Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or
property damage! Retain instructions for future reference.
Description
Heavy-duty dampers are constructed of extruded aluminum or galvanized steel frame and blades. Dampers can be mounted
horizontally or vertically. For intake or exhaust applications. Tie rod linkage is attached to blades on fan side.
Wiring Diagrams
N L1
H L2
12" to 49" - 100 to 240V, 50/60 Hz
Dimensions
A (C+3")
B (C+1")
D
(E+3")
E
⁹⁄₃₂" x ¹⁄₂"
Slotted Mounting Holes
ReaR View Closed
OPERATING INSTRUCTIONS
Motorized daMpers
ModeL aMd/GMd 12" - 72"
1 Neutral
2 Hot
S
1
NC
S
2
0° to 95°
S
3
NO
TF120-S
C
3"
¹⁄₂"
Note: Above dimensions + or – normal tolerance of .0625".
24 to 240 VAC
Wht
Blk
2"
BlADE
Clip
tiE roD
link
Motor
F
(D / 2)
9"
(Closed)
12" (open)
side View
(up to 24")
NFBUP-S
50" to 72" - 24 to 240V, 50/60 Hz
BrACE
BAr
BlADE Clip
tiE roD
link
Motor
1¹⁄₂"
10¹⁄₄" (closed)
13¹⁄₄" (open)
side View
(25" to 72")
2"
1¹⁄₂"
Advertisement
Table of Contents
Summary of Contents for ACP AMD
- Page 1 OPERATING INSTRUCTIONS Motorized daMpers ModeL aMd/GMd 12" - 72" Please read and save these instructions. Read carefully before attempting to assemble, install, operate or maintain the product described. Protect yourself and others by observing all safety information. Failure to comply with instructions could result in personal injury and/or property damage! Retain instructions for future reference.
- Page 2 All products manufactured are warranted by Air Conditioning products Company (ACp) to be free from original defects in workmanship for a period of one year from date of shipment, under conditions of normal use and service. ACp will replace or repair any defective parts upon return to our plant, freight prepaid. this limited warranty will, in no way, include the payment of labor charges for field replacement of defective parts, installation, repairs of adjustments, or any other work done.
