Type HT Chimney
UL Listed to:
• UL 103 HT Factory-Built Chimneys for Residential Type and Building Heating Appliances
• CAN/ULC-S604 STANDARD FOR FACTORY- BUILT TYPE A CHIMNEYS
Model HT - Double Wall 1" Fiber Insulation
Installation Instructions
A MAJOR CAUSE OF CHIMNEY RELATED FIRES IS FAILURE TO MAINTAIN REQUIRED
CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE
THAT THIS CHIMNEY BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS.
Important: Read all instructions before beginning to install. Failure to comply with these instructions may result in
a hazardous installation resulting in injury or damage to property. An improper installation will void the
manufacturer's warranty.
Keep these instructions for future reference.
For Technical Support or more product information please contact us at 678-388-2740 or visit our website at
www.jeremiasinc.com
Jeremias INSTALL_HT Rev: 3/26/19
1
Advertisement
Table of Contents
Summary of Contents for Jeremias HT 103
- Page 1 An improper installation will void the manufacturer’s warranty. Keep these instructions for future reference. For Technical Support or more product information please contact us at 678-388-2740 or visit our website at www.jeremiasinc.com Jeremias INSTALL_HT Rev: 3/26/19...
-
Page 2: Table Of Contents
Introduction Jeremias HT Chimney provides the highest quality product in its class. It features all welded inner and outer pipes, flue gas pipes made of 316L Stainless Steel, a unique design which leaves no destructive heat bridge between inners and outers and a strong, simple locking band design which makes for easy assembly. -
Page 3: Product Code Key
Product Code Key Each part manufactured by Jeremias is identified with a product code. The product code contains the Model, Vent size, Part ID, and Other information. Part Number Example: Chimney Model Diameter Material Product ID SS = 316ss Inner / 304ss outer 5"... -
Page 4: Suggested Tools, Equipment & Hardware
(Joists, studs, electrical, plumbing, etc.). Chimney Length Due to the engagement of the chimney sections, the effective installed length of any chimney pipe or fitting is 2-3/16” less than the described length. Jeremias INSTALL_HT Rev: 3/26/19... -
Page 5: Joint Assembly
Caution: Do not drill more than ½ deep into chimney pipe. Apply High Temperature (250°F) Silicone sealant over each screw to eliminate moisture penetration. Fig 4. HT Joint / Cut-away view Fig 5. Alternate Screw Joint Jeremias INSTALL_HT Rev: 3/26/19... -
Page 6: Cutting Pipe To Length
Secure the Ceiling Support by driving a minimum of two x 2” screws (provided) per side (minimum of 8 screws total) through the Ceiling Support box and into the framed Fig 7. Ceiling Support opening. Alternatively, three 8-penny nails per side can be used. Jeremias INSTALL_HT Rev: 3/26/19... -
Page 7: Chimney Adapter (Ad)
Refer to Table 2 for required maximum spacing distance. Secure mounting bracket to wood stud or suitable solid structure with 5/8” lag bolts. Route vent through clamp band and secure by tightening Clamp Band Bolts. Fig 11. Adjustable Wall Bracket (AWB) Jeremias INSTALL_HT Rev: 3/26/19... -
Page 8: Wall Thimble (Wt)
(black) 2” long wood screws provided. From the exterior, position Exterior-Trim-Plate-Halves against exterior plate and round tee branch perimeter. Secure with two #8 Self- drilling screws. 10. Use high-temperature sealant (500°F) to seal around chimney length, seams and all plates. Jeremias INSTALL_HT Rev: 3/26/19... -
Page 9: Tee With Cap (Twc)
SEB Brackets to the Tee Support Plate. Secure SEB Brackets to the wall. Ensure Wall Brackets are mounted to joist or other solid structure. Install adjoining chimney lengths as described in Joint Assembly section. Fig 17. Tee Support Extended Brackets (SEB) Jeremias INSTALL_HT Rev: 3/26/19... -
Page 10: Roof Support (Rs)
Install adjoining chimney lengths as described in Joint Assembly section. Anchor Plate (AP) Fig 18. Tee Support (above Tee) The Anchor Plate (AP) connects a masonry fireplace or a factory-built fireplace to Jeremias HT chimney. To Install For Masonry fireplace(see Fig 20) : Follow the requirements of the local building code for connecting factory-built chimney to masonry fireplace. -
Page 11: Firestop Radiation Shield (Frs)
Slide the AIS down over the chimney and position the plate of the AIS on the framed opening. Secure the AIS to the framed opening using the screws provided Fig 23. FRS & AIS Jeremias INSTALL_HT Rev: 3/26/19... -
Page 12: Storm Collar (Sc)
To install (See Fig 26): Verify Rain Cap location conforms to details in Termination Requirements section. Position Rain Cap on Chimney and secure. Refer to Joint Assembly section. Fig 25. Termination Requirements Fig 26. Rain Cap Fig 26. Chimney Cap Jeremias INSTALL_HT Rev: 3/26/19... -
Page 13: Spark Arrestor (Sa)
The chimney should be inspected once every 2 months during the heating season to determine if a creosote or soot buildup has occurred. If creosote or soot has accumulated, it should be removed to reduce the risk of chimney fire. Jeremias INSTALL_HT Rev: 3/26/19... - Page 14 Fig 29. CEILING SUPPORT INSTALLATION Fig 30. TEE SUPPORT INSTALLATION Jeremias INSTALL_HT Rev: 3/26/19...
- Page 15 Limited Warranty is limited to repair or replacement of the Product plus shipping cost to the location of the defective Product. The Limited Warranty does not cover labor costs for removal or replacement of the defective Product, unless such labor shall be carried out by Jeremias itself in its sole discretion.
- Page 16 Jeremias INSTALL_HT Rev: 3/26/19...
