TRASH WATER PUMP
USE AND CARE MANUAL
READ THIS MANUAL CAREFULLY BEFORE OPERATION
Failure to follow the instructions and safety precautions in this manual can result
in property damage, serious injury and/or death.
SAVE THIS MANUAL FOR FUTURE REFERENCE
NOTE: Photographs and line drawings used in this manual are for
reference only and may not represent your specific model.
Part Number 7113995 / ENGLISH
Models covered: SSTP02 / STP03
REV 0 - 07/08/2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SSTP02 and is the answer not in the manual?

Questions and answers

Related Manuals for Simpson SSTP02

Summary of Contents for Simpson SSTP02

  • Page 1 TRASH WATER PUMP USE AND CARE MANUAL Models covered: SSTP02 / STP03 READ THIS MANUAL CAREFULLY BEFORE OPERATION Failure to follow the instructions and safety precautions in this manual can result in property damage, serious injury and/or death. SAVE THIS MANUAL FOR FUTURE REFERENCE NOTE: Photographs and line drawings used in this manual are for reference only and may not represent your specific model.
  • Page 2 NOTES THIS PAGE WAS INTENTIONALLY LEFT BLANK Page II Part Number 7113995 / ENGLISH REV 0 - 07/06/2020...
  • Page 3 Save this manual for future use Keep this manual for future reference. This manual should be considered a permanent part of the product and stay with it. This manual should be available to anyone operating the product(s) it covers. This manual should remain with the product(s) it covers if sold to a new owner.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SAFETY INSTRUCTIONS ..............4 Hazard Alert Symbols ..............4 Safety Symbols ................5 General Hazards ................6 Fire and Explosion Hazards ............7 Exhaust Hazards ................7 DISCLAIMERS ..................13 UNPACKING ..................13 Unpacking ..................13 COMPONENT LOCATION ..............14 OPERATING CHECKLIST ..............15 Location ..................15 High Altitude Operation ..............16 Operating Conditions ..............16 Checking the Engine Oil ..............17 Checking Fuel ................19...
  • Page 5 Storing for more than two months ..........29 Transportation ................29 SPECIFICATIONS ................30 Model Number: SSTP02 / Item Number: 71002 ......30 Model Number: STP03 / Item Number: 71003 ......30 WARRANTY INFORMATION ..............31 Warranty Terms: ................31 Warranty Limitations: ..............31 STANDARDS INDEX ................32 Page 3...

  • Page 6: Safety Instructions

    SAFETY INSTRUCTIONS Read This Manual Before Operating This manual contains important safety information and instructions. Do not operate this product until you have read and completely understand all safety, operation, and maintenance instructions listed in this manual. Failure to follow the information listed in this manual before operation will result in property damage, injury, and/or death.

  • Page 7: Safety Symbols

    Safety Symbols EXPLOSION ACID FIRE TOXIC FUMES GASOLINE CHILDREN AND PETS ENGINE START MOVING PARTS CRUSHING INJURY KICKBACK HOT SURFACE ATTENTION INSPECT RESIDENTIAL USE READ MANUAL MAINTENANCE RUNNING WATER Page 5 Part Number 7113995 / ENGLISH REV 0 - 07/06/2020...

  • Page 8: General Hazards

    CALIFORNIA PROPOSITION 65 WARNING This product and the engine exhaust can expose you to chemicals which are known to the state of California to cause cancer, birth defects, or other reproductive harm. For more information on California Proposition 65, go to www.P65Warnings.ca.gov. POLYCYCLIC AROMATIC HYDROCARBON WARNING The air filter element and air box assembly may contain polycyclic aromatic hydrocarbons (PAHs).

