REYNAERS 062.8262. Installation And Testing Manual

Manually slide and electric lock + preparations for potential conversion to motorized sliding
Hide thumbs
Table of Contents

Advertisement

Quick Links

Electric lock: 062.8262.-- Installation and testing
Manual for the installer & electrician.
Manually slide and electric lock + Preparations for
potential conversion to motorized sliding
Version: 3-12-2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 062.8262. and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for REYNAERS 062.8262.

  • Page 1 Electric lock: 062.8262.-- Installation and testing Manual for the installer & electrician. Manually slide and electric lock + Preparations for potential conversion to motorized sliding Version: 3-12-2020...

  • Page 2: Table Of Contents

    Statement of Conditions In the interest of improving internal design, operational function, and/or reliability, Reynaers Aluminium reserves the right to make changes to the products described in this document without notice. Reynaers Aluminium does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.

  • Page 3: Safety Information

    Safety information It is very important to have the Reynaers Hi-Finity Training before You start to order, construct or install. In this way, You are certified. The installation, connection and commissioning of electrical equipment must be carried out by a qualified electrician.

  • Page 4: Choosing The Right Assembly

    2.1.1 Choosing the right assembly The electric lock can be assembled as standard electric lock or pre-assembled for an easy upgrade to a motorised Hi-Finity solution later-on. Both solutions use the same electric lock but different wires, millings and adapters in the system and connection to the vent.
  • Page 5 Electrical parts R-SWITCH MANUAL SWITCH INPUT (061.8478.--) ELECTRICAL CABINET 24V - 5.5A (062.8246.--) DIN-RAIL POWER SUPPLY 24VDC – 0.75AMPS (062.8623.--) BUILD-IN POWER SUPPLY 24VDC – 0.75AMPS (062.8624.--) DIN-RAIL POWER SUPPLY 24VDC – 1.75AMPS (062.8647.--) DIN-RAIL POWER SUPPLY 24VDC – 4.2AMPS (062.8595.--) DIN-RAIL UNINTERRUPTED POWER SUPPLY 24VDC BATTERY BACKUP...
  • Page 6 Cables POWER SUPPLY CABLE 10M (062.8217.--) POWER SUPPLY CABLE 3M POWER - ALARM – BUTTON (3-in-1) (062.8583.--) POWER SUPPLY CABLE 10M POWER - ALARM – BUTTON (3-in-1) (062.8584.--) Only to be used if 062.8217.-- and 062.8219.-- or 062.8222.-- or 062.8547 is not been selected CABLE 10M FOR PUSH BUTTON Installer sources push button (062.8219.--)

  • Page 7: Additional/Other Finishing Parts For Pre-Motorised Element

    2.1.3 Additional/other finishing parts for pre-motorised element COVER PLATE RETURN PULLEY (062.8257.XX) COVER PLATE SLIDE MOTOR (062.8258.XX) CONNECTION ROD SYSTEM (062.8259.--) Do not use connecting rod (062.9551.--) POWER EXTENSION CABLE 5M (062.8681.--) PUSH BUTTON EXTENSION CABLE 5M (062.8682.--) LOCK CABLE FOR SLIDING WINDOW MOTOR 5M Needs to be pre-installed - not possible afterwards (062.8546.--) EXTENSION CABLE ALARM CONTACT 5M...

  • Page 8: Finishing Parts For Conversion To A Motorised Element

    2.1.4 Finishing parts for conversion to a motorised element R-ADAPTER (LOCK INPUT: SLIDE MOTOR + ELECTRIC LOCK) (062.8296.--) Replaces: 061.8478.-- SLIDING WINDOW MOTOR 50W (062.8252.-- ) SLIDING WINDOW MOTOR DOCKING UNIT (062.8254.--) Replaces: 062.8681.-- + 062.8682.-- TIMING BELT 10M (062.8549.--) TIMING BELT 30M (062.8256.--) SLIDING WINDOW MOTOR RETURN PULLEY...

