FabiaTech FB2710 User Manual

Pc/104 cpu board low power series
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
FabiaTech Corporation
IPC Solution
Website:
http://www.fabiatech.com
Email:
support@fabiatech.com
PC/104 CPU Board
Low Power Series
FB2710
User's Manual
OCT 2017
Version: 1.1
Part Number: FB2710
i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FB2710 and is the answer not in the manual?

Questions and answers

Related Manuals for FabiaTech FB2710

Summary of Contents for FabiaTech FB2710

  • Page 1 FabiaTech Corporation IPC Solution Website: http://www.fabiatech.com Email: support@fabiatech.com PC/104 CPU Board Low Power Series FB2710 User’s Manual OCT 2017 Version: 1.1 Part Number: FB2710...
  • Page 2 FabiaTech shall not be reliable for technical or editorial errors or omissions, which may occur in this document. FabiaTech shall not be reliable for any indirect, special, incidental or consequential damages resulting from the furnishing, performance, or use of this document.

  • Page 3: Table Of Contents

    Table of Contents FB2710 User’s Manual ......................i Chapter 1 Introducing the FB2710 CPU Board................1 Overview..........................1 Series Comparison Table .......................2 Layout............................3 Specifications..........................4 Packing List ..........................5 Chapter 2 Hardware Installation ....................7 Before Installation ........................7 Hardware Features.........................8 DIMM1: So-DIMM Socket..................9 　...
  • Page 4 BIOS Functions ....................24 　 Keyboard Convention ..................25 　 Main Setup ..........................26 Advanced Setup........................27 ACPI settings ......................28 　 CPU Configuration....................30 　 IDE Configuration....................32 　 USB Configuration .....................34 　 SMART Settings....................37 　 Super IO Configuration ..................38 　 Wake Configuration ..................41 　 Realtek PCIe GBE Family Controller (MAC) ..........42 　...
  • Page 5 Watchdog Timer Setting ..................65 　 Watchdog Timer Enabled ................66 　 Watchdog Timer Trigger ..................66 　 Watchdog Timer Disabled................66 　 Chapter 6 Technical Reference ....................67 Technical Reference......................67 Physical and Environmental ................67 　 Real-Time Clock and Non-Volatile RAM ............67 　 CMOS RAM Map....................69 　...

  • Page 7: Chapter 1 Introducing The Fb2710 Cpu Board

    FabiaTech Corporation Chapter 1 Introducing the FB2710 CPU Board Overview The FB2710 is an AMD® G-Serial T16R low power all–in-one PC/104 CPU board. This user’s manual provides information on the physical features, installation, and BIOS setup. Built to unleash the total potential of the AMD® G-Serial T16R Processor, the FB2710 is a single board computer capable of handling today’s demanding requirements.

  • Page 8: Series Comparison Table

    FabiaTech Corporation Series Comparison Table Model FB2710 Processor T16R 615MHZ AMD® G-Serial Memory DDR3L-1066 204 Pin So-DIMM*1 4GB (Max.) Display VGA/LVDS S-Chipset AMD Fusion Controller HUB A55E Multi I/O Port One RS232 & One RS232/RS422/RS485 USB 2.0 Port Storage SATA Port...

  • Page 9: Layout

    FabiaTech Corporation Layout CN18 CN13 CN10 CN11 BUS1 DIMM1 CN12...

  • Page 10: Specifications

    FabiaTech Corporation Specifications Processor & Memory – AMD® G-Serial T16R 615MHZ (512KB L2 Cache) Low Power Processor One 204 pin So-DIMM socket for up to 4GB DDR3L/1066 RAM I/O Outlets – One 10/100/1000 base-TX Ethernet LAN port VGA and LVDS LCD Connector Three USB ports (2.0) and providing one AC97 audio function...

  • Page 11: Packing List

    Verify the accessories in the package according to the packing list and see if there is anything missing or incorrect package is included. • If the cable(s) you use to install the FB2710 is not supplied from us, please make sure the specification of the cable(s) is compatible with the FB2710 system.
  • Page 12 FabiaTech Corporation...

