OUTDOOR ENCLOSURE

Product Description

Total Cable Solutions' FPP-12S-W-16 incorporates high impact plastic that is ultraviolet and water resistant. The FPP-12S-W-16 can be
used for wall mounted and pole installation.
A flexible rubber jam and waterproof joint work together to create sustainable cable entries. The enclosure is suitable for 2.0mm or
3.0mm pigtail or drop cable.
Suitable for applications such as: FTTH Access Network, Telecommunications Network, CATV Networks, Data Communications Networks.
Special Key
TotalCableSolutions.com
|
INSTALLATION MANUAL
Product Photo
1 (of 4)
Total Cable Solutions
SAVE TIME & MONEY! BUY
FULLY LOADED
FROM TCS
TODAY!
Foam Circles
Silver Screws
Zip Ties (4)
Tubes (2)
Small Screws
Splice Sleeves
888.235.2097

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FPP-12S-W-16 and is the answer not in the manual?

Questions and answers

Summary of Contents for TCS FPP-12S-W-16

  • Page 1 TODAY! Product Description Total Cable Solutions' FPP-12S-W-16 incorporates high impact plastic that is ultraviolet and water resistant. The FPP-12S-W-16 can be used for wall mounted and pole installation. A flexible rubber jam and waterproof joint work together to create sustainable cable entries. The enclosure is suitable for 2.0mm or 3.0mm pigtail or drop cable.
  • Page 2 Installation Procedure Cable Fixing Point 1. When stripping the cable, take out the right fiber Cable. Insert it into the box through waterproof joint, and set the cable onto the cable fixing point and set the fiber onto the fiber fixing point. Fiber Fixing Point 2.
  • Page 3 SAVE TIME & MONEY! BUY FULLY LOADED FROM TCS TODAY! 3. Install the adapters, insert the pigtails into the adapters and fix them with small screws and board. Screws for fixing splice tray Cable Output Location 4. Fix the cable output onto the solid module and screw up, and output the cable through the black flexible rubber jam, and close up the box cover and screw down.
  • Page 4 SAVE TIME & MONEY! BUY FULLY LOADED FROM TCS Specifications TODAY! 1. Outdoor and indoor use 2. Dimensions: 10.25 in x 3.75 in x 12 in 3. 16 Simplex SC capacity 4. 12 Duplex (24 fiber) LC capacity 5. Inner splice tray with 24 fiber capacity 6.