  • Page 9: Assembly And Installation

    3 Assembly and installation Legend title meaning  belt List item Note or Warning The element ... ▲1 Assembly step Set with art. n° or part of a set with art.n° 062.8262.-- Safety Information Assembly / installation order The various subsystems were described in section 2.1. Assembly is done in the following order: 1 Workshop preparations ...
  • Page 10 : R-S 061.8478.-- WITCH BOX ▲3 Install the lock and lock bracket ▲4 Protect the wires, electronics and electric devices for transport preventing damages. Electric devices are not water proof Hi-Finity electric lock: Installation and testing – Manual for the installer & electrician II&E2020_11...

  • Page 11: Electric Lock Upgrade Ready

    3.1.2 Electric lock upgrade ready The top profile millings (see catalogue) are >1meter from the edge of the Hi-Finity moving glass pane. ▲1 Check the millings  Milling for lock  Milling for slide motor  Milling for return pulley ...

  • Page 12: Electric Lock Upgrade To Motorization

    The installation of this product will be part of a motorised window. Motorised windows involve a risk of crushing body parts and collision. For safety reasons only Reynaers Aluminium catalogue articles can be used to complete the system. The checklists for...

  • Page 13: Onsite Electric Connections

    3.2 Onsite electric connections For detailed electric wiring diagrams please visit your customer portal on our website https://www.reynaers.com/en/reynaers-customer-portal-en > Access Control 3.2.1 Power connection The installation has to be done by a professional conform local regulations. Please install an uninterrupted power supply (UPS) with battery to prevent inconvenient behaviour during power outages.

  • Page 14: Onsite Completion Mechanical Installation

    3.3 Onsite completion mechanical installation 3.3.1 Assembly of the connection rod For both assembly options (standard or pre-motor ), the 062.9551.-- 062.8259.-- connection rod has the same principles on installation. Check if the lock is connected to the power supply, a button and is working before installing the connection rod.

  • Page 15: Change Operandi Modus

    3.3.3 Change operandi modus Warning: Do not lock yourself out. Check if a 2 entrance into the building is available when changing the settings. By default the lock will not drop down when the vent is in closed position : this is a safety modus for balconies where only 1 entrance to the building is possible.

  • Page 16: Liability And Guarantee

    The guarantee ceases to apply if unauthorised modifications were made to the product. Further information on the guarantee can be found in the “Reynaers guarantee 20xx” document, available on the Reynaers website.

  • Page 17: Faq

    6 FAQ  By default, when is the LED on/off? o If the window is locked: LED is off o If the window is unlocked: LED in on o If the lock should lock, but pen is still up: LED will blink o If dipswitch2 on R-Switch box is changed, LED functionality will be inverted ...

  • Page 18: Technical Specifications

    7 Technical specifications 7.1 Electric drawings Hi-Finity electric lock: Installation and testing – Manual for the installer & electrician II&E2020_11...
  • Page 19 Hi-Finity electric lock: Installation and testing – Manual for the installer & electrician II&E2020_11...
  • Page 20 Hi-Finity electric lock: Installation and testing – Manual for the installer & electrician II&E2020_11...

  • Page 21: Connecting The Alarm Output

    Please remark that when there is no power on the R-Switch box, the contact between Pin1 and Pin3 will be open. More detailed information is available on http://www.reynaers.com/ Hi-Finity electric lock: Installation and testing – Manual for the installer & electrician II&E2020_11...
  • Page 22 Electric lock 062.8262.--  Stainless steel bolt – fail secure Model  24V – 0,75Amps Input  Voltage tolerance 22-30VDC  Protection class IP20  Dimensions Body 200 (L) x 32(W) x 46(D) (mm)  Dimensions Bolt 17(Throw) x 15.5(Diameter) (mm) ...
  • Page 23 REYNAERS ALUMINIUM NV/SA Oude Liersebaan 266 • B-2570 Duffel t +32 15 30 85 00 • f +32 15 30 86 00 www.reynaers.com • info@reynaers.com Hi-Finity electric lock: Installation and testing – Manual for the installer & electrician II&E2020_11...
