Polargos EASY WAY PACK 201 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Manual
EASY WAY PACK 201
AUTOMATIC GATE
INTELLIGATE
smart gate

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EASY WAY PACK 201 and is the answer not in the manual?

Questions and answers

Summary of Contents for Polargos EASY WAY PACK 201

  • Page 1 Manual EASY WAY PACK 201 AUTOMATIC GATE INTELLIGATE smart gate...
  • Page 2 EASY WAY PACK 201 AUTOMATIC GATE 4 sets 2 sets 8 sets *The carriage bolt is intended for installing the gate on 70 x 70 mm steel posts - in the event of installing the gate on 100 x 100...
  • Page 3 INTELLIGATE SMART GATE 4 sets 2 sets 8 sets *The carriage bolt is intended for installing the gate on 70 x 70 mm steel posts - in the event of installing the gate on 100 x 100 mm steel posts it is necessary to obtain 8 sets of M8 x 120 mm carriage bolts, and for 120 x 120 mm steel posts it is necessary to obtain 8 sets of M8 x 140 mm carriage bolts.

  • Page 5: Table Of Contents

    Table of contents User training Introduction Safety principles Advanced settings Opening that enables passage of pedestrians Information on batteries Recycling and disposal of waste equipment Automatic closing Compliance with regulations Remote control programming Risk prevention Presentation of remote control devices Specification of danger zones Adding a remote control device Safety measures aiming at eliminating risk...

  • Page 6: Introduction

    “fashion” on the fencing market. Thank you for your trust and choosing the EASY WAY PACK 201 device and Intelligate. We would like to ask you to become thoroughly familiar with this manual prior to commencing installation.

  • Page 7: Safety Principles

    POLARGOS declares hereby that the product complies with the fundamental requirements and other applicable provisions of the Directive 1999/5/CE. The declaration of conformity is available at the online address www.polargos.pl...

  • Page 8: Information On Batteries

    Compliance with regulations POLARGOS declares hereby that on condition of being used according the recommended provided, the product described in this manual meets the essential requirement of the binding European Directives, and in particular those of the Machinery Directive 2006/42/CE and Radio Equipment Directive 2015/53/EU.

  • Page 9: Safety Measures Aiming At Eliminating Risk

    Safety measures aiming at eliminating risk Photocells ZONE 1 Risk of impact and crushing Solution: System for detection of obstacles within the drive Photocells. ZONE 2 Shearing and crushing risk to hands min. 10 cm Post bevel Solution: If the system features a shearing zone: leave a spacing of at least 10 cm between the wing and the post/wall bevel the corner without weakening...

  • Page 10: Product Presentation

    Product presentation This product is intended for gates used in detached house construction. Technical data Type EASY WAY 201 Power supply voltage 230 V~ / Solar power system 24 V Drive type 24 V Drive power 120 W Max. energy consumption (incl. gate zone lighting) 600W Power consumption in standby mode 3 W (without accessories)

  • Page 11: Wing Dimensions And Maximum Weight

    Wing dimensions and maximum weight The width of each wing should be between 1 m and “L”. Maximum opening angle for the hinges installed on the side of the post for standard hinges • The gate opening angle should be within the range from 85 to 95 degrees.

  • Page 12: Preparation To Installation

    Preparation to installation Points to be checked prior to performing the installation • Gate control The gate is in good technical condition: it opens and closes without using force. During the whole cycle of movement the gate remains in horizontal position. It opens to the inside of the property. Middle rail Fixing bracket Post - (metal or...

  • Page 13: Tools Required

    Tools required tape measure pencil cutter spirit level cross screwdriver flat wrench 13 flat screwdriver flat wrench 17 hammer drill wire stripping pincers socket wrench 13 and 10 pliers distribution box clamp...

  • Page 14: Preliminary Electric Wiring System

    Preliminary electric wiring system In order the install the gate drive it is necessary to: • Lead 230 V power supply to one of the posts located as close to the drive as possible. • Connect the posts with one another using a 2 x 1 mm2 cable that is not included in the set. Other than that, it is necessary to obtain an IP55 distribution box for securing the connection between the cable going out from the drive and the extension reaching the control module.

