: Modbus-RTU Master 8.1.3 Parameter Setting 1) Setting communication parameter (1) Open a new project file at KGLWIN. iS7 should be selected in PLC type. Open a new project file for each of the master and the slave.
Page 99 Chapter 8 Modbus Communication Set the contents as follows. Item Setting ontents Set a number between 0 to 31 (Don’t assign no. 0 as broadcasting station Station No. lest it may be a cause for mistaken operation) Baud Rate Set one from 1200, 2400, 4800, 9600, 19200, 38400, or 57600 bps. Set 7 or 8.
Page 100: Instruction
Chapter 8 Modbus Communication 8.1.4 Instruction Available device Flag Instruction Error Zero Carry integer steps (F110) (F111) (F112) MODCOM Designation Designated communication channel MODCOM Ch S1 S2 S3 (Ch 0, Ch 1) Device which is registered communication parameter Device which stored communication Flag data Error flag turns On when #D area is...
Page 101 Chapter 8 Modbus Communication • S3 format is as below. Bit15 Bit 8 Bit1 Bit0 Error Bit Error Code (Bit8 ~Bit15) (Bit1) NDR(Bit) • NDR : when the communication ends normally, this bit turns on during 1 scan. • Error bit: when communication error occurs, this bit turns on during 1 scan. At that time, error code stores bit 8 ~ bit 15.
Page 102 Chapter 8 Modbus Communication Example Program 1 The master reads status of the Coil 00020 ~ 00056 of the slave station no. 17. The Coil of the slave station is supposed to be as follows and the data that are read is saved in data register D1000. Coil Status Status...
Page 103 Chapter 8 Modbus Communication Example program 2 The master reads status of the input contact 10197 ~ 10218 of the slave station no. 17. The input contact of the slave station is supposed to be as follows and the data that are read is saved in Internal relay M015.
Page 104 Chapter 8 Modbus Communication Example Program 3 The master writes 4 words data of D1000 ~ D1003 to output register 40000 of the slave station no. 10. ① ② ③ ④ ① It designates slave station and function code (No. of station: h0A(10) , function code : h10 ) ②...
Page 105 Chapter 8 Modbus Communication Example Program 4 The master writes 1 word data of PLC option card in D1000 to output register 40000 of the slave station no. 10. ① ② ③ ④ ① It designates slave station and function code (No. of station: h0A(10) , function code: h06 ) ②...
Page 106: Chapter 9 Maintenance
Chapter 9 Maintenance Chapter 9 Maintenance Be sure to perform daily and periodic maintenance and inspection in order to maintain the PLC option card of iS7 inverter in best conditions. 9.1 Maintenance and Inspection The I/O module mainly consists of semiconductor devices and its service life is semi-permanent. However, periodic inspection is requested for ambient environment may cause damage to the devices.
Page 107: Chapter 10 Troubleshooting
Chapter 10 Troubleshooting Chapter 10 Troubleshooting The following explains contents, diagnosis and corrective actions for various errors that can occur during system operation. 10.1 Basic Procedures of Troubleshooting System reliability not only depends on reliable equipment but also on short downtimes in the event of faults.
Page 108: Troubleshooting Flowchart Used When The Err Led Is Flickering
Chapter 10 Troubleshooting 10.2.1 Troubleshooting flowchart used when the ERR LED is flickering The following flowchart explains corrective action procedure to be used when the ERR LED is flickering during operation. ERR LED flickering. Check the error code, with connected KGLWIN. App-2 “System Warning error?
Page 109: Troubleshooting Flowchart Used When The Run Led Turns Off
