Summary of Contents for Billion 7025
- Page 1 ISDN PCI Card Quick Start Guide This product is designed for the ISDN with Basic Rate Interface.
-
Page 2: Package Contents
For more detailed instructions on configuring and using the ISDN card, please refer to the on-line manual. Package Contents • One ISDN card • One ISDN card installation CD with drivers, utility and bundled application software programs • One RJ-45 ISDN cable •... - Page 3 ISDN PCI card For Windows 95, OEM Service Release 2 (OSR2) or Windows 98: 1. Start Windows. After the opening banner, Windows will tell you that your ISDN card has been detected. You will then see the following screen for Windows 95: Or you will see the following screen for OSR2: Or you will see the following screen for Windows 98:...
- Page 4 2. Insert the installation CD into the CD-ROM drive (D: or E: , etc.). 3. For Windows95, select “Driver from disk provided by hardware manufacturer”. For OSR2, click “Next >” to go For Windows 98, click “Next >”. Then, check “Specify a location:”...
-
Page 5: For Windows Nt
ISDN PCI card 8. After complete installing the ISDN card driver, you will be prompted to restart the computer. Press “Yes” to restart your computer. For Windows NT 4.0: 1. Start Windows. Insert the installation CD into the CD- ROM drive (D: or E: , etc.). Run “Setup.exe”... - Page 6 5. If your PC has PnP BIOS, you can choose “Auto setting”. Then the IRQ and I/O Port of the ISDN card will be configured by the system. 6. After setting the properties of the ISDN card, you might see the following screen prompting for the path of the Windows NT source files to installing the Remote Access Service (RAS).
- Page 7 ISDN PCI card 8. Press “OK” to select “ISDN1-NTWANMP” as one of the “RAS Capable Devices”, you should then see the following screen. 9. Click “Add...” for adding “ISDN2-NTWANMP” to the list of RAS communication ports. The “ISDN1” and “ISDN2” ports make the ISDN card be capable of dialing or receiving multilink calls.
-
Page 8: For Windows Me
11. Click “Close”. Then, you will be prompted to restart the computer. 12. Press “Yes” to restart your computer and finish the driver installation. For Windows ME: 1. Start Windows. After the opening banner, Windows will tell you that your ISDN card has been detected. 2. -
Page 9: For Windows 2000
ISDN PCI card 3. After pressing “Next >” button for the next screen, then press “Finish”. 4. If the next screen appears when Windows finishes installing the drivers, press “Yes” to restart the computer. For Windows 2000: Start Windows. After the opening banner, Windows will tell you that your ISDN card has been detected. -
Page 10: For Windows Xp
Insert the installation CD into the CD-ROM drive (D:, or E:, etc.). Select “Specify a location” and browse for “D:\Driver\Win2000” (D: represents your CD-ROM drive). Click “OK”. After pressing “Next >” for the next screen, click “Yes” if windows titled “Digital Signature Not Found” appear. - Page 11 ISDN PCI card Click “Continue Anyway” to continue the installation.
-
Page 12: For Linux
Press “Finish”. For Linux: The Linux support for the ISDN PCI card comes with the Isdn4Linux package. First, you have to reconfigure the kernel to make the HiSax module be compiled with “Support for HFC PCI-BUS cards”. You can patch your kernel with the latest ISDN kernel tree using the current CVS sources. - Page 13 ISDN PCI card ISDN Utility and Diagnostic Program The ISDN Utility includes helpful programs for the ISDN card, such as a diagnostic program, a status program, an uninstallation program, and an on-line manual. You are highly recommended to run the diagnostic program to make sure the ISDN card, its drivers and the ISDN line are all properly installed and connected.
-
Page 14: Uninstalling The Isdn Card
Open the “Programs” folder on the “Start” menu and click on the “ISDN Utility” program folder. Click on the “ISDN Status” item to start the program. You should see the status like below. Uninstalling the ISDN card Click “Start”, “Programs” and click the “ISDN Utility” item. -
Page 15: Troubleshooting
ISDN PCI card Troubleshooting If your ISDN card is not functioning properly, run the Diagnostic Program to help you identify the problem. Here are some basic faults that are often overlooked by users. Follow these procedures for troubleshooting the ISDN card. Error Indication You are not... - Page 16 Error Indication Connecting fail. 1. Own ISDN Number is incorrect. (error code = xxxx) 2. Other devices on the same S occupying the B channel. 3. The ISDN protocol is wrong. Data transfer The ISDN line is not error. in good condition Possible Cause 1.