  • Page 15: Preparation Of Connectors

    Preparation of connectors In the case No. we use the M8 x 85 carriage bolts included in the set. NOTE: View from the property side! 70x70 POST 70x70 POST NOTE: View from above! 8 SETS LEFT POST RIGHT POST RIGHT CONNECTOR LEFT CONNECTOR In the case No.
  • Page 16 In the case No. , it is necessary to obtain 8 sets of M8 x 140 mm carriage bolts at the 120x120 mm steel posts NOTE: View from the property side! 120x120 POST 120x120 POST NOTE: View from above! 8 SETS LEFT POST RIGHT POST LEFT CONNECTOR...

  • Page 17: Installation Of Automatics

    Installation of automatics Gate preparation 1. Arrange the gate wings horizontally. View from the property side 2. Establish the location of the automatics. Mandrel ejected to the maximum. 3. The set prepared should be applied to the previous levelled, closed gate. The automatics should not rub against the fixture to the gate. 70x70 POST View from the...
  • Page 18 4. Check which kind of fixture is present in you gate Profile without openings Profile with factory-made through openings Profile with threaded openings Reinforced profile with openings Profile with longitudinal openings...
  • Page 19 Gate type No. 5. Hold the position of the L and R connectors using a clamp. The actuator mandrel is ejected to the maximum towards the internal limiter when the closed gate adheres to the limiter in the ground. View from property side Mark the points for drilling...
  • Page 20 6. Attach the fixture to the gate using bolts. The fixture to the gate should be positioned in such a way as to enable further adjustment by means of gentle movements (tighten the bolts so that slight resistance can be felt). 7.
  • Page 21 9. Install the automatic device onto the properly installed fixtures. 10. Remove the automatics Select one opening on the fixture that does not interfere with the picket. At the opening location, drill the gate middle rail through with a drill bit. Next, from the side of the street, ream the opening made with a drill bit.
  • Page 22 Gate type No. 11. Hold the position of the L and R connectors using a clamp. The actuator mandrel is ejected to the maximum towards the internal limiter when the closed gate adheres to the limiter in the ground. View from the property side fixing into 2...
  • Page 23 Gate type No. 13. Hold the position of the L and R connectors using a clamp. The actuator mandrel is ejected to the maximum towards the internal limiter when the closed gate adheres to the limiter in the ground. View from the property side Use M8 x 50 bolts...
  • Page 24 Gate type No. 15. Hold the position of the L and R connectors using a clamp. The actuator mandrel is ejected to the maximum towards the internal limiter when the closed gate adheres to the limiter in the ground. View from the property side Dismantle the picket reinforcement Insert M8x16 carriage...
  • Page 25 Gate type No. 18. Hold the position of the L and R connectors using a clamp. The actuator mandrel is ejected to the maximum towards the internal limiter when the closed gate adheres to the limiter in the ground. View from the property side Slide the carriage bolts into the openings in the gate profile.
  • Page 26 Installation of a clamp fixing the V1 or V2 wing 20. Install the unlocking element (D) on the clamp fixing the (V1) or (V2) wing using the bolt (C). In order to use the unlocking element properly, it is necessary to maintain the installation direction specified on the diagram.
  • Page 27 23. Setting the opening limiter Push the button No. 1 of the remote control device. After a few seconds, the first wing of the gate will start opening slowly. Push again the button No. 1 of the remote control device in order to stop the gate wing in the position desired.

  • Page 28: Electrical Connection

    Electrical connection Stages • Placement of the electrical distribution board on a post. • Fixing the electrical distribution board to a post. • Connection of two actuators. • Connection of the antenna. • Connection to the mains power supply or solar plant power supply. Placement of the electrical distribution board on a post The box should be installed on the side of the power supply source.

  • Page 29: Fixing The Electrical Distribution Board To A Post

    Fixing the electrical distribution board to a post Location of the control module on a post/wall 1. The module should be installed on the side of the power supply Installation of a sealing cord 2. Introduce the sealing cord (13) into the top part of the control module. Fixing the control module to the post Place the angle bar fixing the module near the post/wall.