  • Page 13: Chapter 2 Hardware Installation

    FabiaTech Corporation Chapter 2 Hardware Installation This chapter introduces the system connectors & jumper settings, and guides you to apply them for field application. Before Installation Before you install the system, make sure you follow the below descriptions. 1. Before removing the board from its anti-static bag, wear an anti-static strap to prevent the generation of Electricity Static Discharge (ESD).

  • Page 14: Hardware Features

    FabiaTech Corporation Hardware Features The following list is for the setup of the connectors and jumpers of the FB2710. Item Description Battery Header (JST 2-Pin 2.0mm) RJ45-LAN 2.0mm connector (JST 12-Pin 2.0mm) LVDS LCD connector (DF13 30-Pin 1.25mm) VGA connector (IDC10-Pin 2.0mm) Power connector for LVDS LCD Backlight (JST 5-Pin 2.0mm)

  • Page 15: Dimm1: So-Dimm Socket

    FabiaTech Corporation DIMM1: So-DIMM Socket The DIMM1 socket on the solder side accepts 2GB to 4GB of DDR3L RAM module. DIMM1 CN12 CN12: CFAST Compact Flash Socket The CFAST Compact Flash socket CN12 (on the solder side) is support CFAST...

  • Page 16: Cn9: Serial Ata Hard Disk Connector

    FabiaTech Corporation CN9: Serial ATA hard Disk Connector CN18 Signal Ground TX-DP TX-DN CN13 CN10 Ground RX-DN RX-DP Ground CN11 BUS1 J4 & CN18: USB Connector Header The CPU board supports three USB port. Any USB device can be attached to USB ports with plug-and-play supported, J4 is10-pin connector and CN18 is 4-pin connector header.

  • Page 17: Cn6 & Cn8: Serial Port Connectors

    FabiaTech Corporation CN6 & CN8: Serial Port Connectors The Serial port 0 (CN8) is designed for multiple proposes. It could be RS-232, RS-422 or RS-485 by BIOS CMOS setting. Use the included serial cables for transferring 10- pin IDC to 9-pin D-sub connector. The following tables show the signal connections of these connectors.

  • Page 18: J2: External Speaker Header

    FabiaTech Corporation J2: External Speaker Header CN18 Signal Speaker+ CN13 Speaker- CN10 CN11 BUS1 CN1: External Battery heade CN18 Signal CN13 Battery + CN10 Battery - CN11 BUS1 D2: Power LED, D3: SATA and CFAST Access LED indicator CN18 CN13...

  • Page 19: Jp1: Clear Cmos Data

    J1 is a 2-pin header for connecting to system reset button. Shorting the circuit of the 2 pins makes the hardware reset and FB2710 restart system. It is similar to power off the system and then power it on again.

  • Page 20: Bus1: Pc/104 Bus Connectors

    I/O Port resource; when set ITE8888 ISA Decode is Positively decode, if you add on the I/O card or memory card to FB2710.You can refer to Chapter 6 Technical Reference “ Configure Positively Decode I/O port & Memory ”...

  • Page 21: Cn10: Audio Connector

    The CN4, CN6, and CN5 connectors on FB4706x are 2-way Line-In, mono Microphone input, and 2-way Lineout respectively. You can connect CN7 (Audio), CN2 (USB) cable from FB2710 CN10 and J4. The following figure shows these Audio connectors on FB4706x board:...

  • Page 22: Cn11: Power Connector (4-Pin 2.54Mm Jae)

    J3: Power Button header The J3 is a 2 pin connecting to Power Button Switch; It’s Pushing the PWR-SW button once will switch the FB2710 on or off. It’s depending on system BIOS (South Bridge > Restore on AC Power Lose) or OS setting.

  • Page 23: Cn13: Cpu Or System Fan Connector

    FabiaTech Corporation CN13: CPU or System Fan Connector CN13 CN18 Signal Ground +12V CN13 CN10 + 5V CN11 BUS1...
  • Page 24 FabiaTech Corporation...

  • Page 25: Chapter 3 Installing Vga & Lcd Display

    The following shows the block diagram of using FB2710 for LVDS LCD module. LCD Panel Block Diagram The diagram shows that FB2710 needs components to be linked with a LCD Module. NOTE: Be careful with the pin orientation when installing connectors and the cables. A wrong connection can easily destroy your LCD module.

