INSTALLATION INSTRUCTIONS
E-WKL Series
INSTALLATION
NOTE: Requires E-WKLA01A-NM40BLU or E-WKLA05A-NM40BLU
Fixture.
Preparing The Tripod- See Figure 1
1.
Loosen the tripod screw and move the support legs away from the
center tube of the tripod.
2.
Push down on the leg connector until the support legs are fully
extended. Tighten the tripod screw.
3.
Adjust the height of the tripod by loosening the black twist collar
on the center tube and raise the pole section.
4.
Firmly tighten the twist collar once the tripod is adjusted to the
desired height.
Attaching The Worklight To The Tripod- See Figure 1
1.
Position the center of the fixture stand over the center of the
tripod. Insert the quick connect on the base of the stand into the
top of the tripod.
2.
Push the lever on the tripod to lock the fixture stand in place.
3.
To unlock the stand from the tripod, pull the lever back and lift the
fixture away.
Tripod
www.e-conolight.com
Document:
Created By:
FIGURE 1
Quick Connect
Screw
|
888.243.9445
|
FAX: 262.504.5409
Date
DCR#
Twist Collar
Leg Connector
Tripod Screw