  • Page 30: Connection Of Drives

    Remove the bottom of the module and then drill an opening through the post/wall. Determine the diameter of the opening on the basis of the type of bolts used for fixing. Fix the bottom of the module to the post/wall: 1 bolt for fixing the module to the angle bar + 2 bolts for fixing the module to the post/wall.

  • Page 31: Connection Of Two Actuators

    Connection of two actuators 1. The connection between the actuators and the electrical distribution box has to be made prior to connecting that box to the mains. The M1 actuator has to be installed on the post of the wing that opens first and closes last. The M1 actuator starts the right wing, which opens first and closes last.
  • Page 32 1. Connect the earthing cable in the fuse box. The earthing cable (green/yellow) will be necessary in case of certain accessories (Class I 230 V lighting). 2. Connect the phase and the zero point. Check whether the cables are locked properly by pulling them. 3.

  • Page 33: Startup And Standard Use

    5. Close the control module housing and screw in the cover Startup and standard use Stages • Explanation of symbols used. • Remote control device programming. • Learning the wing movement path. • Adjustment of the automatic system. • Switching from automatic mode to sequential mode. •...

  • Page 34: Turning On The Power Supply For The System

    The drive provides 2 modes of functioning: • Only full opening Full opening of 2 wings through short or longer press of a remote control device button. • Opening that enables passage of a pedestrian, or full opening Opening of only a single wing through short press of the remote control device button, in order to enable passage of a pedestrian.

  • Page 35: Setting The Electronic Control System Standby/Wake-Up Mode

    Do not interrupt gate movement (full opening/closing). In the even of the gate movement being interrupted, learning will be resumed automatically during the next opening. If the status light flashes, resume the automatic wing movement path learning procedure (4 full opening and closing movements). If the status light keep flashing, see “Diagnostics”, page 49.

  • Page 36: Obstacle Detection

    Push the button No. 1 of the remote control device in order to open the gate fully. Gate in motion: push the button No. 1 of the remote control device in order to stop the gate. Gate open: push the button No. 1 of the remote control device in order to close the gate.
  • Page 37 Activation of the opening mode that enables passage of pedestrians Button No. 1 of remote control devices with 2 or 4 buttons cannot be programmed for controlling the gate opening mode that enables passage of pedestrians. See “Presentation of remote control devices”, page 40, in order to obtain additional information.

  • Page 38: Automatic Closing

    Automatic closing The method of functioning of the automatic closing mode The gates closes after 30 seconds or after 5 seconds in case of detection passage through the photocells. Automatic closing of the gate can be interrupted by pushing the button No. 1 of the remote control device. In order to close the gate it is necessary to push again the button No.
  • Page 39 Deactivation of automatic closing 2. Put the remote control device on the 3. Hold the pressed button No. 1 of the 1. Press and hold for 2 s the dial of the electronic control system. remote control device until the status button of the electronic control light starts flashing.

  • Page 40: Remote Control Programming

    Remote control programming Presentation of remote control devices The Somfy RTS remote control devices may control, according to the settings selected: • full gate opening • gate opening that enables passage of pedestrians • other Somfy RTS equipment (e.g. garage door drive, roller blinds, etc.) Remote control Remote control device with 2...

  • Page 41: Adding A Remote Control Device

    Method of using a remote control device with 3 buttons In order to open the gate fully, it is necessary to push the «Up» button of the remote control device. Opening In order to stop the gate while it moves, push the middle button of the remote control device. Stop In order to close the gate, it is necessary to push the «Down»...

  • Page 42: Cabling Of Accessories

    Cabling of accessories Due to safety reasons these activities have to be performed with the power supply disconnected. It is recommended to perform automatic learning of the gate travel path before connecting accessories (photocells, orange light, etc.) Photocells / Intelligate gate The photocells enable stopping or changing the movement direction of the gate in the event of detecting an obstacle.

  • Page 43: Orange Light (Option)

    The cabling of the second set of photocells is not possible to make in case of this drive assembly. Installation After connecting the cables to the photocells it is necessary to: • turn off the drive’s power supply, • launch the gate opening and closing mode. Photocells are recognised by the electronic control system after this movement is finished.