  • Page 26: Vga Display (Cn4)

    FabiaTech Corporation VGA Display (CN4) The FB2710 supports a VGA colored monitor. It can be connected to create a compact video solution for the industrial environment. 254MB simulated VRAM allows a maximum VGA resolution of 1920X1080 with 32 bit at 60Hz. The following...

  • Page 27: Cn3 & Cn5: Lvds Connector And Power Connector

    Ground 14 LDP0_AUX + 15 LTDP0_AUX - 16 Ground LTDP0_HP0 Ground Ground Ground Ground LVDS_+3.3V 28 LVDS_+3.3V LVDS_+3.3V 30 LVDS_+3.3V NOTE: If any trouble occurs when connecting FB2710 with LCD panels, you could contact technical support division of FabiaTech Corporation.
  • Page 28 FabiaTech Corporation...

  • Page 29: Chapter 4 Bios Setup

    FabiaTech Corporation Chapter 4 BIOS Setup This chapter describes the BIOS setup. Overview BIOS are a program located on a Flash memory chip on a circuit board. It is used to initialize and set up the I/O peripherals and interface cards of the system, which includes time, date, hard disk drive, the ISA bus and connected devices such as the video display, diskette drive, and the keyboard.

  • Page 30: Bios Functions

    FabiaTech Corporation BIOS Functions On the menu, you can perform the following functions 1. Main 2. Advanced ACPI Settings CPU Configuration IDE Configuration USB Configuration SMART Settings Super IO Configuration WAKE Configuration IT8888 Configuration 3. Chipset North Bridge North Bridge LVDS Config Select South Bridge 4.

  • Page 31: Keyboard Convention

    FabiaTech Corporation Keyboard Convention On the BIOS, the following keys can be used to operate and manage the menu: Function [↑][↓] The Up and Down keys allow you to select item. [←][→] The Left and Right keys allow you to select screen.

  • Page 32: Main Setup

    FabiaTech Corporation Main Setup This section describes BIOS version information and basic system hardware configuration. If the CPU board is already installed in a working system, you will not need to select this option anymore. System Date & Time Setup Highlight the <Date>...

  • Page 33: Advanced Setup

    FabiaTech Corporation Advanced Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as USB Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...

  • Page 34: Acpi Settings

    FabiaTech Corporation ACPI settings This filed specifies allow you set this value to utilize the ACPI (Advanced Configuration and Power Interface) specification. Enabled ACPI Auto Configuration This item allows users to enable or disable BIOS ACPI Auto Configuration. Available Options: Disabled, Enabled...
  • Page 35 FabiaTech Corporation ACPI Sleep State This item allows users to select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. Available Options: Suspend Disabled, S1 Only (CPU Stop Clock) Default setting: Suspend Disabled Lock Legacy Resources This item allows users to enable or disable Lock of Legacy Resources.

  • Page 36: Cpu Configuration

    FabiaTech Corporation CPU Configuration The Item Display CPU Information, like CPU speed and L1/L2 cache and support function, you can use this screen to select options for the CPU information. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option.
  • Page 37 FabiaTech Corporation PPC Adjustment This field provides to adjust _PPC objects. Available Options: PSTATE0, and PSTATE2 Default setting: PSTATE0 NX Mode This field allows the users to enable or disable the No-executed page Protection functions. Available Options: Disabled, and Enabled...

  • Page 38: Ide Configuration

    FabiaTech Corporation IDE Configuration You can use this screen to select options for the SB SATA Configuration.
  • Page 39 FabiaTech Corporation SB SATA Configuration OnChip SATA Channel This item allows users to enable or disable SATA Controller. Available Options: Disabled, and Enabled Default setting: Enabled OnChip SATA Type Select a configuration for SATA controller. Install Windows XP in AHCI mode need to use the F6 Method pre-installed AHCI driver, if you select Legacy IDE mode, you do not need to pre-install.