  • Page 9: Fire And Explosion Hazards

    Exhaust Hazards ● Never operate the pump inside a house, garage, or any other kind of enclosure even if doors and windows are open. Run engine outside at least 20 feet away from windows, doors, and vents. Carefully consider wind direction and air currents when using pump outside to avoid breathing in engine exhaust.
  • Page 10 TOXIC FUMES Engine exhaust contains carbon monoxide, an odorless, colorless, poisonous gas. Running an engine indoors will kill you in minutes. Never use this product inside a house, garage, or any other kind of enclosure even if doors and windows are open. Run engine outside at least 20 feet (6 meters) away from windows, doors, and vents.
  • Page 11 INSPECT BEFORE OPERATING Failure to inspect this product before use could result in a hazardous situation resulting in product damage, serious injury, and/or death. To avoid these hazards, inspect the pump before each use. Check for loose or damaged parts, signs of oil or fuel leaks, missing guards, plugged cooling vents, or any other condition that may affect proper operation.
  • Page 12 SPARK ARRESTOR Operation of this product may create sparks that can start fires around dry vegetation. If the pump will be used around flammable materials, grasslands, woodlands, or other dry vegetation, an approved spark arrester must be installed. In some areas, a spark arrester is required by law.
  • Page 13 GASOLINE STORAGE It is important to prevent gum deposits from forming in essential fuel system parts, such as the carburetor, fuel filter, fuel hose or tank during storage. Alcohol-blended fuels (also called gasohol, ethanol, or methanol) attract moisture, which leads to separation and formation of acids during storage.
  • Page 14 PRIMING This pump will not prime when dry. Running the pump dry without priming can damage the pump assembly and seals. Damage caused by running dry is not covered under warranty. To avoid damaging the seals and pump assembly, do not run the pump when it is dry without priming.

  • Page 15: Disclaimers

    DISCLAIMERS ● All information in this publication was based on the latest product information available at the time of printing. The FNA Group reserves the right to change, alter, and/or improve the product and this document at any time, without notice, and without incurring any obligation.

  • Page 16: Component Location

    COMPONENT LOCATION 1. Primer funnel 2. Discharge port 6. Fuel tank 3. Suction port 7. Fuel level indicator 4. Engine ignition switch 8. Fuel tank cap 5. Starter recoil Engine choke 10. Fuel valve 11. Pump drain plug Page 14 Part Number 7113995 / ENGLISH REV 0 - 07/06/2020...

  • Page 17: Operating Checklist

    OPERATING CHECKLIST Location Place the pump on a level surface outside in a well-ventilated area before any operation. Keep all flammable materials at least five feet away from all sides of the product. ● Never use pump inside a house, garage, or any other kind of enclosure even if doors and windows are open.

  • Page 18: High Altitude Operation

    High Altitude Operation This engine will have proper engine performance and emission control when it is operated at or below an altitude of 5000 feet (1524 meters). This engine requires a high-altitude carburetor kit to ensure proper engine performance and emission control when operated at altitudes above 5000 feet (1524 meters).

  • Page 19: Checking The Engine Oil

    HOT SURFACES A running engine produces heat. The surfaces of the engine, other related components, and engine exhaust gas get hot enough to cause mild moderate burns or ignite materials on contact. To avoid burns, do not touch engine surfaces or exhaust gases while operating and allow engine to cool completely before moving, touching, or performing any maintenance.
  • Page 20 FILL ENGINE OIL BEFORE USE The engine is shipped from the factory without oil. Running the engine without oil will result in severe engine damage and void the warranty. To avoid causing engine damage and voiding the warranty, fill the engine with the recommended oil type. USE CORRECT ENGINE OIL Oil is a major factor in the performance and service life of any engine.

  • Page 21: Checking Fuel

    Checking Fuel REFUELING Gasoline is highly flammable and gasoline vapors are extremely explosive. Fire and explosions can cause severe burns and/or death. Keep gasoline away from flames, sparks, and other ignition sources. Refuel outdoors in a well-ventilated area with the engine stopped and cool.
  • Page 22 GASOLINE STORAGE It is important to prevent gum deposits from forming in essential fuel system parts, such as the carburetor, fuel filter, fuel hose or tank during storage. Alcohol-blended fuels (also called gasohol, ethanol, or methanol) attract moisture, which leads to separation and formation of acids during storage.

  • Page 23: Connecting Hoses

    CONNECTING HOSES Connecting Suction and Discharge Hoses 1. Place gaskets and hose barbs onto both the suction and discharge ports then secure by threading on hose barb nuts. 2. Attach the suction hose (not included) to the suction port by sliding the hose over the barb then securing it with a hose clamp.

  • Page 24: Connecting Suction Hose Strainer

    Connecting Suction Hose Strainer 1. Thread the strainer barb into the strainer. 2. Place the suction hose over the strainer barb and secure it with a strainer hose clamp. 1. Suction hose 2. Strainer hose clamp 3. Strainer barb 4. Strainer Hose Placement 1.