Chapter 10 Troubleshooting 10.2.2 Troubleshooting flowchart used when the RUN LED turns off. The following flowchart explains corrective action procedure to treat the lights-out of RUN LED when the power is supplied, operation starts or operation is in the process. RUN LED is off.
Page 110: Troubleshooting Flowchart Used When The I/O Part Doesn't Operate Normally
Chapter 10 Troubleshooting 10.2.3 Troubleshooting flowchart used when the I/O part doesn’t operate normally. The following flowchart explains corrective action procedure used when the I/O module doesn’t operate normally. When the I/O module doesn’t work normally. Is the indicator LED of the P40 on? Measure the voltage of Replace the connector of...
Page 111 Chapter 10 Troubleshooting Continue Are the indicator LEDs of the P000 and P001? Check the P000, P001 Check the P000, P001 terminal voltage with terminal voltage with tester. tester. Is the terminal screw tightened Is the value normal? Is the value normal? securely? Is the condition of the terminal board connector...
Page 112 Chapter 10 Troubleshooting 10.2.4 Troubleshooting flowchart used when a program cannot be written to the CPU part The following flowchart shows the corrective action procedure used when a program cannot be written to the PLC module. Program cannot be written to the PC CPU Switch to the remote S Is the mode-setting switch set TOP mode and execute...
Page 113: Troubleshooting Questionnaire
Chapter 10 Troubleshooting 10.3 Troubleshooting Questionnaire When problems have been met during operation of the PLC Option Card of iS7 inverter series, please write down this Questionnaires and contact the service center via telephone or facsimile. For errors related to special or communication modules, use the questionnaire included in the User’s manual of the unit.
Page 114: Troubleshooting And Countermeasure
Chapter 10 Troubleshooting 10.4 Troubleshooting and Countermeasures Describes the various circuit example and countermeasure. 10.4.1 Input circuit troubles and corrective actions Describes the various troubleshooting and its countermeasures. Cause Condition Corrective Actions Leakage current of external device Connect an appropriate resistor and (Such as a drive by non-contact switch) Input signal capacity, which will make the voltage lower...
Page 115: Output Circuit Troubles And Corrective Actions
Chapter 10 Troubleshooting 10.4.2 Output circuit troubles and corrective actions The following describes possible troubles with input circuits, as well as their corrective actions Condition Cause Corrective Action When the output Load is half-wave rectified inside (in some Connect resistors of tens to hundreds KΩ is off, excessive cases, it is true of a solenoid) across the load in parallel.
Page 116 Chapter 10 Troubleshooting Condition Cause Corrective Action The load does Sneak current due to the use of two Use only one power supply. not turn off. different power supplies. Connect a sneak current prevention diode. Output Output Load Load E1<E2, sneaks. E1 is off (E2 is on), sneaks. If the load is the relay, etc, connect a counter-electromotive voltage...
Page 117: Error Code List
Chapter 10 Troubleshooting 10.5 Error Code List Code Error Type Message Cause Corrective Actions (F006) State Internal Fault of some area of operating ROM, Contact the service system System Error Stop h0001 or H/W defect center. error OS ROM OS ROM Contact the service Stop Internal system ROM is defected...
Page 118 Chapter 10 Troubleshooting Code Error Type Message Cause Corrective Actions (F006) State Missing the Miss SBRT h0043 SBRT Error The subroutine does not has the Insert the SBRT instruction in Stop SBRT instruction. instruction. the subroutine program. The JMP ~ Correct the JMP ~ JME JMP(E) Error h0044...
Page 119: Appendix
