75-70681
TR270 TERRA RAKE
(S/N 0000 and higher)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TR270 TERRA and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Steiner TR270 TERRA

Summary of Contents for Steiner TR270 TERRA

  • Page 1 75-70681 TR270 TERRA RAKE (S/N 0000 and higher)

  • Page 2: Table Of Contents

    TABLE OF CONTENTS TERRA RAKE CALIFORNIA PROPOSITION 65 WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. ADVERTENCIA: Cáncer y Dãno Reproductivo - www.65Warnings.ca.gov. IMPORTANT MESSAGE Thank you for purchasing this Schiller Grounds Care, Inc. product. You have purchased a world class product, one of the best designed and built anywhere.

  • Page 3: Description / Specifications

    The TR270 Terra Rake comes with the Steiner Quick Hitch attachment system for easy installation or removal in minutes without any tools. The Terra Rake can also be mounted to the rear 3-point hitch with a Steiner 3-Point Quick Hitch SPECIFICATIONS Specifications are subject to change without notice.

  • Page 4: Safety

    SAFETY TERRA RAKE This symbol means: NOTICE !!! ATTENTION! Unauthorized modifications may present extreme BECOME ALERT! safety hazards to operators and bystanders and could also result in product damage. Your safety and the safety of others is involved. Schiller Grounds Care, Inc., strongly warns against, Signal word definitions rejects and disclaims any modifications, add-on accessories or product alterations that are not...
  • Page 5 SAFETY TERRA RAKE GENERAL SAFETY Read the Operation & Safety Manual • The owner of this machine is solely responsible for properly training the operators. • The owner/operator is solely responsible for the operation of this machine and prevention of accidents or injuries occurring to him/her self, other people, or property.
  • Page 6 SAFETY / SAFETY DECALS TERRA RAKE OPERATION SAFETY • Do not attempt to work on the Terra Rake while the power unit engine is running. • Inspect machine before operation. Repair or replace any damaged, worn, or missing parts. Be sure guards and shields are in proper working condition and are secured in place.

  • Page 7: Assembly / Operation

    Rear Weight Requirements NOTE: Optional 3-point hitch installation is covered • The Steiner 450 tractors requires two 50# under it own section. See 3-Point Hitch Installation rear weights based upon average raking Section. conditions and operator’s weight of 150 lbs. The...

  • Page 8: Operation

    5. Remove large rocks before raking. DO NOT use the Terra Rake as a bulldozer. If large amounts of material needs to be leveled, start with a Steiner Slip Scoop or Steiner Power Angle Blade and smooth out first. Finish with the Terra Rake.

  • Page 9: Tine Depth / Tine Angle Adjustment

    ADJUSTMENTS TERRA RAKE TINE DEPTH AND TINE ANGLE ADJUSTMENT The TR270 tine depth and tine angle can be set to desired depths and angles by adjusting the caster spacer positions and the top link length. See typical configurations below. Light Tine Angle •...

  • Page 10: Rotation Adjustment / Caster Arm Placement

    ADJUSTMENTS TERRA RAKE ROTATION ADJUSTMENT • Rotate the rake to the right or left to direct material and create windrows of debris. • If desired, reverse auxiliary hydraulic hoses to reverse control operation. CASTER ARM PLACEMENT • Mounting the caster arms to the inside will make maneuvering next to barriers easier.

  • Page 11: Optional 3-Point Hitch Mounting

    OPTIONAL 3-POINT HITCH MOUNTING TERRA RAKE OPTIONAL REAR MOUNT 3-POINT HITCH To setup the TR270 Terra Rake for use on the 3-Point Quick Hitch QH202, it is recommended to first attach the rake to the front of the tractor for setup.
  • Page 12 OPTIONAL 3-POINT HITCH MOUNTING TERRA RAKE 10. For stability, the 75-71203 WB200 Front Weight Bar Kit and 75-71204 WB201 Weight Kit must be used if the TR270 is mounted to the 3-point hitch. 11. Attach the terra rake to the 3-point quick hitch. Reattach hose clamps to main frame and hitch frame.

  • Page 13: Maintenance / Storage

    MAINTENANCE / STORAGE TERRA RAKE MAINTENANCE LUBRICATION LOCATIONS DAILY INSPECTION AND MAINTENANCE 3 points-Centerlink and wheel casters RAKE TINE REPLACEMENT WARNING 1. Park power unit on level surface and set the parking brake. 2. Lower kickstand and lower rake to the ground. Shut off the tractor.

  • Page 15: Parts Section

    TERRA RAKE PARTS SECTION...

  • Page 16: Hitch Assembly

    HITCH ASSEMBLY TERRA RAKE FIGURE 1...
  • Page 17 HITCH ASSEMBLY TERRA RAKE FIGURE 1 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4177225.17 WLDMT-FRAME, MAIN 64268-03 NUT-FL NYLON LOCK 3/8-16 64262-011 BLT-FLG HD 3/8-16 X 1 64018-51 BLT-CRG 5/16-18 X 3/4 SN 64018-49 BLT-CRG 3/8-16 X 1-1/2 64018-34 BLT-CRG 5/16-18 X 1-1/2 4177754.7 BRKT-KICKSTAND LOWER...

  • Page 18: Main Frame Assembly

    MAIN FRAME ASSEMBLY TERRA RAKE FIGURE 2...
  • Page 19 MAIN FRAME ASSEMBLY TERRA RAKE FIGURE 2 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4177225.17 WLDMT-MAIN FRAME 4177210 TOP LINK 23-058 CYLINDER 1-1/2 X 5 DUMP 4176748 BAR-TINE FRAME CENTERING 64262-011 BLT-FLG HD 3/8-16 X 1 64268-03 NUT-FL NYLON LOCK 3/8-16 64123-342 BLT-HEX 1-14X7-1/2 64262-040...

  • Page 20: Caster Wheel Assembly

    CASTER WHEEL ASSEMBLY TERRA RAKE FIGURE 3...
  • Page 21 64262-040 BLT-FLG HD 3/8-16 X 4-1/2 GR 8 64268-03 NUT-FL NYLON LOCK 3/8-16 4137004 CAP-VINYL 4129801 BUSHING-FLANGED 4167312 DECAL-STEINER 85010N ZERK 1/4-28 STR SELF THREAD 64163-22 WSHR 1-1/32X1-3/4X1/2 4176233 WHEEL-ASSY 13X5.00-6 BLK 2722228-03 BEARING-205 W/SNAP RING 64173-04 QUICK PIN 7/16 X 2...

  • Page 22: Tine Assembly

    TINE RAKE ASSEMBLY TERRA RAKE FIGURE 4...
  • Page 23 TINE RAKE ASSEMBLY TERRA RAKE FIGURE 4 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4176899.17 WLDMT-TINE FRAME 4176766.17 BRKT-TINE HOLDER, LEFT 4176765.17 BRKT-TINE HOLDER, RIGHT 4177203 TINE, TERRA RAKE 4176745.17 PLT-TINE COMB 64268-03 NUT-FL NYLON LOCK 3/8-16 64262-039 BLT-FLG HD 3/8-16 X 4 GR 8 64262-012 BLT-FLG HD 3/8-16 X 1-1/4 4177614...
  • Page 24 SCHILLER GROUNDS CARE, INC. ONE BOB-CAT LANE P.O. BOX 469 JOHNSON CREEK, WI 53038 920-699-2000 www.schillergc.com ©Schiller Grounds Care, Inc. 2010...
