- Page 1 EnPointe Wireless Display Set User Manual EP-K02 EP-D01 EP-P01...
-
Page 2: Table Of Contents
CONTENTS Introduction Setting up the Pocket Boxes Switching the Pocket Box on Pocket Box placement Loose pockets Setting up the Display Box Changing the Display Box’s preferences Touching on Switching off Replacing the Pocket Box’s batteries Checking a Pocket Box’s battery level Important information about replaceable batteries Charging the Display Box Checking the Display Box’s battery level... - Page 3 General troubleshooting guide FAQs Technical specifications Warranty Disposal of product Disclaimer and safety message Compliance information...
-
Page 4: Introduction
This system functions as a wired (reels) system would, without a grounded metallic piste. An EnPointe Piste Box can be added to this set for hit cancellation on metallic pistes. To learn more about the EnPointe wireless fencing range, visit enpointefencing.com or contact our support team at support@enpointefencing.com. - Page 5 Figure 1 The Display Box Weapon select menu Display menu controls Equipment error lights Socket for power supply (DC 9V 2A charger input) Power supply EnPointe logo Introduction...
-
Page 6: Setting Up The Pocket Boxes
Battery compartment EnPointe logo SETTING UP THE POCKET BOXES To begin using your EnPointe Wireless Display Set, place two AAA batteries in the battery compartment of each Pocket Box, shown in Figure 2 h, in the direction indicated. To begin fencing with the Pocket Boxes, plug your three-pronged body wire into the socket at the top of the box, shown in Figure 2 g. -
Page 7: Pocket Box Placement
Extremely loose clothing, or loose pockets in which the Pocket Box could move around, may impact the reliable performance of the EnPointe wireless system. An EnPointe Waistband Clip can be used with clothing that is loose, or for fencers wearing breeches without pockets, to ensure the Pocket Box maintains a reliable connection to the fencer. -
Page 8: Setting Up The Display Box
SETTING UP THE DISPLAY BOX The Display Box will be approximately 30% charged when delivered new. You can turn on the screen by pressing any of the weapon select buttons on the front of the display (shown in Figure 1 a): V U T You are now in ‘fencing mode’... -
Page 9: Touching On
Once you’ve switched on the Display Box by selecting your weapon mode, the screen will show the EnPointe logo to indicate that the system is ready for fencers to touch on. If your weapon is plugged in and connected to your lamé in Foil and Sabre, you can ‘touch on’... -
Page 10: Switching Off
SWITCHING OFF To switch the Display Box off, press the already-selected weapon button (shown in Figure 1 a). The green light on the button will turn off. Any touched on Pocket Boxes will switch off automatically at the same time. If either fencer’s weapon is disconnected for one minute or more, or if no hit of any kind has been made for more than 15 minutes, the system will automatically switch itself off to preserve battery. -
Page 11: Checking A Pocket Box's Battery Level
CHECKING A POCKET BOX’S BATTERY LEVEL The battery level can be viewed by touching the two outer pins on the Pocket Box. The centre pin will glow green (high battery), fade to yellow (medium battery) or red (low battery – around 20% charge). When touching on the Pocket Box, a low battery indicator will be briefly shown on the Display Box screen if that Pocket Box has low batteries. -
Page 12: Charging The Display Box
CHARGING THE DISPLAY BOX Display Box power socket The Display Box uses a rechargeable lithium iron phosphate (LiFePO ) battery. It has a typical battery life of 60 hours of continuous fencing at the default brightness setting, or two months of club use. Lower brightness settings will result in longer battery life, while higher settings will decrease the battery life (down to a typical 15 hours at maximum brightness). - Page 13 The Display Box can still be used for fencing while power is connected and the device is charging. When the Display Box is fully charged, it will automatically disable the charger even if it is plugged in. There is no way to overcharge the battery and it is safe to leave the Display Box plugged in indefinitely.
-
Page 14: Checking The Display Box's Battery Level
Checking the Display Box’s battery level You can check the battery level at any time by scrolling to the ‘battery’ icon in the preferences menu. This screen will display the red, orange, yellow or green levels of battery that indicate the remaining charge. -
Page 15: Using A Piste Box To Cancel Hits To A Metallic Piste
USING A PISTE BOX TO CANCEL HITS TO A METALLIC PISTE With the addition of an EnPointe Piste Box, hits to a metallic piste can be cancelled. Without a Piste Box, the Display Box functions as a wired system would without a metallic piste, with hits to the floor not cancelled for Foil and Épée. -
Page 16: Disconnecting A Piste Box
To re-pair the Piste Box to the Display Box, you will need to touch it on again. For full details on the complete set-up and use of the Piste Box with the EnPointe wireless system, refer to the EnPointe Piste Box (EP-G01) User Manual. -
Page 17: Timing Changes And Updates
firmware (June 2021). Future updates may change the system’s behaviour. Refer to the version release notes available at enpointefencing.com for more information. Any Display Box purchased from EnPointe will be delivered with the latest firmware version pre-installed. WEB BLUETOOTH SUPPORTED BROWSERS To download and install a Display Box update, you’ll need to use an internet... -
Page 18: Installing An Update
Installing an update First, place the Display Box in ‘update mode’ by selecting the update screen in the preferences menu, shown below: Then, touch either of the < > buttons to trigger the screen shown below, indicating that the Display Box is ready to receive an update: Enable Bluetooth technology on your computer, smartphone or tablet. - Page 19 Touch a weapon mode button to switch it back on. The update has not been downloaded and installed successfully. Re-attempt the update process or contact EnPointe Support at support@enpointefencing.com. All Display Box preferences will reset to default after an update is installed. Timing changes and updates...