  • Page 44: Battery (Option)

    Battery (option) This element is not compatible with solar energy powering. In order to extend the battery functioning time, the wired control system become disconnected; the gate is controlled only by means of remote controlled devices and radio transmitters. Spare battery The spare battery ensures that the gate operates at low speed in the event of any electrical malfunction.

  • Page 45: Independent Antenna (Option)

    Independent antenna (option) An independent antenna characterised by greater range may replace the wired antenna. It is necessary to place it on top of the post and check whether it is not obscured. The antenna is connected to terminals 1 and 2 (blue “ANT” sticker) of the control module: the cable core goes to terminal 1, while the ground wire bundle - to terminal 2.

  • Page 46: Key Switch (Option)

    Key switch (option) This element is not compatible with solar energy powering. Zone lighting (option) This element is not compatible with solar energy powering. For zone lighting only halogen or incandescent lamp with maximum power of 500 W should be used. Zone lighting functioning The zone lighting lights up every time when the drive is started.

  • Page 47: Help In Removal Of Malfunctions

    Technical support If the defect is still present, if another problem appears, or if you have any questions regarding the driver assembly, visit our website: www.polargos.pl Battery replacement in a remote control device The battery lifetime is usually 2 years...

  • Page 48: Locking / Unlocking Of Drives

    1. Press and hold for 2 s the 2. Put the remote control 3. Hold the pressed button No. 1 4. Push the button No. 1 of the device on the dial of the of the remote control device remote control device once. The button of the electronic control system.

  • Page 49: Diagnostics

    Diagnostics DIAGNOSTICS REMOVAL OF MALFUNCTIONS The drives do not react to the Limited remote control device range - Check the remote control device battery (see control commands from the “Replacement of the remote control device remote control device battery”). - Check the antenna of the control module (cables, location, see page 30).

  • Page 50: The Most Important Functions

    Smart gate - controlled by means of mobile devices The most important functions • Opening of a gate and garage door, turning off the alarm, and turning on the lighting prior to returning home. • Automatic closing after parking the vehicle. •...

  • Page 51: Installation Of A Smart Gate System

    Installation of a smart gate system 1. Install the gate with Easy Way Pack 201i automatics Perform the steps on pages 6-42. Remember to connect the photocells included in the smart gate set. Before installing the Intelligate smart gate check whether the remote control devices are programmed correctly - see pages: 40-41.

  • Page 52: Activation Of The Connexoon Controller

    Activation of the Connexoon controller 1. Connect with the somfy-connect.com website. Check whether the Connexoon unit and the online access providing device are connected properly using an Ethernet cable (green LED status light). 1. Launch 2. Connection status Problem with online connection The LED status light indicates the unit status...
  • Page 53 Stage 4 Stage 3 If the selection window appears, choose the Enter the PIN code of your Connexoon controller. Connexoon Access RTS The individual code is located on the bottom of the controlling device. Stages of activation of Connexoon Access RTS Stage 5 Stage 6 Create your login and password.
  • Page 54 Stage 7 Stage 8 Check the information. Confirm. Activation of the Connexoon controller - reception of the confirmation e-mail Stage 9 You will receive a confirmation e-mail. In order to complete the activation of the Connexoon controller, click the “Click here” link. SMART GATE...

  • Page 55: Downloading Of The Connexoon Access Rts Application To A Mobile

    Downloading of the Connexoon Access RTS application to a mobile phone Download the Connexoon Access RTS application available for iOS and Android operating system to your mobile phone Specify your identifier. The identifier enables Enter the e-mail address and password that checking which activities have been performed you specified during activation of the using the mobile phone.
  • Page 56 After downloading the Connexoon Access application to your mobile phone, accept the declarations in line with the guidelines below: 1. Accept the statement 2. Click the question mark Click here Click here Click here 4. Mark SGS 201/400/501/601 3. Press the TEST button in order to check the S.C.