  • Page 40: Usb Configuration

    FabiaTech Corporation USB Configuration You can use this screen to select options for the USB Configuration. Legacy USB Support Legacy USB Support refers to the USB mouse and USB keyboard support. Normally if this option is not enabled; any attached USB mouse or USB keyboard will not become available until a USB compatible operating system is fully booted with all USB drivers loaded.
  • Page 41 FabiaTech Corporation USB Mass Storage Driver Support Mass storage device emulation type. If the emulation FDD, recommended formatted as FAT32 format. Available Options: Disabled, and Enabled Default setting: Enabled USB transfer time-out The time-out value for control, bulk, and interrupt transfers.
  • Page 42 FabiaTech Corporation Device power-up delay > Select “Manual“ Device Power-Up delay in second Delay range is 1...40 seconds, in one second increments Available Options: 1, 5, 10, 20, 30, and 40 Sec Default setting: 5 Sec Generic Storage Device 1.01 Mass storage device emulation type.

  • Page 43: Smart Settings

    FabiaTech Corporation SMART Settings SMART Self TEST Run SMART Self TEST on all HDD during POST. Available Options: Disabled, and Enabled Default setting: Disabled...

  • Page 44: Super Io Configuration

    FabiaTech Corporation Super IO Configuration This section describes the function of Super I/O settings. Serial Port 0 Configuration These fields select the I/O port address for Serial port 0.
  • Page 45 FabiaTech Corporation Serial Port 0 This item allows users to select the enable or disable Serial port. Available Options: Enabled, and Disabled. Default setting: Enabled Device Settings Serial Port0: IO=3F8; IRQ=IRQ4 Transfer Mode Setting This item allows users can select RS-232, RS-422 and RS-485 of select COM1.
  • Page 46 FabiaTech Corporation Serial Port 1 Configuration Serial Port 1 This item allows users to select the enable or disable Serial port. Available Options: Enabled, and Disabled. Default setting: Enabled Device Settings Serial Port1: IO=2F8; IRQ=IRQ3...

  • Page 47: Wake Configuration

    FabiaTech Corporation Wake Configuration Onboard PCIE LAN PXE ROM This field specifies the PXE boot ROM of the onboard LAN chip. Available Options: Disabled, and Enabled Default setting: Disabled Wake ON Lan This item is can select Enabled to integrated LAN to wake up the system.

  • Page 48: Realtek Pcie Gbe Family Controller (Mac)

    FabiaTech Corporation Realtek PCIe GBE Family Controller (MAC) On the LAN Information screen, you can see the LAN Chipset information, when setting the Launch PXE OpROM Policy to UEFI Only of CSM Boot.

  • Page 49: Ite8888 Setting

    FabiaTech Corporation ITE8888 Setting ITE 8888 ISA Decode These fields are used for the Select Subtractive or positive decode IO Space. Available Options: Subtractive Decode, Positively Decode Default setting: Subtractive Decode Memory Hole 15MB- 16MB This field specifies the location of an area of memory that cannot be addressed on the ISA bus.
  • Page 50 FabiaTech Corporation ISA IO Decode Space This option allows you to select the IO port space for add on board on FB2710. Decode I/O Space 0~5 These fields are used for the enable configuration and the positive decode IO Space.

  • Page 51: Ite8888 Isa Decode Memory

    FabiaTech Corporation ITE8888 ISA Decode Memory This option allows you to select the Memory space to add on board on FB2710. Decode Memory Space 0~3 These fields are used for the enable configuration and the positive decode Memory Space. Available Options: Disabled and Enable...

  • Page 52: Chipset

    FabiaTech Corporation Chipset This section describes the configuration of the board’s chipset features. • North Bridge • North Bridge LVDS Config Select • South Bridge...

  • Page 53: North Bridge

    FabiaTech Corporation North Bridge You can use this screen to select options for the North Bridge Configuration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option.
  • Page 54 FabiaTech Corporation GFX Configuration On the Socket 0 Information screen, you can see the system memory information. Port 4 Control (Onboard LAN) The onboard LAN corresponding PCI Express port 4, the item allows users to enable or disable on board PCIe LAN.

  • Page 55: North Bridge Lvds Config Select

    FabiaTech Corporation North Bridge LVDS Config Select You can use this screen to select options for the Host Bridge Configuration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option.