-
Page 20: Display Box Menu Guide
DISPLAY BOX MENU GUIDE Use the O button to scroll through the menu options. To change the user preferences for a menu option, use the < or > buttons. Brightness The sun icon allows users to change the brightness setting of the Display Box. You can change the level of brightness by using the <... - Page 21 In the first firmware release (June 2021), there are three fencing display styles to choose from. The EnPointe Style (red/green) This is the default display option. It uses the traditional green, red and white colours to denote on and off-targets but has directional shaped arrows that indicate which fencer has made the hit.
- Page 22 Troubleshooting The troubleshooting and error lights setting and error lights enables additional error lights, including the loose pocket and lamé-disconnected lights. When enabled, the off-target lights will also signal a disconnected weapon for Épée. Use the < > buttons to switch the troubleshooting and error lights on or off.
- Page 23 Updates The update mode allows users to download firmware updates to the Display Box using Bluetooth wireless technology. To learn how to install an update, refer to the instructions on page 17. This icon indicates that update mode has been selected. Touch either of the the <...
- Page 24 Piste Box These icons indicate the status of a Piste Box connected to the Display Box. To learn how to connect and disconnect a Piste Box, refer to the instructions on page 15. This icon indicates that a Piste Box has been successfully paired with the Display Box and is active.
-
Page 25: Warning Lights And Screens
WARNING LIGHTS AND SCREENS Error light Cause/solution The Display Box’s equipment error These lights are lit when the system detects lights (Figure 1 c) are lit for both that no Pocket Boxes have been touched on. sides of the Piste. Once you are plugged in and touched on, the lights will turn off. - Page 26 You can still fence with this light flashing, but in extreme circumstances, system performance may be impacted. If you are fencing with loose pockets or no pockets, an EnPointe Waistband Clip is a great way to ensure that that Pocket Box maintains consistent contact with the fencer.
- Page 27 To rectify this, make sure the Pocket Box sits securely in the pocket. Also ensure that the Pocket Box is inserted in the pocket with the EnPointe logo facing away from the body. You can still fence while this error light appears, but system performance may be impacted in extreme circumstances.
- Page 28 A large battery icon appears when This indicates that the Display Box has low I turn on the Display Box. battery and may need to be charged soon. The off-target light(s) on the Display As with a wired system, you may be fencing Box are appearing unexpectedly and with a body wire that needs replacing.
-
Page 29: Troubleshooting A Communication Error
The communication error icon This indicates that a communication link appears, not allowing us to fence. cannot be sustained between the Pocket Boxes and the Display Box. The Display Box will attempt to reconnect, and this icon will be shown if the Pocket Box is disconnected for a sustained period of time. - Page 30 If you have sufficient battery and you’ve tried to improve the radio connectivity using the steps above, you should not continue to experience this issue. If the issue persists, it’s possible your EnPointe system is encountering unprecedented amounts of interference from other electronic devices. For example, you may be fencing near radio transmission devices that aren’t...
-
Page 31: General Troubleshooting Guide
— Your weapon and lamé are plugged in. — Your Pocket Box is sitting snug in the back pocket with the EnPointe logo facing away from your body. Also ensure that it is maintaining continuous contact with your body. -
Page 32: Faqs
EnPointe system functions in the same (reels) system? manner as a wired system. In normal use, the EnPointe system follows the same timing and light decisions of standard reels in all three weapons. It adheres to all FIE guidelines on wireless scoring as outlined in their wireless 2016 test protocol. -
Page 33: Technical Specifications
TECHNICAL SPECIFICATIONS Power supply Display Box Internal LiFePO 3.2V 4200mAh battery; DC 9V 2A charger input Pocket Boxes 2 x AAA batteries per Pocket Box Battery life Display Box Approximately 60 hours on one charge. Pocket Boxes Approximately 90 hours on one set of batteries. - Page 34 Encryption protocol AES-128 authenticated encryption Operating temperature range 0 to 50 degrees Celcius Charging temperature range 0 to 45 degrees Celcius Technical specifications...
-
Page 35: Warranty
WARRANTY The warranty for this EnPointe product is valid for twelve months from the date of purchase. The warranty includes free repair for any defects in materials or assembly. It does not include shipping costs. If you encounter a major fault or defective system, you must stop using the system and contact EnPointe immediately to ensure you are eligible for a warranty claim. -
Page 36: Disposal Of Product
For more information about how to designate your EnPointe Fencing System or Piste Box for recycling, contact our support team at support@enpointefencing.com. - Page 37 FCC COMPLIANCE NOTICE Contains FCC ID: SQGBL652 This device complies with part 15 of the FCC Rules. Operation is to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 38 Bluetooth ® SIG, Inc. and any use of such marks by EnPointe Fencing Pty Ltd is under license. Other trademarks and trade names are those of their respective owners. EnPointe Fencing and the EnPointe Fencing logo are registered trademarks.
- Page 40 Designed & made in Australia enpointefencing.com E N P O I N T E...
