- Page 1 INSTALLATION MANUAL MANUFACTURED AND SOLD DIRECT BY CPT AUTOPILOT INC. 7960 B Soquel Drive, #114, Aptos, CA 95003 USA www.cptautopilot.com email: info@cptautopilot.com...
- Page 3 The CPT is an extra crew member to man the wheel, day or night, rain or shine. It is amazing to take your hands off the wheel and experience the freedom the CPT provides! WARNING! Always remember to maintain a proper look-out.
-
Page 4: How To Use This Manual
HOW TO USE THIS MANUAL 1. Review “Mounting the Motor Box” page 7 to decide how the CPT can best be mounted in your cockpit. The standard pedestal, bulkhead, or L-bracket mounts are the easiest, most straightforward installations. 2. Download installation templates from our website. Print the templates and use them to get the measurements for mounting the autopilot. -
Page 5: Table Of Contents
Mounting the Control Box ......................22 Control Box Mounting Requirements ..............22 Testing the Control Box before final mounting............23 Troubleshooting........................... 24 How to Check for Magnetic Interference................. 24 © 2018 CPT AUTOPILOT INC. VERSION 21 PAGE 3 OF 26... -
Page 6: Parts List
PARTS LIST Before beginning the installation, unpack and identify all parts. Refer to the packing list for the complete list of parts for your order. Standard Parts · Motor Box (larger box with clutch/gear on back) w/10' power cable · Control Box w/heading controls, attached to motor box w/10' cable ·... -
Page 7: Mounting The Wheel Pulley
¼ turn. · The pulley may eventually warp or distort if the J-bolts are over-tightened. Place the belt on the pulley and replace the wheel. © 2018 CPT AUTOPILOT INC. VERSION 21 PAGE 5 OF 26... -
Page 8: Wheels With Wooden Spokes
Wheels with Wooden Spokes Proceed in the same general fashion as for metal-spoked wheels. If preferred the spokes can be padded to prevent crushing the wood or damaging the varnish under J-bolts. Clear vinyl tubing cut to length and slipped over J-bolt hooks works well. If you prefer not to use J-bolts, you may screw the pulley directly to the wheel using self-tapping or wood screws (Use pan-head screws with washers, not flat-head screws):... -
Page 9: Mounting The Motor Box
Shims can be used to obtain proper belt alignment between drive pulley and wheel pulley. Shim Dimensions 2" 2 ½" 2" 3" Use #10 screws (#7 or 3/16ʺ drill size) Shim © 2018 CPT AUTOPILOT INC. VERSION 21 PAGE 7 OF 26... -
Page 10: Standard Pedestal Mount
Standard Pedestal Mount Install Motor Box onto Pedestal Bracket Fasten the slotted motor box mounting bracket to the bottom of pedestal bracket using the four #10 screws and any needed shims. If a shim is needed for aligning the belt with the wheel, the thickness is based on the clearance distance between your spokes and pedestal (measured 5ʺ... -
Page 11: Pedestal Kit Parts Diagram
CPT Autopilot Installation Manual Pedestal Kit Parts Diagram © 2018 CPT AUTOPILOT INC. VERSION 21 PAGE 9 OF 26... -
Page 12: Standard Pedestal Mount With Dropdown Plate
Standard Pedestal Mount with Dropdown Plate The dropdown plate lowers the motor box below the pedestal base without the base obstructing the pedestal bracket. Install Motor Box onto Pedestal Bracket and Dropdown Plate Fasten the slotted motor box mounting bracket to the bottom of the Dropdown Plate using any needed shims and the four #10 screws. -
Page 13: Dropdown Plate Parts Diagram
CPT Autopilot Installation Manual Dropdown Plate Parts Diagram © 2018 CPT AUTOPILOT INC. VERSION 21 PAGE 11 OF 26... -
Page 14: Reverse-Vertical Pedestal Mount
Reverse-Vertical Pedestal Mount The motor box can be mounted to sit on either the Port or Starboard side of the pedestal. · If the pedestal diameter is more than 3 ¾ ʺ, the reverse plate must be at least 8 ¾ ʺ long for Port side mounting. ·... -
Page 15: Reverse-Vertical Pedestal Mount Diagrams, Starboard Side
