Summary of Contents for Travel Lite TLRV ROVE LITE
- Page 1 TRAVEL TRAILER OWNER’S MANUAL To our customers: For your maximum enjoyment and safety, we recommend familiarizing yourself with the contents of this manual before using your camper. Happy Camping!
-
Page 2: Table Of Contents
TABLE OF CONTENTS PLUMBING INTRODUCTION FRESH WATER SYSTEM DEALER RESPONSIBILITIES. WATER PUMP CONTROL SWITCH OWNER RESPONSIBILITIES WATER LINES PRE-TRAVEL INFORMATION SANITIZING THE FRESH WATER SYSTEM TOWING AND HANDLING 9-12 WASTE WATER AND SEWER LP PROPANE GAS SYSTEM DRAINAGE SYSTEM (MOST MODELS) LP GAS PRESSURE REGULATOR DRAINAGE LINES LP TANKS... -
Page 3: Introduction
NOTE: This manual is based on the latest information available at the time of publication. Due to continuous product development and improvements, Travel Lite, Inc. reserves the right to make changes in product specifications and components without prior notice or obligation. -
Page 4: Pre-Travel Information
PRE-TRAVEL INFORMATION To help ensure your traveling enjoyment, call ahead for tourist information in each area that you will be visiting or traveling through. To help eliminate frustration, make sure you obtain the most current road maps. Research and make sure there are no federal, state or local regulations that may prohibit you from fully enjoying your camping adventure. - Page 5 Refer to the hitch manufacturer instructions to adjust the weight-distributing hitch to the proper height. If you have additional questions, consult with your dealer. Travel Lite cannot be responsible for the suspension system of any tow vehicle. There are a variety of tow vehicle suspension systems available that will affect the ball height, stability and levelness of a hooked up RV.
- Page 6 PRE-TRAVEL INFORMATION WEIGHT DISTRIBUTING SYSTEM (CUSTOMER SUPPLIED) A weight distributing hitch system provides a more stable tow vehicle/RV combination. This system will spread the weight evenly to distribute it to the tow vehicle front and rear axles and the trailer axle. Consult with your dealer to familiarize yourself with the operation and requirements of the weight distributing hitch system.
- Page 7 PRE-TRAVEL INFORMATION WEIGHING YOUR TOW VEHICLE & RV Now that your RV is loaded you should have it weighed. The actual weight of the RV, passengers, all options, liquids, the hitch weight of your towed vehicle and your personal cargo is important for you to know so you do not exceed the GVWR.
- Page 8 PRE-TRAVEL INFORMATION FIRST SHORT TRIP After familiarizing yourself with the RV, including going through test runs on the systems and having the RV weighed, it is time to take one or two short trips. The experience gained can be priceless. We recommend an overnight stay at a nearby campground.
-
Page 9: Towing And Handling
TOWING AND HANDLING BREAKAWAY SWITCH The breakaway switch is a crucial part of the RV braking system. Located on the travel trailer A-frame, this switch will apply the trailer brakes if the trailer becomes detached from the tow vehicle. Attach the breakaway switch lanyard to a permanent part of the tow vehicle (on a travel trailer do not attach it to the hitch ball or similar removable parts) when hitching the trailer. - Page 10 TOWING AND HANDLING TRAVEL TRAILER HITCHING PROCEDURE Hooking up your RV will become easier with practice. The following procedure will help until you become more experienced. 1. Make sure the trailer wheels are blocked. 2. Turn the tongue jack crank to raise the travel trailer tongue above the hitch ball.
- Page 11 TOWING AND HANDLING TOWING BEHIND YOUR RV DO NOT tow anything behind your RV. The frame and bumper are not designed for towing. Parking After the RV is in the desired location, set the tow vehicle parking brake and place the transmission in TLRV park.
- Page 12 TOWING AND HANDLING 2. Loosen the wheel lug on the tire you are changing EMERGENCY STOPPING Always carry road flares or reflective warning signs before jacking up the RV. DO NOT remove the lug nuts; only loosen them for ease of removal when to display if necessary.
