- Page 1 Switching Power Supplies PS3V Compact & Reliable Power Supplies Flexible installation allows mounting in four directions...
- Page 2 Suitable for downsizing of equipm Compact & efficient switching power supplies Actual size Suitable for downsizing of equipment Compact (Image: 15W type) Compact size 50.8 (mm) Operates in a wide temperature range from Temperature Derating Temperature Derating –25 to +70°C. Suitable for use in a wide temperature range from cold to hot environment.
- Page 3 Logistics and transport facilities Agricultural facilities Energy-related facilities, others Vibration-resistant and maintenance-free (no retightening of IDEC’s reliable technology enable stable power supply and its screws). Push-in improves ef ciency in limited spaces. compact size allows installation in small equipment.
-
Page 4: Switching Power Supplies
PS3V-100AF PS9Z-3E4D PS3V-150AF *2) PS3X L-shaped mounting brackets (PS9Z-3N3B) cannot be used. L-shaped mounting bracket is not available for PS3V-150AF. PS9Z-3N3B L-shaped mounting brackets cannot be used for PS3V-150AF. DIN rail/End clip/Tools Specify the Ordering no. when ordering. Name Part No. -
Page 5: Specifications
*1) Not subjected to safety standards. Output delay also available. *2) If overload continues for over 30 seconds, the internal elements may be damaged. PS3V-015AF is equipped with a thermal shutdown function. When thermal shutdown operates, auto reset does not function until the temperature inside the power supply drops. -
Page 6: Block Diagram
PS3V Switching Power Supplies Block diagram PS3V-015AF PS3V-030AF, PS3V-050AF Fuse Fuse INPUT INPUT –V – Control V.ADJ V.ADJ Detection Detection PS3V-100AF, PS3V-150AF Fuse INPUT – V.ADJ Detection Characteristics Output current - Operating temperature characteristics (Output derating) Overcurrent protection characteristics * Conditions: Natural air cooling (operating temperature is the temperature around the... -
Page 7: Mounting Direction
PS3V Switching Power Supplies Mounting direction upward A mount D mount B mount C mount (standard mount) Parts Description Note) Note the terminal arrangement when wiring. Horizontal terminal type PS3V-015AF PS3V-030AF PS3V-050AF PS3V-100AF PS3V-100AF AC (L) AC (L) AC （ N）... - Page 8 PS3V Switching Power Supplies Dimensions All dimensions in mm. General tolerance: ±1 mm PS3V-050AFC PS3V-100AF24C (123.5) 2-M3 (114.5) (Depth 6mm max) 2-M3 (Depth 6mm max) 5-M3.5 23.5 12.5 5-M3.5 (Terminal Screw) (Terminal Screw) 3-M3 2-M3 (Depth 6mm max) (Depth 6mm max) PS3V-150AF24C (174.5)
-
Page 9: Safety Precautions
• Blown fuses indicate that the internal circuits are damaged. Contact • When using the product, follow the following precautions. IDEC for repair. If only the fuse is replaced, electric shock, fire, or malfunction may occur. [Precautions on switching power supplies] •... -
Page 10: Overcurrent Protection
Small acoustic noise inside the PS3V may be heard depending on the Mounting panel input voltage and load, but the performance of the PS3V is not affected. Mounting screw 4. Do not close the openings of the switching power supply. Ensure Series operation proper heat dissipation by convection. -
Page 11: Wiring Procedure
If we are responsible for a failure that occurs during the warranty period described at left, we will repair the product or replace it with an IDEC warranties the PS3V switching power supplies for a period of five alternative product. - Page 12 IDEC product fails Furthermore, the warranty described here refers to a warranty on the IDEC product as a unit, and damages induced by the failure of an IDEC product are iii. Wiring and installation that ensures the IDEC product used in your excluded from this warranty.