  • Page 56: South Bridge

    FabiaTech Corporation South Bridge You can use this screen to select options for the South Bridge Configuration. South Bridge is a chipset on the motherboard that controls the USB, and audio function. Restore On AC Power Lose This field specifies the option controls how the PC will behave once power is restored following a power outage (or other unexpected or ungraceful shutdown).
  • Page 57 FabiaTech Corporation USB Configuration OHCI HC (Bus 0 Dev 18 FN 0) The USB OHCI HOST Control each of the USB ports (0~1). Enable: Enable USB 0, 1 port; Disable: Use USB port 0, 1 setting Available Options: Disabled, and Enabled...
  • Page 58 FabiaTech Corporation Azalia HD Audio Audio Controller This item allows users to enable or disable Azalia Controller. Available Options: Disabled, and Enabled Default setting: Disabled...

  • Page 59: Boot

    FabiaTech Corporation Boot Select the Boot tab from the setup screen to enter the Boot BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Boot Device Priority, to go to the sub menu for that item. You can display a Boot BIOS Setup option by highlighting it using the <Arrow>...
  • Page 60 FabiaTech Corporation Quiet Boot This item allows users to enable or disable Quiet boot option. If Enable, an OEM LOGO is shown instead of POST messages. Available Options: Disabled, and Enabled Default setting: Disabled Fast Boot This field is used to activate the fast boot function of the system. When set to Enabled, boot with initialization of a minimal set of devices required to launch active boot option.

  • Page 61: Csm Parameters

    FabiaTech Corporation Note: When you select a boot Option category from the boot menu, a list of devices in that category appears. For example, if the system has hard disk drives and USB storage connected, then the list will show all hard disk drives attached.
  • Page 62 FabiaTech Corporation Launch PXE OpROM Policy This option Controls the execution of UEFI and Legacy PXE OpROM. Available Options: Do not Launch, Legacy only, UEFI only, Leach First and UEFI First. Default setting: Do not Launch Launch Storage OpROM Policy This option Controls the execution of UEFI and Legacy Storage OpROM.

  • Page 63: Security

    FabiaTech Corporation Security Security Setup provides both Administrator and User password. If you use both passwords, the Administrator password must be set first. The system can be configured so that all users must enter a password every time the system boots or when Setup is executed, using either the Administrator password or User password.
  • Page 64 FabiaTech Corporation Clear Old Password Select Administrator/user password item, press <Enter> and type current password, at the next dialog press <Enter> to Clear Old Password.

  • Page 65: Save & Exit

    FabiaTech Corporation Save & Exit Save Changes and Exit When you have completed the system configuration changes, select this option to save the changes and Exit, so the new system configuration parameters can take effect. Discard Changes and Exit Select this option to quit without making any modifications to the system configuration.
  • Page 66 FabiaTech Corporation Discard Changes and Reset Select this option to reboot the system without saving the changes done in the setup configuration. Save Changes When you have completed the system configuration changes, select this option to save your system configuration and continue. For some of the options it required to reset the system to take effect...

  • Page 67: Chapter 5 Software Installation

    FabiaTech Corporation Chapter 5 Software Installation The enclosed CD diskette includes FB2710 VGA, System, Audio, and LAN driver. To install and configure you FB2710 system, you need to perform the following steps. Install AMD Catalyst ™ Drivers WIN XP/7 32/64 Driver To install the AMD T16R driver, insert the DVD ROM into the USB DVD ROM device, and enter DRIVER>VGA>AMD_T40E>WINXP, or >WIN7.

  • Page 68: Audio Driver

    FabiaTech Corporation Step 9: The AMD - Catalyst Install Manager will analyze the system, and install the required files. Step10: The AMD - Catalyst Install Manager will confirm when the installation is complete. Click Finish. Step11: When prompted, Click Yes to restart the system and complete the installation process.

  • Page 69: Pci To Isa Bridge Drivers

    FabiaTech Corporation PCI to ISA Bridge Drivers WINDOWS Driver Step 1: To install the PCI To ISA Bridge driver, insert the CD ROM into the CD ROM device, and enter DRIVER>SysChip >ITE8888 >WIN. If your system is not equipped with a CD ROM device, copy the PCI To ISA Bridge driver from the CD ROM to a CF.

  • Page 70: Watchdog Timer

    This section describes how to use the Watchdog Timer, including disabled, enabled, and trigger functions. The FB2710 is equipped with a programmable time-out period watchdog timer. You can use your own program to Enabled the watchdog timer. Once you have enabled the watchdog timer, the program should trigger the I/O every time before the timer times out.