  • Page 57: Operation Of The Connexoon Access Rts Control Device

    5. Change the name form “Unknown component” to your own, e.g. Intelligate 6. Click on SAVE. Operation of the CONNEXOON ACCESS RTS control device 1. Interface Menu Weather Mode editor Own modes Devices registered in Connexoon SMART GATE...
  • Page 58 2. Control over devices Click the icon and select the gate position: open/close, You can control a gate, garage door, lighting, etc. in and then press the grey frame located at the bottom of the interface. Press the icon of the device that you want to control by moving the list to the right or to the left (example: garage door).
  • Page 59 Open all/Close all When returning or leaving, one can open or close the gate and/or the garage door and turn the external lighting on or off using a single button press. In order to adjust then “open all/close all” mode to your own need, press the button Next, press the...
  • Page 60 Leaving When leaving home, you can open the gate with one press of a button, and it will close automatically after a time that you specified. In order to adjust then “Leaving” mode to your own need, press the symbol of the icon.
  • Page 61 Returning Thanks to geolocation, your home welcomes you when you come back. Specify at what distance from home the automatic devices specified should be turned on. E.g. I activate the “Returning” mode after work when leaving my office. Geolocation is active and my home welcomes me in the manner that I specified.
  • Page 62 4. System management Pressing the symbol enables accessing the functions of parameter setting and managing the Connexoon Access RTS application: • table of indicators, • messages, • parameters, • account, • help, • signing out from the application. The “configuration” menu enables access to advanced installation functions (see chapter 5). SMART GATE...
  • Page 63 Table of indicators This menu enables visualising the history of all the devices connected, with a single button press. • A green spot preceding a command means that everything went well. • A red spot means that the command was interrupted purposefully. •...
  • Page 64 Messages The messages of Connexoon contain all the information regarding updates and future novelties. SMART GATE...
  • Page 65 Parameters Possibility of home geolocation in order to receive local weather information. Turning weather information on the home page on/off. Turning alarms sent via e-mail on/off. In this menu you can turn on displaying the weather data, as well as activate alarms sent via e-mail and/or “push” notifications.
  • Page 66 My account This sheet includes the information provided during the activation of Connexoon. SMART GATE...
  • Page 67 Help You can fill in this sheet yourself or have it filled by the fitter in order to enable direct contact with them in case of ha ving any questions. Remain in contact with the fitter, entering their contact data in the application. Then you can contact them with a single button press.
  • Page 68 5. Advanced system functions This menu enables: • registering new compatible devices in the Connexoon application, • deleting/changing device names, • managing the system security key. In order to gain access to these functions, press the icon. SMART GATE...
  • Page 69 Changing product names in the application Press the menu icon Press the “Configuration” tab button Press the pencil icon to the right of the device in order to change its name SMART GATE...
  • Page 70 You can change the name of your products by clicking the “name” field in the grey rectangle at the top of the screen. In order to check whether the product is correct, click the “Identify” button. The device will move in one direction and back, or it will flash. In order to stop the identification, press the “stop”...
  • Page 71 Registering RTS devices in the CONNEXOON unit Press the menu icon Press the “Configuration” tab button Press the button SMART GATE...
  • Page 72 Select the type of product that you want to add to the system: The RTS drives/actuators or Philips Hue lights, and then confirm this by pressing button. Select the icon representing the product that you want to register in the unit. Check the product by moving it using a wall controller or a remote control device.
  • Page 73 Press the PROG button of the command activating the product added, holding it until the product moves in one direction and back (or flashes). From that moment on, you have 2 seconds to confirm this by pressing the “Add” button. Check whether the product has been registered correctly by pressing the “Test”...
  • Page 74 Name the product and then click OK The product will appear on the list then. SMART GATE...
  • Page 75 Removal of RTS products in the application Press the button. Check the product by controlling it using a wall controller or a remote control device. Make sure that the controlling element activates only the removed product. Press the PROG button of the command activating the product removed and hold the button for about 3 seconds until the product moves in one direction and back (or flashes).
  • Page 76 Check whether the product has been removed properly by pressing the “Test” button. If the product has been removed properly, it will not answer. Press the OK button if the product did not move or click “Restart” if it was closed.
  • Page 77 The SELECT button enables selecting a channel (6 channels are available) The USB port enables powering the Connexoon unit with a power supply cable. The PROG button enables registering accessory product of Somfy in the Connexoon RTS unit without online The LAN network socket enables connecting the connection (Manual included in the Connexoon unit directly to the Internet using an...