-
Page 13: Lp Propane Gas System
LP (LIQUEFIED PETROLEUM) PROPANE GAS SYSTEM Propane is an efficient, inexpensive, portable fuel that burns readily with intense heat. It is used for cooking, heating, and refrigeration. The propane systems in your TLRV camper are designed and built to rigid standards and are tested before leaving the factory for leakage. -
Page 14: Lp Gas Safety Precautions
LP GAS SAFETY PRECAUTIONS WARNING: DO NOT use propane while traveling. The main propane service valve must be shut • off while traveling because of the danger of a fire or explosion if a propane line under pressure were ruptured in an accident. In addition to being unsafe, it is ILLEGAL in some states to operate a propane appliance while the vehicle is in motion. -
Page 15: Safety And Warning Devices
Do not re-enter the camper until the alarm stops sounding. If the alarm sounds a second time after the propane is turned back on, leave the propane off and have a Travel Lite Dealer make the necessary repairs to the source of the propane leak. SMOKE DETECTOR Most fire casualties are caused by inhalation of toxic fumes (smoke) from a fire and not by flame. -
Page 16: Carbon Monoxide (Co)
2. Never attempt to repair or alter a gas or electric appliance. Always consult an authorized and qualified Travel Lite dealer or service technician. 3. Portable fuel-burning equipment, including wood and charcoal grills and stoves, cannot be used inside the camper. -
Page 17: Appliances And Equipment
APPLIANCES AND EQUIPMENT Remember to read all the manufacturer’s instructions BEFORE operating appliances. VENTING All LP gas fired appliances use oxygen from the air. It is necessary to provide proper ventilation when occupying your unit to avoid the danger of asphyxiation. For the best ventilation, open a window and roof vent. START-UP AND OPERATION OF LP GAS APPLIANCES •... -
Page 18: Range Exhaust Hood
WARNING: IT IS NOT SAFE TO USE COOKING APPLIANCES FOR COMFORT HEATING! 1. Cooking appliances need fresh air for safe operation. a. Open overhead vent or turn on exhaust fan. b. Open window 2. The amount of oxygen supply is limited due to the size of the recreational vehicle, and proper ventilation when using the cooking appliance(s) will avoid dangers of asphyxiation. -
Page 19: Roof Vents
ROOF VENTS The roof vents are operated from inside and have built-in screens. To operate, turn the crank in the center of the vent clockwise to open and adjust. The bath vent may be equipped with an optional 12-volt exhaust fan. The switch to control the fan is located on the vent. -
Page 20: Electrical Systems
ELECTRICAL SYSTEMS All electrical equipment must be handled with due care. Never try to repair or altar the electrical system by yourself, consult an authorized service technician. A 7-way connector pigtail is needed to connect the truck to the camper. The pigtail is wired into the truck and plugs into a matching 7-way chassis plug on the front end of the camper. -
Page 21: Battery Charging
If the replacement fuse of the same rating blows in a short time, there is probably an electrical problem with your camper. Leave the blown fuse in that circuit and have your camper checked by your Travel Lite dealer. -
Page 22: Interior Lighting
INTERIOR LIGHTING The interior lighting operates on 12-volt DC power only. When connected to a 110-volt source, the power converter transforms 110-volts to 12-volts. However, when not connected to 110-volts, the entire load of lights, water pump, exhaust fans, etc., is on your 12-volt battery. Use conservatively to minimize battery discharging. Some of the lighting fixtures may be equipped with halogen bulbs. -
Page 23: Plumbing
PLUMBING Most campers will have both the fresh water and drainage waste systems. Depending on the complexity of the plumbing system, the holding tanks, water lines, drainage lines, and fresh water tank will be located and run differently. FRESH WATER SYSTEM The water pump is a self-priming, automatic system that operates on demand. -
Page 24: Waste Water And Sewer
WASTE WATER AND SEWER DRAINAGE SYSTEM (MOST MODELS) Your camper has a drainage/sewer system, which functions much the same as the one in your home. The system consists of a main holding tank and an auxiliary holding tank. Waste from the toilet drain enters the main holding tank (black water) enabling you to use the toilet for several days away from disposal facilities. -
Page 25: Doors, Windows & Compartments
The entry door lock and deadbolt are keyed alike. The key is double sided so it can be installed into the lock in either direction. Be sure to write down the key number and keep it in a safe place. Your Travel Lite dealer can obtain duplicates with this number. -
Page 26: Winter Protection Of Your Camper
WINTER PROTECTION OF YOUR CAMPER CONDENSATION AND YOUR CAMPER Interior moisture can accumulate on windows and ceiling vents when the outside temperature is dramatically colder than the inside temperature. This is a natural occurrence that can be reduced by partially opening one or more roof vents and windows to provide controlled circulation of outside air into the interior of the camper. -
Page 27: Winter Storage Of Your Camper
WINTER STORAGE OF YOUR CAMPER If at all possible, TLRV recommends that you store your camper inside OUTDOOR WINTER STORAGE INSTRUCTIONS Outdoor winter storage requires certain precautions to prevent condensation of excessive moisture, which can cause musty odors and mold. EXTERIOR •... -
Page 28: Exterior Maintenance
EXTERIOR MAINTENANCE Routine maintenance is the best way to insure against cosmetic changes on the exterior components. Routinely wash and wax the exterior of the camper thoroughly to help prevent surface deterioration. Check the weather sealant every couple of months. Your TLRV dealer can inspect the camper and completely reseal, if necessary. -
Page 29: Interior Maintenance
INTERIOR MAINTENANCE Practice good housekeeping. Keeping a clean, well-maintained camper will result in many years of camping fun. Following the suggested cleaning procedures will eliminate many of the problems associated with poorly maintained units. A poorly maintained unit can result in voiding of the warranty, as will negligence, misuse, or the installation of equipment not authorized by TLRV. -
Page 30: Pre-Travel Check List
PRE-TRAVEL CHECK LIST Proper planning of your trip will ensure a pleasurable experience. A thorough knowledge of your truck camper is important if you are going to get the most of the convenience and safety built into your camper. You should become as familiar with your camper as you are with your own personal car or truck. -
Page 31: Periodic Maintenance Chart
PERIODIC MAINTENANCE CHART... -
Page 32: Limited Warranty
W A R R A N T Y WHAT AND WHO IS COVERED This TLRV Recreational Vehicle (“RV”) is distributed by Travel Lite, Inc. As such, Travel Lite, Inc. (“TLRV” or “Warrantor”) supplies the warranty. The TLRV warranty covers this RV, when used only for its intended purpose of recreational travel and camping. -
Page 33: Limited Warranty
W A R R A N T Y may occur at the factory. These items are usually detected and corrected at the factory or by the selling dealer prior to delivery to the retail customer. You must inspect your RV for this type of damage when you take delivery. If you find any such defect or damage you must notify the selling dealer at time of delivery to have these items covered by this limited warranty and to have work performed on the items at no cost to you as provided by this limited warranty.