Appendix 1 System Definitions Appendix 1 System Definitions (1) Connect Option You should set the communication port (COM1∼4) to communicate with PLC option card. • Select the Project-Option-Connection Option in menu. • Default Connection is RS-232C interface. • For detailed information about Connection Option, refer to KGLWIN Manual. Appendix 1-1...
Page 120 Appendix 1 System Definitions (2) Editor Option - This function is to set the time interval for Auto saving (Range : 0 ~60 min) - Automatically saved file is saved in the current directory. - The file is automatically deleted when the program window is closed. Therefore, if a program cannot be saved by "Program Error"...
Page 121 Appendix 1 System Definitions (3) Page Setup You can select print option when printing out the project. (margin, cover, footer) Appendix 1-3...
Page 122 Appendix 1 System Definitions 2) Basic Parameters The basic parameters are necessary for the operation of the PLC option card. Set the ‘Latch area’, ‘Timer boundary’, ‘Watchdog timer’, ‘PLC operation mode’, ‘Input setting’, ‘Pulse catch’ (1) Latch area setting Set the retain area on the inner device. (2) Timer boundary setting Set the 100ms/10ms/1ms timer boundary.
Page 123 Appendix 2 Flag List Appendix 2 Flag List 1) Special Relay F Area Relay Function Description F0000 RUN mode Turns on when the CPU in the RUN mode. F0001 Program mode Turns on when the CPU in the Program mode F0002 Pause mode Turns on when the CPU in the Pause mode...
Page 124 Appendix 2 Flag List (Continue to Special Relay F Area) Relay Function Description F003D ~ F003F I/O module has been mounted or dismounted, the F0040 ~ F005F I/O error corresponding bit turns on. Storing error code Stores the system error code F0060 ~ F006F F0090 20-ms cycle clock...
Page 125 Appendix 2 Flag List (Continue to Special Relay F Area) Relay Function Description F0126 ~ F013F The error code generated by FALS instruction is F0140 ~ F014F FALS number stored to this flag. F150 ~ F16F F170 ~ F173 F180 ~ F183 F190 ~ F193 F0200~ F020F F0210~ F021F...
Page 126 Appendix 2 Flag List 2) Internal Memory M area Relay Function Description M1910 Forced I/O Setting Bit Enables forced I/O. 3) Data Relay D area D register for Forced I/O setting Forced I/O designation Forced I/O data register register P000 D4700 D4800 P004...
Page 127 Appendix 3 Control and Monitoring Specific Inverter Data Appendix 3 Control and Monitoring Specific Inverter Data With the method described in “7.2 Exclusive iS7 Inverter Functions of PLC Option Card (page 7-10 ~ 7-24)” of this User Manual, enter the address of the data for control or monitoring (AP065~69) in No. 60~69 of the APO group, using the digital loader of the inverter.
Page 128 Appendix 3 Control and Monitoring Specific Inverter Data 3.2 Control (PLC Option Inverter) (1) iS7 Inverter Frequency Reference ▶ Special D register of PLC option card for inverter frequency reference Special D Use of parameter Detailed Description Register Inverter Frequency Command x Inverter Frequency (For example, D4451...
Page 129 Appendix 3 Control and Monitoring Specific Inverter Data (2) iS7 Inverter Operation Reference ▶ Special D register of PLC option card for inverter operation reference Special D Use of parameter Detailed Description Register 0: Stop Command BIT0 1: Run Command 0: Reverse Operation Inverter Operation BIT1...
Page 130 Appendix 3 Control and Monitoring Specific Inverter Data 3.3 Monitoring (Inverter PLC Option) (1) Operation Status Monitoring of iS7 Inverter ▶ Special D register of PLC option card for inverter operation status monitoring Special D Function Detailed Description Register BIT0 0: Stop BIT1 1: Forward operation...