  • Page 71: Watchdog Timer Setting

    FabiaTech Corporation Watchdog Timer Setting The watchdog timer is a circuit that may be used from your program software to detect system crashes or hang-ups. The watchdog timer is automatically disabled after reset. Once you have enabled the watchdog timer, your program must trigger the watchdog timer every time before it times out.

  • Page 72: Watchdog Timer Enabled

    FabiaTech Corporation Watchdog Timer Enabled To enable the watchdog timer, you have to output a byte of timer factor to the watchdog register whose address is 2eh and data port is 2fH. The following is a Demo program, which demonstrates how to enable the watchdog timer and set the time-out period at 28 seconds.

  • Page 73: Chapter 6 Technical Reference

    Relative humidity 0 % to 90 % non-condensing Real-Time Clock and Non-Volatile RAM The FB2710 contains a real-time clock compartment that maintains the date and time in addition to storing configuration information about the computer system. It contains 14 bytes of clock and control registers and 114 bytes of general purpose RAM.
  • Page 74 FabiaTech Corporation Address Description Minute alarm Hours Hour alarm Day of week Date of month Month Year Status register A Status register B Status register C Status register D Diagnostic status byte Shutdown status byte Diskette drive type byte, drive A and B...

  • Page 75: Cmos Ram Map

    FabiaTech Corporation CMOS RAM Map Register Description 00h -10h Standard AT-compatible RTC and Status and Status Register data definitions 11h – 13h Varies Equipment Bits Number of Floppy Drives 1 Drive 2 Drives Bits Monitor Type Not CGA or MDA 01 40x25 CGA...

  • Page 76: I/O Port Address Map

    FabiaTech Corporation I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses, which also becomes the identity of the device. There is a total of 1K-port address space available. The following table lists the I/O port addresses used on the Industrial CPU Card.

  • Page 77: Interrupt Request Lines (Irq)

    FabiaTech Corporation Interrupt Request Lines (IRQ) There are a total of 15 IRQ lines available on the Industrial CPU Card. Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on the Industrial CPU Card.

  • Page 78: Serial Ports

    FabiaTech Corporation Serial Ports The ACEs (Asynchronous Communication Elements ACE1 to ACE2) are used to convert parallel data to a serial format on the transmit side and convert serial data to parallel on the receiver side. The serial format, in order of transmission and reception, is a start bit, followed by five to eight data bits, a parity bit (if programmed) and one, one and half (five-bit format only) or two stop bits.
  • Page 79 FabiaTech Corporation Bit 1: Enable Transmitter Holding Empty Interrupt (ETBEI) Bit 2: Enable Receiver Line Status Interrupt (ELSI) Bit 3: Enable MODEM Status Interrupt (EDSSI) Bit 4: Must be 0 Bit 5: Must be 0 Bit 6: Must be 0...
  • Page 80 FabiaTech Corporation Bit 5: Stick Parity Bit 6: Set Break Bit 7: Divisor Latch Access Bit (DLAB) MODEM Control Register (MCR) Bit 0: Data Terminal Ready (DTR) Bit 1: Request to Send (RTS) Bit 2: Out 1 (OUT 1) Bit 3: Out 2 (OUT 2)
  • Page 81 FabiaTech Corporation Bit 4: Clear to Send (CTS) Bit 5: Data Set Ready (DSR) Bit 6: Ring Indicator (RI) Bit 7: Received Line Signal Detect (RSLD) Divisor Latch (LS, MS) Bit 0: Bit 0 Bit 8 Bit 1: Bit 1...

  • Page 82: Configure Positively Decode I/O Port & Memory

    ~D3FF:0 (16K), the following steps are for you to set up the I/O or memory resources manually. 1. Booting the FB2710 CPU board and get into the BIOS CMOS SETTUP > Advanced > IT8888 Settings >, then select ISA Decode IO Space.
  • Page 83 Note: 1. If the wrong selection of I/O ports or memory space conflicts on the FB2710 system board, you can clean CMOS setup by the JP1. 2. The step1 and Step 2 is for I/O add-on board, and step 3 is for ROM/RAM...

  • Page 84: Appendix

    FabiaTech Corporation Appendix Dimension a. FB2710...
  • Page 85 FabiaTech Corporation b. FB4706...
