Steiel MA2000 Quick Start Manual

Viale Europa n° 24 - Z.I. Roncajette - 35020 Ponte San Nicolò (PD) - ITALY
Tel: 049 - 8961488 r.a Fax: 049 – 8960184 E-mail: steiel@tin.it
PANEL ALARM ACQUISITION SWITCHBOARD
CONTENTS:
Foreword
Packing list
How it works
Installation
Level of safety
Guarantee
Technical features
Frontal
Back
Electrical connections
Inside of front panel
Date/time setting
Programming from front panel
Programmable data
Programming from a PC pag.6
Other functions
Troubleshooting
FOREWORD:
This device has been designed and tested in compliance with IEC publication 348: Safety Requirements for
Electrical Equipment for Measurement. More to the point "This device has been designed and tested in
compliance with IEC publication 348, and all criteria have been passed. The following instruction manual
contains information and procedures that need to be followed in order to ensure the safe operation and
maintenence of the device over time. The device has been designed for use inside premises, although it can
occasionally be exposed to temperatures between +5 and –10°C without a resulting loss in safety".
The MA2000 switchboard and this manual are therefore in compliance with CEI 66/1 , 2 , 3 norms. The
switchboard is a "Class II device".
PACKING LIST:
The MA2000 switchboard is supplied with the following:
1) 1 electronic unit
2) 2 brackets for fastening to panel
3) This instruction manual
4) Guarantee coupon (guarantee is for one year; see coupon for conditions)
HOW IT WORKS:
In a state of no alarm, the MA2000 excites all output relays (safety condition) and the words 'NO ALARM'
appear on the display. A clock is always on, so current time also appears on the display. When an alarm is
recognised, the output relays are de-energised and the state of alarm (ALARM, SIREN and, possibly, SHUT)
is signalled; simultaneously, the triggering time is stored (this will appear on the display); the state of alarm is
also indicated by the flashing POWER-ON LED (normally a fixed light) and by the sound of an internal buzzer.
Any other alarms following the first one will also have the respective date and time stored, and will be displayed
in sequence. To switch off the state of alarm, all alarms need to be removed and identified using the ACK
button.
INSTALLATION:
This instrument has been designed for panel installation. Use the two brackets supplied for mounting. An
electrical control panel with transparent front door to protect the instrument from water sprinklers or other is
recommended. For further protection, use optional guard.
MA2000_IST_ING
STEIEL
MA2000
pag.1
pag.1
pag.1
pag.1
pag.2
pag.2
pag.2
pag.3
pag.3
pag.3-4
pag.4
pag.4
pag.5
pag.5-6
pag.7
pag.7
Rev.00 del 20-07-01
ELETTRONICA SRL
STEIEL elettronica s.r.l.
reserves the right
make changes to the
switchboard or to this
manual without notice.
Page 1 of 7