Page 131 Appendix 3 Control and Monitoring Specific Inverter Data 3) In stop condition, D4470 is “h0000” (see “List of PLC option card Special D Registers for Inverter Operation Status Monitoring” above). 4) Now, press the “FWAD” key on the digital loader of the inverter to a give forward operation reference. During forward acceleration, D4470 is “h0021”...
Page 132 Appendix 3 Control and Monitoring Specific Inverter Data (2) iS7 Inverter Output Frequency Monitoring ▶ Special D register of PLC option card for inverter output frequency monitoring Special D Function Detailed Description Register Current output Freq. x 100 D4471 Output Freq. (Ex.
Page 133 Appendix 4 Common Area Parameter of iS7 Inverter Appendix 4 Common Area Parameter of iS7 Inverter 4.1 Common Area Parameter (for Monitoring) Address Parameter Scale Unit Detailed Description 0x0300 Inverter Model iS7 : 000Bh 0.75kW: 3200h 1.5kW: 4010h 2.2kW: 4022h 3.7kW: 4037h 5.5kW: 4055h 7.5kW: 4075h...
Page 134 Appendix 4 Common Area Parameter of iS7 Inverter Address Parameter Scale Unit Detailed Description 9: Pulse 10: built-in485 BIT3 11:communication option 12: App(PLC) BIT2 13: Jog 14: PID BIT1 15~22 : Auto Step 25~39 : sequential frequency BIT0 0x0307 keypad S/W (Exercise) 0x0100 : Version 1.00 version 0x0308...
Page 135 Appendix 4 Common Area Parameter of iS7 Inverter Address Parameter Scale Unit Detailed Description BIT7 None BIT6 None BIT5 Q4 (Expansion IO Relay Output 3) BIT4 Q3 (Expansion IO Relay Output 2) BIT3 Q2 (Expansion IO Relay Output 1) BIT2 Q1 (Basic IO TR Output1) BIT1 Relay2 (Basic IO Relay Output 2)
Page 136 Appendix 4 Common Area Parameter of iS7 Inverter Address Parameter Scale Unit Detailed Description BIT1 Arm Short BIT1 External Trip BIT11 Overvoltage Trip BIT1 Overcurrent Trip BIT9 NTC Trip BIT8 Overspeed Deviation BIT7 Overspeed BIT6 input open phase trip BIT5 output open pahse trip BIT4 Ground Fault Trip...
Page 137 Appendix 4 Common Area Parameter of iS7 Inverter Address Parameter Scale Unit Detailed Description BIT9 None BIT8 None BIT7 None BIT6 None BIT5 None BIT4 Gate Drive Power Loss BIT3 Watchdog-2 Error BIT2 Watchdog-1 Error BIT1 EEPROM Error BIT0 ADC Error BIT15 None BIT14...
Page 138 Appendix 4 Common Area Parameter of iS7 Inverter 4.2. Inverter Common Area Parameter (Control) Address Parameter Scale Unit Detailed Description 0x0380 frequency 0.01 Command Frequency Setting command 0x0381 RPM command Command RPM Setting BIT3 Changed from 0 to 1: Free-run to stop BIT2 Changed from 0 to 1: Trip Reset 0: Reverse Command...
Page 139 Appendix 4 Common Area Parameter of iS7 Inverter Address Parameter Scale Unit Detailed Description 0 : OFF Command 1 : ON Command BIT2 (Basic IO, OUT33: Q1 Define 이 “None”) 0 : OFF Command 1 : ON Command BIT1 (Basic IO, OUT32: Relay2 is “None”) 0 : OFF Command 1 : ON Command BIT0...
Page 140 Fax: 86-532-583-3793 Tel: 86-411-8273-7777 Fax: 86-411-8730-7560 ※ LS Industrial Systems constantly endeavors to improve its product so that SV-iS7 PLC Option /2009.04 Information in this manual is subject to change without notice. ⓒ LS Industrial systems Co., Ltd 2009 All Rights Reserved.

LS Industrial Systems SV-iS7 PLC User Manual

Chapter 1 General

Chapter 2 System Configuration

Chapter 3 General Specification

Chapter 4 CPU Function

Chapter 5 Input and Output Function

Chapter 6 Usage of Various Function

Chapter 7 Exclusive Functions for Is7 Inverter Control/Monitoring

Chapter 8 Modbus Communication

Chapter 9 Maintenance

Chapter 10 Troubleshooting

Appendix

Appendix 1 System Definitions

Quick Links

Troubleshooting

Need help?

Questions and answers

Summary of Contents for LS Industrial Systems SV-iS7 PLC

Table of Contents