  • Page 25: Priming The Pump

    PRIMING THE PUMP PUMP PRIMING This pump will not prime when dry. Running the pump dry without priming can damage the pump assembly and seals. Damage caused by running dry is not covered under warranty. To avoid damaging the seals and pump assembly, do not run the pump when it is dry without priming.

  • Page 26: Starting

    STARTING Starting the Engine 1. Complete the steps in the OPERATING CHECKLIST, CONNECTING HOSES, and PRIMING THE PUMP sections of this manual before starting the engine. Failure to do so could damage your engine and pump. OPERATING CHECKLIST Attempting to start the engine incorrectly or using the pump incorrectly can result in engine and/or pump damage, and may cause serious injury or death.

  • Page 27: Shutting Off Engine

    5. Pull the recoil until you feel some resistance, then pull rapidly to start the engine. RAPID RETRACTION Rapid retraction (also known as kickback) of the engine recoil starter cord will pull your hand and arm towards the engine faster than you can let go of the handle resulting in sprains, broken bones, lacerations, and/or traumatic amputations.

  • Page 28: Maintenance

    MAINTENANCE For safety reasons, the manufacturer recommends all pump service and repairs be performed by an authorized service center. All warranty replacements or repairs must be performed by an authorized distribution or service center. To find an authorized service center near you, to make a warranty claim, or for authorized warranty repair, call 1-877-362- 4271 or email cservice@fna-group.com.
  • Page 29 Interior Pump Cleaning: Keeping your trash pump clean will allow it to perform its best and prolong the life of the pump. Do not store the trash pump with without draining the pump housing. Do not allow dirt and debris to dry inside the pump housing. Clean your trash pump after each use by following the steps below.

  • Page 30: Engine Maintenance

    Engine Maintenance Before each use, check engine for loose or damaged parts, signs of oil or fuel leaks, and/or any other condition that may affect proper operation. Always keep all safety guards in place and in proper working order. Repair or replace all damaged or defective parts immediately. For safety reasons, the manufacturer recommends all engine service and repairs (including emission control devices and systems) be performed by an authorized service center.

  • Page 31: Storing For More Than Two Months

    Storing for more than two months 1. Make sure the engine is completely cool. 2. Turn the fuel valve to the ON position. 3. Remove all the fuel from fuel tank, fuel lines, and carburetor by loosening the drain screw at the bottom of the carburetor, and draining fuel into an appropriate container. 4.

  • Page 32: Specifications

    SPECIFICATIONS Model Number: SSTP02 / Item Number: 71002 Pump Set Flow Rate 158 GPM / 598 liters per minute Inlet Diameter 2 inches / 5 centimeters Outlet Diameter 2 inches / 5 centimeters Suction Head Lift 25 feet / 7.62 meters Total Head Lift 95-feet / 28.96 meters...

  • Page 33: Warranty Information

    WARRANTY INFORMATION Warranty Terms: The FNA Group warrants to the original purchaser this product shall be free from defects in materials and workmanship as follows. The FNA Group agrees to repair or replace, at their discretion, any defective pump or frame free of charge for one (1) year from the date of purchase. Any of the described parts of this product found by the FNA Group to be defective in material or workmanship within these warranty periods will be repaired or replaced at no charge to original purchaser by an authorized service center.

  • Page 34: Standards Index

    but not limited to, expenses related to transporting the product to or from an authorized service, a mechanic’s travel time, any telephone or telegram charges, the rental of a like product while the warranty service is being performed, any other travel time or expenses, loss or damage to personal property, loss of revenue, loss of use of the product, loss of time, or any other inconvenience.
  • Page 35 THIS PAGE WAS INTENTIONALLY LEFT BLANK Page 33 Part Number 7113995 / ENGLISH REV 0 - 07/06/2020...
  • Page 36 READ THIS MANUAL CAREFULLY BEFORE OPERATION Failure to follow the instructions and safety precautions in this manual can result in property damage, serious injury and/or death. SAVE THIS MANUAL FOR FUTURE REFERENCE Part Number 7113995 / ENGLISH REV 0 - 07/08/2020...

This manual is also suitable for:

Stp037100271003
