- Page 1 LK-20 OPERATOR’S MANUAL PITTSBURGH LOCK MODEL 20 WITH AUTO-GUIDE POWER FLANGING ATTACHMENT INSTRUCTIONS AND PARTS DIAGRAM A PRODUCT OF VER. INT. LK20-02-CE 10-2009...
-
Page 2: Safety Guidelines
WARNING THIS EQUIPMENT IS DESIGNED TO BE OPERATED WITH ALL COVERS SECURED IN PLACE. OPERATION WITHOUT THESE SAFEGUARDS MAY RESULT IN CONDITIONS WHICH ARE HAZARDOUS TO THE OPERATOR AND OBSERVERS. SAFETY GUIDELINES Before operating the machine, study and follow the safety precautions in this section. These precautions are intended to prevent injury to you and your fellow workers. - Page 3 Safety Precautions WHILE Operating The Machine(s) Never leave the work area while the equipment is in operation. Never leave the machine unattended while it is under power or in operation. Always be alert while operating machinery. Be alert for loose, worn or broken parts. Do not attempt to operate any machinery with such parts present or if the machinery is making unusual noises or actions.
-
Page 4: Warranty
FORMTEK and excluded from this agreement. This warranty shall not be modified for any reason. In no event shall FORMTEK be liable for consequential or incidental damages, including the cost of assembly or disassembly, lost production or personal injury. -
Page 5: Safety First
Replacement and maintenance parts must be purchased from FORMTEK or the component original equipment manufacturer. Use of other parts may result in unsafe operation or failure of the machinery. If there is a question to the suitability of a part, proper personnel FORMTEK should be consulted. - Page 6 SAFETY GUIDELINES You are NOT ready to operate this equipment if you have not read and understood all of the safety information in this manual. ! ! ! ! ! WARNING: Do not wear loose clothing, neckties, improper gloves, or jewelry while operating this machine. If long sleeves must be worn, avoid loose cuffs or buttons, Tie back or contain long hair.
-
Page 7: Installation
INSTALLATION Provide a clean, flat, well lighted installation site. Level the machine and anchor it to the floor. Inspect the gears and drive assembly, and remove any debris that may have accumulated during shipping. ELECTRICALS Standard Electrical: 2HP (1.5KW) 110 Volts 1 phase, grounded power supply. Provide a sufficient 110V receptacle at the point of operation. -
Page 8: Basic Operation
OPERATING INSTRUCTIONS BASIC OPERATION Hold the material against the entrance gauge and slide it into the forming rolls. Be sure that the material remains against the gauge until the trail edge of material is engaged in the rolls. Note: Minimum part length is 175mm(7”). Make hold down adjustments as outlined below, to accommodate slight variations in metal thickness and hardness. - Page 9 1. Tighten the Auxiliary HOLD DOWN NUTS fully tight. 2. Loosen Auxilary HOLD DOWN NUTS of a turn (270 degrees) FORMTEK Machinery offers options for Auxiliary Rolls. Specific HOLD DOWN NUT adjustments depend on which optional rolls are installed. The turn specification may change depending on...
- Page 10 HOLD DOWN SPRING WASHERS ø31.5(OD) 91166A310 ø16.3(ID) 91455A130 96445K236 3 WASHERS PER GROUP 2 GROUPS PER STACK 5S355 ø8.2(ID) ø16(OD) SMALL SPRING WASHERS 96475K295 SADDLE WASHER 7X635 8 WASHERS 2 WASHERS PER GROUP 2 GROUPS PER STACK STACK AS SHOWN FEMALE PITTSBURGH LOCK HAMMER-OVER EDGE HAMMER-OVER EDGE ADJUSTMENT (ENTRANCE GAUGE)
- Page 11 EXIT GAUGE Never move the exit gauge bar for this roll set. This gauge is not intended to contact the material under normal circumstances. NOTE: There should be a deep scribe or scratch mark along the side of the exit gauge, this is the original line location of the exit gauge from the factory.
- Page 12 Replace the table top. 10. INSTALL THE COVER 11. Remove the lock outs. 12. Restore power to the machine. DRIVE CLEAT ROLLS 1. DISCONNECT POWER. 2. Install lock outs to prevent accidental start up. 3. Remove the cover. 4. Unscrew and remove the right hand side table top section. This will expose the auxiliary shafts on which the rolls will be mounted.