CPT Autopilot Installation Manual Reverse-Vertical Pedestal Mount Diagrams, Starboard Side © 2018 CPT AUTOPILOT INC. VERSION 21 PAGE 13 OF 26... -
Page 16: Reverse-Vertical Pedestal Mount Diagrams, Port Side
Reverse-Vertical Pedestal Mount Diagrams, Port Side PAGE 14 OF 26... -
Page 17: L-Bracket Mount
Use a backing block if the mounting surface is not substantial or trustworthy. If desired, use a mounting pad between the L-bracket and mounting surface to ease clamp lever operation or to permit easy removal of the L-bracket © 2018 CPT AUTOPILOT INC. VERSION 21 PAGE 15 OF 26... -
Page 18: L-Bracket Parts Diagram
L-Bracket Parts Diagram Item # Quantity Part Name Motor Box Drive Pulley Motor Box Mounting Bracket, Slotted Clamping Lever L-Bracket Knurled Nut ¼-20 Washer ¼" 10-24 x ⅝" Pan Head Machine Screw 10-24 nut PAGE 16 OF 26... -
Page 19: Bulkhead Or Square Pedestal Mount
Drill just one hole first; check the fit before drilling the remaining holes. Check the installation by disengaging the clutch (pull outward ¼˝) and turning the wheel. © 2018 CPT AUTOPILOT INC. VERSION 21 PAGE 17 OF 26... - Page 20 Spoke-to-Bulkhead Clearances (If the wheel pulley mounts to a wood ring on a wood wheel, or to spoke spacers, use the clearance from the wood ring or from the spoke spacers when using the charts below) Full Bulkhead Mount Clearance Chart Partial Bulkhead Mount Clearance Chart (clutch extends past bulkhead starboard corner) Clearance...
-
Page 21: Tilted Or Angled Wheels
1ʺ spacers are used between the spokes and wheel pulley. Mounting Problems Not Addressed If you have difficulty working out a mounting solution, please contact CPT Autopilot for advice. © 2018 CPT AUTOPILOT INC. VERSION 21... -
Page 22: Electrical Connection
Connect motor box power line to a good 12-volt power source with 12ga cable. Even though current draw is low, the CPT will compensate for voltage drop from small wires by increasing current draw. Be sure to use a good quality 10-amp circuit breaker, or attach the 10-amp inline fuse that is supplied. A 10-amp circuit breaker is recommended to avoid a slight 0.04 mA draw when the unit is off. -
Page 23: Setting The Magnetic Reference
The cable exits the bottom side of the box. If the control box does not face the bow or stern of the boat, the autopilot heading will be affected by the boat pitching and heeling. © 2018 CPT AUTOPILOT INC. VERSION 21... -
Page 24: Mounting The Control Box
MOUNTING THE CONTROL BOX The control box MUST NOT be mounted too close to anything magnetic that will influence it, and the location should be checked with a handheld compass before placing an order. See “How to check for magnetic interference” below. Only use included 316 stainless fasteners for mounting the control box, other stainless alloys and fasteners can have a magnetic field. -
Page 25: Testing The Control Box Before Final Mounting
If the magnetic field is too strong the autopilot will not be able to keep the boat on heading. The CPT is able to steer on some steel boats but not all. The electronic sensor in the control box is more sensitive to magnetic fields than the older CPT models that used an optical compass. -
Page 26: Troubleshooting
HOW TO CHECK FOR MAGNETIC INTERFERENCE The CPT heading sensor is built into the control box so the control box mounting area must be free from magnetic influences. The helm area of most boats will be free of magnetic fields, but this should be checked. Use a hand-held compass, preferably a needle-bearing hiking compass, to check for magnetic fields near your pedestal. - Page 27 Steel boats should do a careful magnetic survey, and have a mounting location at least 6 ft from the nearest steel. If a suitable location is not available for the control box, use of the CPT is not recommended. © 2018 CPT AUTOPILOT INC.
- Page 28 NOTES PAGE 26 OF 26...
