Summary of Contents for Aspira CEX-70
-
Page 2: Fundamental Safety Rules
E N G L I S H C E X - 7 0 1. GENERAL 1.1 INTRODUCTION This manual was prepared with the aim of making the installation and management of your system as simple as possible. By reading and applying the suggestions of this manual, you can achieve the best performance of the purchased product. -
Page 3: Installation
CABINET KIT CEX-70 (code AP20375) SIDE VIEW FRONT VIEW FRONT VIEW PASSAGES FOR OUTDOOR and EXHAUST AIR BOTTOM VIEW 6+6 FITTINGS DN 75/90 INSTALLATION WITH RECESSED CABINET KIT + AIR OUTLET PLENUM CABINET KIT CEX-70 (code AP20375) + GEX-70 grids (code AP20376) -
Page 4: Unit Positioning
E N G L I S H C E X - 7 0 Model / code CEX-70 / AP20375 CEX-70 / AP20375 + GEX- 70 / AP20376 Width L Depth P Height H 1200 1200 + 320 Bracket depth P2 Outdoor air/ exhaust diameter DN Ø... - Page 5 E N G L I S H C E X - 7 0 CABINET KIT SECURING To secure the cabinet kit it is possible to: - secure the cabinet kit by the 4 rear holes, and based on the construction materials, using suitable screws and plugs;...
- Page 6 E N G L I S H C E X - 7 0 2.3 AERAULIC CONNECTION SET-UP CORRUGATED PIPE CONNECTION TOWARDS INDOOR ROOMS Inside the cabinet kit there are the connections for air distribution inside the building; It is possible to install up to 6 corrugated pipes with diam. of 75 mm for both supply and return; The body allows 6+6 corrugated pipes to pass through the bottom where the bottom insulation is installed;...
- Page 7 E N G L I S H C E X - 7 0 OUTDOOR AND EXHAUST AIR CONFIGURATIONS For the outdoor and exhaust air connections it is possible to choose from two types of installation; The first type refers to the cabinet kit with the Outdoor air accessory kit: -1 The cabinet kit is combined with the outdoor air kit to be connected by DN160 pipes to position the outdoor air kit at the chosen height;...
- Page 8 E N G L I S H C E X - 7 0 The second type, on the other hand, involves connection with dn160 OUTDOOR EXHAUST ducts and outdoor and ejection air grids remotely controlled by the installer; Outdoor and exhaust air configurations with ducts SUPPLY EXTRACTION CONNECTION WITH OUTDOOR AIR KIT...
- Page 9 E N G L I S H C E X - 7 0 The second through the direct assembly of the kit above the cabinet kit; In this case, proceed as shown in the figures on the side; Remove the sleeves of both cabinet kit and plenum, and place the plenum on top of the cabinet kit; Then, secure with the provided holes and screws;...
- Page 10 E N G L I S H C E X - 7 0 2.4 SET-UP FOR ELECTRICAL AND CONDENSATION DISCHARGE CONNECTIONS: ELECTRICAL AND CONDENSATION DISCHARGE CONNECTIONS Side entrances have been provided on both sides with pre-shearing of the cabinet kit for the set-up of electrical cables and condensation discharges;...
- Page 11 ........................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................................
- Page 12 FANTINI COSMI S.p.A. Via Dell’Osio, 6 - 20090 Caleppio di Settala, Milan, Italy Tel. +39 02 956821 | Fax +39 02 95307006 E-mail: info@aspira.it | supportotecnico@aspira.it www.aspira.it...