-
Page 13: Maintenance
MAINTENANCE GREASE DRIVE GEARS The recommended lubricant is Castrol Molub-Alloy 777-1 or equivalent. Apply grease to all drive gears after every 40 hours of operation. If the machine is to be used in a damp environment, apply a film of oil or grease to all unpainted metal surfaces to prevent rust. CLEANING THE ROLLS Keeping the forming rolls clean is an important step toward efficient operation of your machine. -
Page 14: Trouble Checks
IMPROPERLY FORMED/DEFORMED EDGES -It may be necessary to add a slight lubricant to the surface of the sheet being formed to aid the flow of material through the forming rolls. Lockformer’s GALV-OFF available from FORMTEK is recomended. -The operator may have to experiment with hold down settings for desired results. Run test pieces to check different settings on the hold down nuts or bolts. - Page 15 require exit gauge pressure along the materials edge such as long heavy pieces where an awkward weight and size make it difficult for the operator to hold the piece straight during the forming process. This technique must be used carefully. Other conditions may be causing the runnout, such as loose settings on the hold downs or improperly adjusted entrance gauges (those settings should always be checked first).
- Page 16 LK-20-AGF AUTO GUIDE FLANGING ATTACHMENT...
- Page 17 OPERATING INSTRUCTIONS ADJUST UNIT FOR GAUGE MATERIAL TO BE USED To adjust clearance between flanging rolls, tighten the adjusting screw on the front of the block of the machine all the way, then loosen the screw approximately one eighth of a turn. (This setting is usually correct for 26 gauge material).
- Page 18 INSTALLATION AND OPERATION 1. DISCONNECT POWER – INSTALL ELECTRICAL LOCKOUTS 2. Remove the top cover from the2. Loosen the front mounting screws on spacers # 1 and # 4 Remove spacer #2 Loosen #1, #2 spacer screw 3. Remove spacers #2 and # 3 by removing their mounting screws. Install Auto Guide power Flanger (AGF) Installed Auto Guide power Flanger(AGF)
-
Page 19: Parts Diagram
LK-20 PARTS DIAGRAM FIG.1 Chassis M0B752(T3) M0B754(T5) M0B748(T1) M0B750(T2) M0B752(T4) M0B753(B3) M0B749(B1) M0B757(B5) M0B751(B2) M0B755(B4) M0B758 (10) M0B759 (10) M0B759 (10) 248M2 (4) 248M2 (4) 8G598 8G598 3X667 (4) 8Q536 M0B392 M0B388 M0B391 (2) M0B389 M0B390 M0B684 FIG.2 Opening Roll 1H345 SPRING 91595A712 PIN 5V675 OPENING ROLL... - Page 20 PULLEY FIG.3 Hold Down FIG.4 Straightener Roll SPRING WASHER(8) 96475K92 STUP (2) 96445K236 NUT (4) 90685A045 BEARING 87R78 SPRING WASHER(12) 3G 380 96445K236 5N 261 PIN (2) 5Y067 THRUST WASHER (3) 7814K21 FIG.5 Top PULLEY FIG.6 Exit Gauge 5D228 (2) PULLEY M0B386 FIG.7 Motor Control...
- Page 21 FIG.8 Motor PIG.9 FIG.9 AGF Parts SHAFT 1B 380 MOTOR 1B 367 LIFTER BUTTON 7E158 CASTING 3IQ13 PULLEY FIG.10 AGF Parts BEARING (1 EACH) 5M622 6F482 RACE 96717A 210 2998H OE568 AG22-24025 57485K73 3D799 2Y762 39F33 128M3 2U683 2E135 1T385 1U389...
- Page 22 FIG.11 Center Spacer 71V86 05X23 63J70 CENTER SPACER 8G598...
- Page 23 Due to continuous improvements, FORMTEK reserves the right to modify the product design and specifications contained herein without notice. Please contact your Lockformer sales representative for the most current specification information. Use, publication, or sale of any images or content without the expressed written consent of FORMTEK is strictly prohibited.
